Specifications
Model Number :
Cr12MoV
Brand Name :
Bao Steel
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
500KGS
Price :
1.45 USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
50000KGS
Delivery Time :
14 DAYS
Packaging Details :
Wodden Pallet
Steel grade :
Alloy Steel
Alloy or not :
Is Alloy
Technique :
Hot Rolled,Forged,Cold Drawn
Application :
Tool Steel Bar,chemical,shipbuilding
Type :
Alloy Steel Bar
Standard :
ASTM,DIN,AISI
Special use :
Mold Steel
Shape :
Round
Length :
1--12m
Surface :
black or bright
Product name :
Cr12MoV
Diameter :
12mm-650mm
Delivery condition :
annealed,hot rolled/forged
Heat treatment :
Normalized +Annealed +Quenched + Tempered
Description

Cr12MoV Steel Properies Cr12Mov Chemical Composition SKD11 Tool Steel Round Bar Bright Rod

D2 Tool Steel | 1.2379 | Cr12MoV | SKD11 steel

  • What is D2 steel?

AISI D2 is a cold work tool steel.Cold work die steel D2 steel with high abrasion resistance, micro deformation, the wind hard tool steel, carbon content as high as 1.5%, chromium content as high as 11.5%, the heat treatment hardness can reach 60 HRC. Otai Special Steel are chinese d2 steel china supplier in steel round bar, plate, flat.

D2 tool steel properties as below:

  • D2 steel composition
Grade C(％) P(%) Si(％) S(%) Mn(％) Cr(%) Mo(％) V(%)
AISI D2 1.40～1.60 ≤0.030 0.10～0.60 ≤0.030 0.20～0.60 11.0～13.0 0.70～1.20 0.50～1.10
  • AISI D2 steel equivalent

1, JIS SKD11 steel

2, GB Cr12MoV steel

3, DIN.EN 1.2379 steel

4, KS STD11 cold work steel

D2 tool steel heat treatment

  • Forging of D2 die steel

Pre heat to 700 °C, Then rapidly heat to 900-1040 °C. Start forge the D2 steel fabrication.

  • Annealing of D2 cold work tool steel

Heat to 900 °C, soak enough time. cool in furnace until to room temperature.

  • Quenching of AISI D2 tool steel

For improve d2 tool steel hardness, Quenching is needs. Heat to 1010°C, heat thoroughly, cool in air.

  • Tempering of Tool Steel D2

After Quenching, according different tool requirement, Tempering at different temperature. Typical data as below:

Temperature [°C] 150°C 200°C 250°C 300°C 350°C 400°C
Hardness [HRC] 62-61 61-60 60-59 57-56 56-55 56-55

Mechanical properties and Physical properties of AISI D2 steel grade material

  • Melting point 1421°C
  • Density of D2 steel: About 7.85 kg/cm3 at room temperature
  • Hardness: Rockwell C 62 HRc, Vickers 748 V
  • Izod impact unnotched: 77 J
  • Elastic modulus: 190-210 GPa.
  • Thermal Properties: 10.4 x 10-6/ºC

Machining D2 tool Steel
