High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
Specifications
Brand Name :
JIU STEEL
Model Number :
AZ150 AZ120
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
500KGS
Price :
0.85 USDKG
Payment Terms :
L/C, T/T
Supply Ability :
50000KGS
Delivery Time :
14 DAYS
Packaging Details :
Wodden Pallet
Width :
600mm-1250mm
Standard :
ASTM,AISI,JIS,DIN
Length :
Customer's Requirement
Grade :
Q195 DX51D DX53D SGCC
Zinc coating :
30-275g/m2
Technique :
Cold Rolled
Coil weight :
3-8 Tons
Type :
Steel Coil
Spangle :
Minimized
Surface :
Galvanized Coated
Thickness :
0.12-4.0
Product name :
Galvanized Steel Coil
Description

High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120

Resist rust, fire and elemental onslaughts with galvalume steel sheet & coil from Alliance Steel.

Galvalume steel is carbon steel coated with an aluminum-zinc alloy using a continuous hot dip process, combining the corrosion protection and high temperature resistance of aluminum with the formability and galvanic protection of zinc.

Galvalume steel’s unique protective characteristics and economical price point make it ideal for residential and commercial exterior building products, including roofing, siding and cabinetry.

Galvalume Steel Sheet

Alliance Steel Multi-Blanking Capabilities:

Material Thickness: .015-.135

Max Coil: 45,000lbs

ID: 20”-24”

Entry Width: 15.00”-74.00”

Exit Width: 5.00”-74.00”

Length: 6.00”-144”

Width/Length Tol: +/-.010

Galvalume Steel Coil

Alliance Steel Slitting Capabilities:

Material Thickness: .010-.250

Min/Max Slit width: .375”-72”

Min/Max ID: 20”-30”

Max OD: 73”

Slit Width Tolerance: +/-.005

Alliance Steel’s galvalume steel service capabilities include slitting, shearing, blanking, degreasing and brushing, stretcher leveling and metallurgical support.

Contact Alliance Steel for galvalume steel product information and availability.

Structural Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
30,33,36,40 0.25 0.9 0.035 0.04 0.2 0.2 0.15 0.06 0.008 0.008 0.025
36T2,45-80 0.25 1.35 0.035 0.04 0.2 0.2 0.15 0.06 0.008 0.008 0.025
45T2 .02- 0.08 .30- 1.0 .03- .07 0.025 .02- .08 0.6 0.2 0.2 0.15 0.06 0.008 0.008 0.025 .01- .03

HSLA Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
45C1 0.22 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
45C2 0.15 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C1 0.23 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
50C2 & 55C2 0.15 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
55C1 0.25 1.35 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C1 & 65C1 0.26 1.5 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
60C2 & 65C2 0.15 1.5 0.04 0.04 0.2 0.2 0.15 0.06 0.005 0.005 0.005
70C1 0.26 1.65 0.04 0.04 0.2 0.2 0.15 0.16 0.005 0.005 0.005
70C2 0.15 1.65 0.04 0.04 0.2 0.2 0.15 0.16 0.005 0.005 0.005

Common Grades C Mn P S Al Si Cu Ni Cr Mo V Cb Ti N
CSA 0.1 0.6 0.03 0.035 0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSB 0.02-.15 0.6 0.03 0.035 0.2 0.2 0.15 0.06 0.008 0.008 0.025
CSC 0.08 0.6 0.1 0.035 0.2 0.2 0.15 0.06 0.008 0.008 0.025
BH 0.012 1.5 0.12 0.03 0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSA 0.1 0.5 0.02 0.035 0.2 0.2 0.15 0.06 0.008 0.008 0.025
FSB 0.02-.15 0.5 0.02 0.03 0.2 0.2 0.15 0.06 0.008 0.008 0.025
DDS 0.06 0.5 0.02 0.025 .01 0.2 0.2 0.15 0.06 0.008 0.008 0.025
EDDS 0.02 0.4 0.02 0.02 .01* 0.2 0.2 0.15 0.06 0.1 0.1 0.15

High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120High Corrosion Resistance Galvanized Steel Coil Galvalume Coil AZ150 AZ120
