ABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel Plate
ABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel Plate
ABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel Plate
ABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel Plate
ABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel Plate
ABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel Plate
Specifications
Brand Name :
TSING SHAN
Model Number :
AH36 DH36 EH36
Certification :
ISO SGS MTC
Place of Origin :
China
MOQ :
100KGS
Price :
0.65-0.95 USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
50000KGS
Delivery Time :
7 Days
Packaging Details :
Export Packing
Product Keywords :
Steel metal plate
Grade :
A, B, D, E, AH32, AH36, DH32, DH36, EH32, EH36
Type :
plate
Length :
3000mm-18000mm
Standard :
ASTM, GB, JIS, EN
Technique :
cold rolled / hot rolled
Application :
Shipbuilding, Offshore Platforms, Bridges
Width :
1500mm-4500mm
Trade Term :
EXW,FOB,CIF,CFR
Shape :
Plate
Mill :
Bao Steel Mittel Steel
Usage :
Shipbuilding
Packing :
Standard Seaworthy Packing
Payment Terms :
L/C T/T (30% Deposit)
Size :
Customized
Description

ABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel Plate

ABS/AH36,ABS/DH36,ABS/EH36,ABS/FH36 ship plate steel plates

1.Grade: ABS/A,ABS/B,ABS/D,ABS/E,ABS/AH32,ABS/DH32,ABS/EH32,ABS/FH32,ABS/AH36,ABS/DH36,
ABS/EH36,ABS/FH36,ABS/AH40,ABS/DH40,ABS/EH40,ABS/FH40,ABS/2HGr50

2.classification societies:ABS

3.T*W*L: 8--200 mm* 1500--4020mm * 3000--18000 mm

4.Payment terms: T/T,L/C
5.Delivery term: Within 30 days

6.Delivery condition: AR,CR,TMCP,N or QT
7.Pretreatment services:Painting,Blasting,Clearing rust.
We are glad to inform you that our products were used in Bird Nest,Three Gorges Dam and many other national projects.We also can provide you the relative MTC sample.

The steel AB/AH36, AB/DH36, AB/EH36, AB/FH36 is used in the construction of container ships, bulk carriers and commercial ships such as liners and ferries.

AH36 Shipbuilding Steel Chemical Composition:

Grade C % Si % Mn % P % S % V % AL % Cr %
Grade AH36 0.180 0.1-0.5 0.90-1.6 0.035 0.035 0.05-0.10 0.015 0.200
Cu % Mo % Nb % Ni % Ti %
0.350 0.080 0.02-0.05 0.400 0.020

AH36 Grade Ship Steel Mechanical Properties:


Grade		 Thickness(mm) MinYield(Mpa) Tensile(Mpa) Elongation (%) Min Impact Energy
DNV Grade AH36 8mm-50mm Min 355Mpa 490-620Mpa 21% -0 34J
51mm-70mm Min 355Mpa 490-620Mpa 21% -0 41J
71mm-100mm Min 355Mpa 490-620Mpa 21% -0 50J

If you want to know the AH36 steel price, please contact us,we will give you our formal quotation as soon as possible.

ABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel PlateABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel PlateABS Grade A Steel Plates 6000x2000mm x 16mm Thick AH36 EH36 Shipping Steel Plate
