Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1
Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1
Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1
Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1
Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1
Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1
Specifications
Brand Name :
TSING SHAN
Model Number :
ASTM A283 Grade C
Certification :
ISO SGS MTC
Place of Origin :
China
MOQ :
100KGS
Price :
0.45-0.95 USD/KG
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000KGS
Delivery Time :
7 Days
Packaging Details :
Export Packing
Technology :
Hot Rolled Cold Rolled
Packing :
Normal shipping packing or As required
Surface :
Black Painted,galvanized,etc.
Hs Code :
7208900000
Origin :
Jiangsu,China
Corrosion Resistance :
Low
Sample :
Sample Freely
Elongation :
20%
Stock :
Stock
Tolerance :
±1%
Quality :
Prime,Secondary,etc.
Surface Finish :
Hot rolled
Invoicing :
by actual weight
Description

ASTM A283 Grade C Plate Metal Hot Rolled Smooth Surface 8.0*2000*6000mm With MTC EN 10204 TYPE 3.1

ASTM A283 Carbon Steel Plate

ASTM A283 plate steel features low and intermediate tensile strength carbon steel plate of structural quality. It has four common variants, each represented as a separate material. The material properties section below shows ranges encompassing all variants.

This specification covers four grades of carbon steel plates of structural quality for general application. Steel samples shall be melt processed by either open-hearth, basic-oxygen, or electric furnace. Heat and product analysis shall be performed wherein steel materials shall conform to required chemical compositions of carbon, manganese, phosphorus, sulfur, silicon, and copper. Steel specimens shall also undergo tensile tests and shall conform to required values of tensile strength, yield point, and elongation.

ASTM A283 Chemical Properties
Grade A Grade B Grade C Grade D
Carbon, max 0.14 0.17 0.24 0.27
Manganese, max 0.90 0.90 0.90 0.90
Phosphorus, max 0.035 0.035 0.035 0.035
Sulphur, max 0.04 0.04 0.04 0.04

Silicon

Plates 1 1/2 in and under, max

Plates over 1 1/2 in

 0.40 0.15-0.40 0.40 0.15-0.40 0.40 0.15-0.40 0.40 0.15-0.40
Copper min % when copper steel is specified 0.20 0.20 0.20 0.20
ASTM A283 Mechanical Properties
Grade A Grade B Grade C Grade D
Tensile Strength:

45,000 -60,000 psi

[310 - 415 MPa]

50,000 -65,000 psi

[345 - 450 MPa]

55,000 75,000 psi

[380 - 515 MPa]

60,000 -80,000 psi

[415 - 550 MPa]
Min. Yield Point:

24,000psi

[165 MPa]

27,000psi

[185 MPa]

30,000psi

[205 MPa]

33,000psi [

230 MPa]
Elongation in 8": 27% min 25% min 22% min 20% min
Elongation in 2": 38% min 28% min 25% min 23% min

ASTM A283 carbon steel is an alloy of iron, further classified as a carbon steel. This is steel specification covers four grades of low carbon steel plates of structural quality for general application. Grades A, B, C and D.

Comparison between A36 and A283C
  • ASTM A 283 Gr C consist of four grade of material (A,B,C, & D) of carbon steel plate of structural quality for general application.
  • ASTM A 36 covers carbon steel plate, shape, and bar of structural quality for use in riveted, bolted or welded construction of bridges and building and for general structural purpose.
  • From material scope, both ASTM A 36 and ASTM A 283 are the carbon steel of structural quality for general application.

Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1Astm A283 Grade C Hot Rolled Carbon Steel Sheet Plate Metal Smooth Surface 8.0*2000*6000mm With Mtc En 10204 Type 3.1

Q:Can I get samples before order ?
A:Yes, of course. Usually our samples are free,we can produce by your samples or technical drawings.
Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q:How can I get a quotation from you ?
A:You can leave us message, and we will reply every message in time. Or we may talk on line.
Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.we accept the third party inspection absolutely.
