904l Stainless Steel Sheet Plate Bendable Cold Rolled 4mm 3mm 420 405
904l Stainless Steel Sheet Plate Bendable Cold Rolled 4mm 3mm 420 405
904l Stainless Steel Sheet Plate Bendable Cold Rolled 4mm 3mm 420 405
904l Stainless Steel Sheet Plate Bendable Cold Rolled 4mm 3mm 420 405
904l Stainless Steel Sheet Plate Bendable Cold Rolled 4mm 3mm 420 405
904l Stainless Steel Sheet Plate Bendable Cold Rolled 4mm 3mm 420 405
904l Stainless Steel Sheet Plate Bendable Cold Rolled 4mm 3mm 420 405
904l Stainless Steel Sheet Plate Bendable Cold Rolled 4mm 3mm 420 405
Specifications
Certification :
ISO9001, CE
Place of Origin :
Jiangsu, China
MOQ :
1 ton
Payment Terms :
L/C, T/T
Supply Ability :
5000 Ton/Tons per Month
Delivery Time :
7~10working days
Product name :
Stainless Steel Sheet
Type :
Cold Rolled,Hot Rolled
Surface :
No.1,2D,2B,BA,No.4,8k,Tempered
Thickness :
0.4mm~6mm
Brand Name :
Changjian
Description

Grade 316Ti Stainless Steel Sheet

316Ti (1.4571) STAINLESS STEEL

316Ti (UNS S31635) is a titanium stabilised version of 316 molybdenum-bearing austenitic stainless steel.

The 316 alloys are more resistant to general corrosion and pitting/crevice corrosion than the conventional chromium-nickel austenitic stainless steels such as 304. They also offer higher creep, stress-rupture and tensile strength at elevated temperature. High carbon Alloy 316 stainless steel can be susceptible to sensitisation, the formation of grain boundary chromium carbides at temperatures between approximately 900 and 1500°F (425 to 815°C) which can result in intergranular corrosion. Resistance to sensitisation is achieved in Alloy 316Ti with titanium additions to stabilise the structure against chromium carbide precipitation, which is the source of sensitisation. This stabilisation is achieved by an intermediate temperature heat treatment, during which the titanium reacts with carbon to form titanium carbides. This significantly reduces susceptibility to sensitisation in service by limiting the formation of chromium carbides. Thus, the alloy can be used for extended periods at elevated temperatures without compromising its corrosion resistance. 316Ti has equvilent corrosion resistance to sensitisation as the low carbon version 316L.

CHEMICAL COMPOSITION

Element C Mn Si P S Cr Ni N Ti
316 0.07% 2.0% 1.00% 0.045% 0.03% 16.5~18.5% 10.0~13.0% 0.11% -
316L 0.03% 2.0% 1.00% 0.045% 0.02% 16.5~18.5% 10.0~13.0% 0.11% -
316LN 0.03% 2.0% 1.00% 0.045% 0.015% 16.5~18.5% 10.0~12.5% 0.12~0.22% -
316Ti 0.08% 2.0% 0.75% 0.045% 0.03% 16.0~18.0% 10.0~14.0% 0.10% 5x%(C+N)~0.70%

MECHANICAL PROPERTIES

Grade

Tensile Strength

(MPa)

Yield Strength

(MPa)Min

Density

(g/cm3)

Brinell

(HB)Max
316 500~700 200 8 215
316L 520~680 220 8 215
316LN 580~780 205 8 220
316Ti 515Min 205 8 209

316Ti COMMON APPLICATIONS

  • Equipment that resists sulfuric acid, phosphoric acid, acetic acid, and acetic acid;
  • Petrochemical;
  • Mechanical and electrical hardware;
  • Shipyard;
  • Power plant;
  • Others
