Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale
Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale
Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale
Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale
Specifications
MOQ :
1 Roll
Supply Ability :
3000 Rolls per month
Packaging Details :
Inside waterproof paper,outside wooden carton
Material :
Stainless steel,galvanized
Opening size :
0.0385-10.9
Wire diameter :
0.025-1.8
Width :
1m-1.5m
Length :
30m
Application :
Filtration
Description

Metal mesh fine mesh h/stainless steel wire mesh/304 ss wire mesh screen for hot sale

Stainless steel mesh

Material: stainless steel wire mesh, copper mesh, I-mesh, stainless steel sintered mesh, stainless steel wire mesh, expanded metal, expanded metal mesh, perforated metal mesh and other metal net.
Stainless steel mesh wrapping

Edging material: stainless steel plate.
Product Shape: rectangular, square, round, oval, circular, rectangular, hat, waist and shaped
Stainless steel welding wire mesh

Material: stainless steel wire mesh, copper mesh, I-mesh, stainless steel sintered mesh, stainless steel wire mesh, expanded metal, expanded metal mesh, perforated metal mesh and other metal net.
Product structure: single, double, three, four, five, multiple layers.
Processing Size: 6 mm to 650 mm.
Category: single filter sheet, multi-spot welding filter chip, packet filter chip, combined filter sheet.

material
mesh size
wide m
length
stainless steel201
4mesh--500mesh
0.914 , 1 ,1.22, 1.3, 1.6
30m
stainless steel304
4mesh--500mesh
0.914 , 1 ,1.22, 1.3, 1.6
30m
stainless steel304
4mesh--500mesh
0.914 , 1 ,1.22, 1.3, 1.6
30m

Stainless steel wire mesh specification list

Mesh/inch Wire diameter mm Aperture mm Mesh/inch Wire diameter mm Aperture mm
2mesh 1.8 10.90 60 mesh 0.15 0.273
3 mesh 1.6 6.866 70 mesh 0.14 0.223
4 mesh 1.20 5.15 80 mesh 0.12 0.198
5 mesh 0.91 4.17 90 mesh 0.11 0.172
6 mesh 0.80 3.433 100 mesh 0.10 0.154
8 mesh 0.60 2.575 120 mesh 0.08 0.132
10 mesh 0.55 1.990 140 mesh 0.07 0.111
12 mesh 0.50 1.616 150 mesh 0.065 0.104
14 mesh 0.45 1.362 160 mesh 0.065 0.094
16 mesh 0.40 1.188 180 mesh 0.053 0.088
18 mesh 0.35 1.060 200 mesh 0.053 0.074
20 mesh 0.30 0.970 250 mesh 0.04 0.061
26 mesh 0.28 0.696 300 mesh 0.035 0.049
30 mesh 0.25 0.596 325 mesh 0.03 0.048
40 mesh 0.21 0.425 350 mesh 0.03 0.042
50 mesh 0.19 0.318 500 mesh 0.025 0.0385

Plain dutch weave mesh

Mesh per inch(warp×weft) Wire diameter(warp×weft)
12×64mesh 0.58×0.40mesh
14×88mesh 0.50×0.33mesh
24×110mesh 0.355×0.25mesh
30×150mesh 0.23×0.18mesh
40×200mesh 0.18×0.14mesh
50×250mesh 0.14×0.11mesh
60×300mesh 0.14×0.09mesh
70×400mesh 0.12×0.08mesh

Twill weave mesh

Type Wire diameter aperture
inch mm inch mm
50×50 .010 .250 .0110 .28
50×50 .011 .280 .0120 .31
60×60 .006 .160 .0092 .23
60×60 .007 .180 .0097 .25
70×70 .007 .170 .0078 .20
80×80 .007 .180 .0060 .15
80×80 .006 .180 .0070 .18
90×90 .006 .140 .0061 .16
100×100 .005 .120 .0055 .14
110×110 .005 .120 .0051 .1295
120×120 .0037 .0940 .0064 .1168
150×150 .0026 .0660 .0041 .1041
160×160 .0025 .0635 .0038 .0965
180×180 .0023 .0584 .0033 .0838
200×200 .0021 .0533 .0029 .0737
250×250 .0016 .0406 .0024 .0610
270×270 .0016 .0406 .0021 .0533
300×300 .0051 .0381 .0018 .0457
325×325 .0014 .0356 .0017 .0432

Twilled dutch weave mesh

Mesh per inch(warp×weft) Wire diameter(warp×weft)
24mesh×220mesh 0.3×0.25
20mesh×250mesh 0.3×0.2
50mesh×500mesh 0.14×0.11
80mesh×700mesh 0.1×0.08
165mesh×800mesh 0.071×0.045
200mesh×600mesh 0.071×0.050
200mesh×1400mesh 0.14×0.09
165mesh×1400mesh 0.071×0.04
325mesh×2300mesh 0.035×0.025
400mesh×2800mesh 0.03×0.02

Reverse dutch weave mesh

Mesh per inch25.4mm warp×weft Wire diameter (warp×weft) Fineness of filtering micron
48×10 0.5×0.5 330
63×18 0.40×0.60 220
72×15 0.45×0.55 210
100×16 0.35×0.45 190
107×20 0.24×0.60 210
120×16 0.35×0.45 180
132×17 0.32×0.45 170
152×24 0.27×0.40 160
160×17 0.27×0.45 160
170×18 0.27×0.45 160
171×46 0.15×0.30 130
180×20 0.27×0.45 170
200×40 0.17×0.27 120
240×40 0.15×0.25 70
260×40 0.15×0.27 55
290×76 0.09×0.19 40
300×40 0.15×0.25 50
300×80 0.15×0.20 35
400×120 0.058×0.10 30
615×105 0.04×0.11 27
615×125 0.04×0.11 25
615×130 0.04×0.13 22
615×132 0.04×0.11 22
625×104 0.04×0.15 28
720×150 0.036×0.1 17

Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale

Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale

Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale

Packing of stainless steel woven wire mesh

Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale

Product series

Metal mesh fine mesh/stainless steel wire mesh/304 ss wire mesh screen for hot sale

Company introduction

Our company Anping tenglu metal wire mesh co.,ltd is located in the wire mesh industrial base Anping city in China,after 15 years of development,at present our product cover stainless steel woven wire mesh,welded wire mesh,expanded wire mesh,crimped wire mesh,hexagonal wire mesh,knitted wire mesh,shale shaker screen,wire conveyor belt.

If make an offer,we need to get following product information,

Material

Wire diameter

Aperture

Wire mesh length per roll.

Wire mesh width per roll

We welcome your enquiry.
