Specifications
Brand Name :
TL
Model Number :
TL SC03
Place of Origin :
Hengshui,China
MOQ :
5 rolls
Price :
4.5-80 us dollar/square meter
Supply Ability :
50 0000 square meters per month
Packaging Details :
Waterproof paper is used to separate the inner two sheets of net, and the outer one is packed in wooden cases
Material :
Stainless steel
Application :
Moisquito proof
Color :
White,black,grey etc
Feature :
anti-theft, anti-missile, anti-mosquito, anti-rat
Wire diameter :
0.5-1.9mm
Mesh size :
10 mesh, 11 mesh, 12 mesh, 14 mesh, 18 mesh
Supply type :
Mass stock
Surface treatment :
Powder coated,PVC coated
Width :
1.2m,1.5m or customized
Length :
30 m or customized
Description

Stainless Steel Security Screen /stainless Steel Wire Mesh For Window Door 0.8mm X 11 Mesh Powder Coated

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

Material
SS wire 201,304,316,316L
Wire diameter
0.018-2.03mm
Woven type
plain weave,twill weave,dutch weave,reversed dutch weave,crimped weave
Mesh counts
plain weave wire mesh can be woven up to 400 mesh
twill weave wire mesh can be woven from 30 to 635 mesh

Stainless Steel Security Screen Doors

Security screen mesh is our main product ,Our Stainless Steel Security door is made of high tensile AISI316 stainless steel wire, tolerance(+/-0.01mm), tensile strength is more than 900Mpa (900N).

The holes are square and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.


Characteristic:
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty

Specifications

Material Mesh Size Hole Size Sheet Size
General tensile 316 Marine grade stainless steel wire 8mesh×1.2mm 2.0mm

Width×Length

750mm×2000mm/2400mm/3000mm3500mm 900mm×2000mm/2400mm/3000mm/3500mm 1000mm×2000mm/2400mm/3000mm/3500mm 1200mm×2000mm/2400mm/3000mm/3500mm 1500mm×2000mm/2400mm/3000mm/3500mm

9mesh×1.0mm 1.8mm
10mesh×0.8mm 1.8mm
10mesh×0.9mm 1.6mm
10mesh×1.0mm 1.5mm
11mesh×0.8mm 1.5mm
11mesh×0.9mm 1.4mm
12mesh×0.7mm 1.4mm
12mesh×0.8mm 1.3mm
12mesh×0.9mm 1.2mm
14mesh×0.5mm 1.3mm
14mesh×0.55mm 1.2mm
14mesh×0.6mm 1.2mm
18mesh×0.32mm 1.0mm
High tensile 316 Marine grade stainless steel wire 8mesh×1.2mm 2.0mm

Width×Length

750mm×2000mm/2400mm/3000mm3500mm 900mm×2000mm/2400mm/3000mm/3500mm 1000mm×2000mm/2400mm/3000mm/3500mm 1200mm×2000mm/2400mm/3000mm/3500mm 1500mm×2000mm/2400mm/3000mm/3500mm

8mesh×1.3mm 1.9mm
9mesh×0.9mm 1.9mm
9mesh×1.0mm 1.8mm
10mesh×0.9mm 1.6mm
10mesh×1.0mm 1.5mm
11mesh×0.8mm 1.5mm
11mesh×0.9mm 1.4mm

1.Sheet Size:Can be customized

2.Coating Color:Black/Gray/White

3.Packing:50 pcs per polywood box

Features
Excellent flact surface
High tension,Equal aperture and dia
Corrosion resistance,easy to install
10 years not to corrode,face or bubble
Black color filter 60% of UV rays


Stainless Steel Security Screen Feature
1. Prevent from mosquitoes, flies and other insects. 2. Resist the thieves and intruders.
3.Fire proof and knife proof. 4. Equal aperture and wire diameter
5. High tensile. 6. Long life and durable.
7. Easy to clean and install 8. Resistance for corrosion and rust.
9. Clear from inside and vague from outside. 10. Excellent for fresh air flowing.
11. Adjust for harsh environments such as hurricane or storm.

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

304 Stainless Steel Security Screen for Super Hardness

304 stainless steel security screen is also called bulletproof security screen or crime safe mesh screen. Its 304 stainless steel material offers excellent fire prevention, high temperature resistance, high strength and good toughness properties that can withstand damage from knife, ax, pliers and scissors. At the same time its powder coated layer further strengthens rust resistance and anti-corrosion properties which make the security screen have a long service time. And if you have a baby, it can also prevent babies and children from climbing or accidentally falling, this aids to ensure the safety of children. Furthermore, 304 stainless steel security screen keeps houses bright, natural flow of fresh air 24 hours a day and reduces unnecessary air conditioning running, it not only save energy but also reduce air conditioning that brings sub-health, this gives you and your family a healthy body and mind. 304 stainless steel security screen is suitable for houses, office buildings, suburbs, banks, airports, resorts, hospitals, schools, nursing homes and other living areas.

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

316 Stainless Steel Security Screen - Anti-corrosion

316 stainless steel security screen is a kind of plain woven security screen with powder coated layer. Its material 316 stainless steel wire has more than 900 MPa high tensile strength that can effectively prevent babies or children from climbing or accidentally falling. Besides the higher nickel content, 316 stainless steel wire also contains molybdenum, so compared with 304 stainless steel wire, its anti-corrosion, fire prevention and high temperature resistance properties are better. And 316 stainless steel security screen is also called 316 marine grade stainless steel mesh, it meets Australian standards and through neutral salt spray test, so it is suitable for beachfront cities and swimming pools. 316 stainless steel security screen is used for houses, banks, office buildings, chemical industry district and sea-view villas.

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

316L Stainless Steel Security Screen - Anti-rust and Heat Resistance

316L stainless steel security screen is a kind of new high-end home security screen. 316L stainless steel security screen and 316 stainless steel security screen are very similar, the biggest difference between them is the carbon content. The carbon content of 316 stainless steel wire is 0.08 while 316L stainless steel wire is only 0.03, so this low carbon content feature makes 316L stainless steel security screen offer the best corrosion resistance property, especially its pitting corrosion resistance is perfect. At the same time it offers excellent high temperature strength, fire prevention and heat resistance, thus it can be used for chemical industrial district and marine environment. And 316L stainless steel security screen is also suitable for houses, banks, suburbs, swimming pools, beachfront cities and office buildings.

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

Mass stock

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

Application

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

About us

201 304 304L 316 316L Stainless Steel Woven Wire Mesh security screen/Insect proof security screen

Anping tenglu metal wire mesh co.,ltd,is a manufacture and exporter of stainless steel wire mesh product.

We are located in wire mesh industrial base Anping city,Hebei province in China.

Our product range is as below,

Stainless steel woven wire mesh

Welded wire mesh

Crimped wire mesh

Hexagonal wire mesh

Knitted wire mesh

Wire mesh filter

Window screen

It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.

In order to make an offer,please provide us below wire mesh specification information.

Material

Wire diameter

Mesh size

Wire mesh length

Wire mesh width

If it is possible,please also provide us weight per roll that you required.
