Stainless Steel Security Screen /stainless Steel Wire Mesh For Window Door 0.8mm X 11 Mesh Powder Coated
Material | SS wire 201,304,316,316L | ||
Wire diameter | 0.018-2.03mm | ||
Woven type | plain weave,twill weave,dutch weave,reversed dutch weave,crimped weave | ||
Mesh counts | plain weave wire mesh can be woven up to 400 mesh twill weave wire mesh can be woven from 30 to 635 mesh |
Security screen mesh is our main product ,Our Stainless Steel Security door is made of high tensile AISI316 stainless steel wire, tolerance(+/-0.01mm), tensile strength is more than 900Mpa (900N).
The holes are square and the wires are very strong (not sliding), screen surface is flattened after we weave the wires to mesh screen.
Characteristic:
Private live: No one can peep at room
Beautiful: Gorgeous surface
Durable: More than 10years Warranty
Material | Mesh Size | Hole Size | Sheet Size |
General tensile 316 Marine grade stainless steel wire | 8mesh×1.2mm | 2.0mm | Width×Length 750mm×2000mm/2400mm/3000mm3500mm 900mm×2000mm/2400mm/3000mm/3500mm 1000mm×2000mm/2400mm/3000mm/3500mm 1200mm×2000mm/2400mm/3000mm/3500mm 1500mm×2000mm/2400mm/3000mm/3500mm |
9mesh×1.0mm | 1.8mm | ||
10mesh×0.8mm | 1.8mm | ||
10mesh×0.9mm | 1.6mm | ||
10mesh×1.0mm | 1.5mm | ||
11mesh×0.8mm | 1.5mm | ||
11mesh×0.9mm | 1.4mm | ||
12mesh×0.7mm | 1.4mm | ||
12mesh×0.8mm | 1.3mm | ||
12mesh×0.9mm | 1.2mm | ||
14mesh×0.5mm | 1.3mm | ||
14mesh×0.55mm | 1.2mm | ||
14mesh×0.6mm | 1.2mm | ||
18mesh×0.32mm | 1.0mm | ||
High tensile 316 Marine grade stainless steel wire | 8mesh×1.2mm | 2.0mm | Width×Length 750mm×2000mm/2400mm/3000mm3500mm 900mm×2000mm/2400mm/3000mm/3500mm 1000mm×2000mm/2400mm/3000mm/3500mm 1200mm×2000mm/2400mm/3000mm/3500mm 1500mm×2000mm/2400mm/3000mm/3500mm |
8mesh×1.3mm | 1.9mm | ||
9mesh×0.9mm | 1.9mm | ||
9mesh×1.0mm | 1.8mm | ||
10mesh×0.9mm | 1.6mm | ||
10mesh×1.0mm | 1.5mm | ||
11mesh×0.8mm | 1.5mm | ||
11mesh×0.9mm | 1.4mm | ||
1.Sheet Size:Can be customized 2.Coating Color:Black/Gray/White 3.Packing:50 pcs per polywood box |
Features
Excellent flact surface
High tension,Equal aperture and dia
Corrosion resistance,easy to install
10 years not to corrode,face or bubble
Black color filter 60% of UV rays
Stainless Steel Security Screen Feature | |
1. Prevent from mosquitoes, flies and other insects. | 2. Resist the thieves and intruders. |
3.Fire proof and knife proof. | 4. Equal aperture and wire diameter |
5. High tensile. | 6. Long life and durable. |
7. Easy to clean and install | 8. Resistance for corrosion and rust. |
9. Clear from inside and vague from outside. | 10. Excellent for fresh air flowing. |
11. Adjust for harsh environments such as hurricane or storm. |
304 Stainless Steel Security Screen for Super Hardness
304 stainless steel security screen is also called bulletproof security screen or crime safe mesh screen. Its 304 stainless steel material offers excellent fire prevention, high temperature resistance, high strength and good toughness properties that can withstand damage from knife, ax, pliers and scissors. At the same time its powder coated layer further strengthens rust resistance and anti-corrosion properties which make the security screen have a long service time. And if you have a baby, it can also prevent babies and children from climbing or accidentally falling, this aids to ensure the safety of children. Furthermore, 304 stainless steel security screen keeps houses bright, natural flow of fresh air 24 hours a day and reduces unnecessary air conditioning running, it not only save energy but also reduce air conditioning that brings sub-health, this gives you and your family a healthy body and mind. 304 stainless steel security screen is suitable for houses, office buildings, suburbs, banks, airports, resorts, hospitals, schools, nursing homes and other living areas.
316 Stainless Steel Security Screen - Anti-corrosion
316 stainless steel security screen is a kind of plain woven security screen with powder coated layer. Its material 316 stainless steel wire has more than 900 MPa high tensile strength that can effectively prevent babies or children from climbing or accidentally falling. Besides the higher nickel content, 316 stainless steel wire also contains molybdenum, so compared with 304 stainless steel wire, its anti-corrosion, fire prevention and high temperature resistance properties are better. And 316 stainless steel security screen is also called 316 marine grade stainless steel mesh, it meets Australian standards and through neutral salt spray test, so it is suitable for beachfront cities and swimming pools. 316 stainless steel security screen is used for houses, banks, office buildings, chemical industry district and sea-view villas.
316L Stainless Steel Security Screen - Anti-rust and Heat Resistance
316L stainless steel security screen is a kind of new high-end home security screen. 316L stainless steel security screen and 316 stainless steel security screen are very similar, the biggest difference between them is the carbon content. The carbon content of 316 stainless steel wire is 0.08 while 316L stainless steel wire is only 0.03, so this low carbon content feature makes 316L stainless steel security screen offer the best corrosion resistance property, especially its pitting corrosion resistance is perfect. At the same time it offers excellent high temperature strength, fire prevention and heat resistance, thus it can be used for chemical industrial district and marine environment. And 316L stainless steel security screen is also suitable for houses, banks, suburbs, swimming pools, beachfront cities and office buildings.
Mass stock
Application
About us
Anping tenglu metal wire mesh co.,ltd,is a manufacture and exporter of stainless steel wire mesh product.
We are located in wire mesh industrial base Anping city,Hebei province in China.
Our product range is as below,
Stainless steel woven wire mesh
Welded wire mesh
Crimped wire mesh
Hexagonal wire mesh
Knitted wire mesh
Wire mesh filter
Window screen
It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.
In order to make an offer,please provide us below wire mesh specification information.
Material
Wire diameter
Mesh size
Wire mesh length
Wire mesh width
If it is possible,please also provide us weight per roll that you required.
