316 stainless steel wire mesh/woven wire mesh,Flexible Wire Mesh Netting SS Plain Woven Wire Mesh

• Material	SS wire 201, 304, 304L, 316, 316L, 431, 321 347 etc.
  Wire diameter	0.018-2.03mm
  Woven style	plain weave,twill weave,dutch weave,reversed dutch weave,crimped weave
  Mesh counts	Plain weave wire mesh can be woven up to 400 mesh. Twill weave wire mesh can be woven from 30 to 635 mesh.
  Packaging Details	inner kraft, outside plastic cloth, put into wooden pallet or case
  Application	Plain/Twill weave stainless steel wire mesh is used for screening and filtering in acid or alkali environment. As mud mesh in oil industry, chemical packing nets, chemical fiber industry as screen mesh, electroplating industry as pickling nets.

  Feature of the stainless steel wire mesh

  · Corrosion resistance.

  · Anti-acid and alkali resistance.

  · Anti-high temperture.

  · Good filter performance.

  · Long using life

  Application of the stainelss steel wire mesh

  · In acid, alkali environment conditions sieving and filtering.

  · Petroleum industry as mud mesh,.

  · Chemical fiber industry as screen mesh.

  · Plating industry as acid cleaning mesh.

  Stainless Steel Square Woven Mesh
  Weave Type	Mesh Count	Wire Dia. (Inch)	Width of Opening (Inch)	Open Area (%)	Weigh Per 100 sq' based on 304ss	Opening (Micron)
  Plain	2 x 2	.063	.4370	76.4	51.7	11119
  Plain	3 x 3	.0540	.2790	70.1	57.3	7099
  Plain	4 x 4	.0470	.2030	65.9	58.2	5165
  Plain	5 x 5	.0410	.1590	63.2	55.4	4046
  Plain	6 x 6	.0350	.1320	62.7	48.6	3359
  Plain	6 x 6	.0320	.1350	65.6	20.7	3435
  Plain	7 x 7	.0320	.1110	60.4	47.5	2824
  Plain	7 x 7	.0280	.1150	64.8	36.2	2926
  Plain	8 X 8	.0250	.1000	64.0	32.9	2545
  Plain	9 X 9	.0250	.0860	59.9	37.3	2188
  Plain	9 X 9	.0230	.0880	62.7	31.4	2239
  Plain	10 x 10	.0250	.0750	56.3	41.6	1908
  Plain	11 x 11	.0230	.0680	56.0	38.8	1730
  Plain	11 x 11	.0200	.0710	61.0	29.1	1807
  Plain	12 x 12	.0200	.0630	57.2	31.9	1603
  Plain	14 x 14	.0200	.0510	51.0	37.6	1298
  Plain	16 x 16	.0180	.0445	50.7	34.8	1132
  Plain	18 x 18	.0170	.0386	48.3	35.1	982
  Plain	20 x 20	.0200	.0300	36.0	55.8	763
  Plain	30 x 30	.0120	.0213	40.8	29.7	542
  Plain	30 x 30	.0095	.0238	51.0	18.2	606
  Plain	40 x 40	.0100	.0150	36.0	27.9	382
  Plain	50 x 50	.0055	.0145	52.6	10.1	369
  Plain	60 x 60	.0060	.0107	41.2	14.8	272
  Plain	60 x 60	.0045	.0122	53.3	8.1	310
  Plain	80 x 80	.0055	.0070	31.4	17.1	178
  Plain	100 x 100	.0045	.0055	30.3	14.3	140
  Plain	100 x 100	.0040	.0060	36.0	11.1	153
  Plain	120 x 120	.0026	.0058	47.3	5	148
  Plain	150 x 150	.0026	.0041	37.4	7.2	104
  Plain	165 x 165	.0019	.0042	47.1	4.2	107
  Plain	180 x 180	.0023	.0033	34.7	7.5	84
  Plain	200 x 200	.0019	.0030	60.6	3.6	77
  Plain	230 x 230	.0014	.0029	46.0	3.4	74
  Plain	250 x 250	.0016	.0024	36.0	4.3	61
  Twill	270 x 270	.0016	.0021	32.2	4.8	53
  Plain	300 x 300	.0012	.0018	29.7	3	46
  Twill	325 x 325	.0014	.0017	30.0	4.3	43
  Twill	400 x 400	.0011	.0014	31.4	3.4	36
  Twill	500 x 500	.0010	.0010	25.0	*	25
  Twill	635 x 635	.0008	.0008	25.0	*	20

Available woven type for choose of stainless steel wire mesh

Anping tenglu metal wire mesh co.,ltd,is a manufacture and exporter of stainless steel wire mesh product.
We are located in wire mesh industrial base Anping city,Hebei province in China.
Our product range is as below,
Stainless steel woven wire mesh
Welded wire mesh
Crimped wire mesh
Hexagonal wire mesh
Knitted wire mesh
Wire mesh filter
Window screen

It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.

In order to make an offer,please provide us below wire mesh specification information.
Material
Wire diameter
Mesh size
Wire mesh length
Wire mesh width
If it is possible,please also provide us weight per roll that you required.
