1×1 Stainless Steel Welded Mesh Sheets Low Carbon Iron Wire 300~2500mm Width
1×1 Stainless Steel Welded Mesh Sheets Low Carbon Iron Wire 300~2500mm Width
1×1 Stainless Steel Welded Mesh Sheets Low Carbon Iron Wire 300~2500mm Width
1×1 Stainless Steel Welded Mesh Sheets Low Carbon Iron Wire 300~2500mm Width
Specifications
Place of Origin :
Hengshui,China
MOQ :
20 Rolls
Price :
According to order quantity determined
Supply Ability :
10000 rolls per month
Packaging Details :
Waterproof Paper & Shrink Film, Plastic Film
Material :
Low-Carbon Iron Wire,Galvanized Steel Wire,Galvanized Iron
Type :
Reinforce mesh
Application :
Construction Wire Mesh,Poultry Cages,Fence Mesh,Gabions
Width :
300mm~2500mm
Length :
10m,15m,25m,30m,50m,100m,
Wire diameter :
1/4, 1/2,3/8
Description

Stainless steel wire mesh,1×1 Stainless steel welded wire mesh, welded wire screen mesh,stainless steel welded screen

Welded wire mesh Materials: The high-quality low-carbon steel, stainless steel wire.

Use: widely used in industry, agriculture, construction, transportation, mining, playgrounds, lawns, farming and other sectors of the fence, decorative, mechanical protection.

Weaving: Including galvanizing before or after welding. It is divided to hot dipped, electrical galvanizing, pvc coating, specilal electric welded wire mesh.
Property:It has the characteristics of corrosion-resisting and oxidation-resisting.
Uses:It is used in Industry, agriculture, building. transportation, mine, court, lawn, breeding, for fence, decoration, machine protection etc

Specification List of Welded Wire Mesh
Opening Wire Diameter
inch mm mm
1/4" x 1/4" 6.4mm x 6.4mm 22,23,24
3/8" x 3/8" 10.6mm x 10.6mm 19,20,21,22
1/2" x 1/2" 12.7mm x 12.7mm 16,17,18,19,20,21,22,23
5/8" x 5/8" 16mm x 16mm 18,19,20,21,
3/4" x 3/4" 19.1mm x 19.1mm 16,17,18,19,20,21
1" x 1/2" 25.4mm x 12.7mm 16,17,18,19,20,21
1" x 1" 25.4mmX25.4mm 16,17,18,19,20,21
1-1/2" x 1-1/2" 38mm x 38mm 14,15,16,17,18,19
1" x 2" 25.4mm x 50.8mm 14,15,16
2" x 2" 50.8mm x 50.8mm 12,13,14,15,16
2" x 3" 50mmx70mm 2.0mm,2.5mm,1.65mm
3" x 3" 75mmx75mm 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2" x 4" 50mmx100mm 2.11mm,2.5mm
4" x 4" 100mmx100mm 2.0mm,2.5mm

GALVANIZED WELDED MESH
Mesh Size Wire Diameter Width & Length
In Inch In MM In BWG In MM

Width: 0.5m-2.0m

Length: 25m, 30m

Other sizes can be made as request
1/2” 12.7mm BWG16 - BWG28 1.65mm - 0.356mm
3/4” 19.05mm BWG16 - BWG27 1.65mm - 0.406mm
1” 25.4mm BWG14 - BWG20 2.1mm - 0.88mm
1” x 2” 25.4 x 50.8mm BWG14 - BWG19 2.1mm - 1.06mm
2” 50.8mm BWG12 - BWG18 2.76mm - 1.24mm
2” x 4” 50.8 x 101.6mm BWG10 - BWG18 3.4mm - 1.24mm
1/4” 6.35mm BWG19 - BWG24 1.06mm - 0.56mm
3/8” 9.52mm BWG18 - BWG27 1.24mm - 0.406mm
5/8” 16mm BWG18 - BWG27 1.24mm - 0.406mm
New mesh sizes: 1” x 1/2”, 30 x 30mm, 60 x 60mm

1×1 Stainless Steel Welded Mesh Sheets Low Carbon Iron Wire 300~2500mm Width

1×1 Stainless Steel Welded Mesh Sheets Low Carbon Iron Wire 300~2500mm Width

Usage

1×1 Stainless Steel Welded Mesh Sheets Low Carbon Iron Wire 300~2500mm Width

Welded wire mesh treatment:
Galvanized welded wire mesh is made in accordance to English Standard normally in regard to the production and zinc coating. The finished welded mesh offer flat and uniform surface, firm structure, good integrity. It offers the most excellent anti-corrosion resistance among all the steel wire mesh products, it is also the most versatile wire mesh due to its wide application in different fields.

Welded wire mesh features:
It is very popular in breeding industry: Can be made into various animal cages or fences for breeding with its excellent anti-corrosion property. The galvanized offers a kind of decorative outlook with its flat surface. With first-class anti-corrosion property, it is widely used in mine sieving industries as sieving screen. The low carbon steel wire for making of welded wire mesh offers flexibility that can be made in many further.

About our company

Anping tenglu metal wire mesh co.,ltd.

1×1 Stainless Steel Welded Mesh Sheets Low Carbon Iron Wire 300~2500mm Width

Our product range

Stainless steel woven wire mesh

Welded wire mesh

Expanded wire mesh

Crimped wire mesh

Hexagonal wire mesh

Knitted wire mesh

In order to make an offer,please consider and advise below wire mesh specification

Material

Mesh size

Wire diameter

Wire mesh length per roll

Wire mesh width per roll.

Thank you.
