Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel
Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel
Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel
Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel
Specifications
Place of Origin :
Hengshui,China
MOQ :
20 Square meter
Price :
According to order quantity negotiated
Supply Ability :
10000 Square Meter/Square Meters per Day
Packaging Details :
In waterproof paper in rolls or in pallet. Custom packing available at request
Material :
Galvanized, Painting, Aluminum
Application :
Protecting Mesh
Color :
customized
Sheet Thickness :
0.5-8mm
Hole shape :
Diamond
Description
Stainless Steel Expanded Metal Wire Mesh/Diamond Wire Mesh,Bright Surface Stainless Steel Expanded Metal Wire Mesh

EXPANDED METAL MESH, EXPANDED METAL SHEET

Aluminum expanded metal mesh:
Material: aluminum sheet
Aperture:5x10cm
Thickness:4.0mm
Strand width:4.0mm
Expanded metal mesh
Long way of mesh(mm):12.5-200
Short way of mesh (mm):5-80
Thickness(mm): 0.5-8
Length(mm):600-4000 width (mm):600-2000
Variety: small, medium and heavy expanded metal mesh. Expanded aluminum mesh, expanded platinum filtration mesh, expanded brass mesh, expanded copper mesh, expanded stainless steel mesh, expanded nickel mesh. Opening in the shape of diamond, hexagonal or special shape.
Uses: used with concrete in buildings and construction, maintenance of equipments, making of arts and crafts, covering screen for first class sound case. Also fencing for super highway, studio, highway. Heavy expanded metal can be used as step mesh of oil tanks, working platform, corridor and walking road for heavy model equipment, boiler, petroleum and mine well, automobile vehicles, big ships. Also serve as reinforcing bar in construction, railway and bridges.
Specification:

Sheet thickness(mm) Opening in width(mm) Opening in length(mm) strand Roll width(m) Roll length(m) Weight(kg/m2)
0.5 2.5 4.5 0.5 0.5 1 1.8
0.5 10 25 0.5 0.6 2 0.73
0.6 10 25 1 0.6 2 1
0.8 10 25 1 0.6 2 1.25
1 10 25 1.1 0.6 2 1.77
1 15 40 1.5 2 4 1.85
1.2 10 25 1.1 2 4 2.21
1.2 15 40 1.5 2 4 2.3
1.5 15 40 1.5 1.8 4 2.77
1.5 23 60 2.6 2 3.6 2.77
2 18 50 2.1 2 4 3.69
2 22 60 2.6 2 4 3.69
3 40 80 3.8 2 4 5.00
4 50 100 4 2 2 11.15
4.5 50 100 5 2 2.7 11.15
5 50 100 5 1.4 2.6 12.39
6 50 100 6 2 2.5 17.35
8 50 100 8 2 2.1 28.26

Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel

LWD: diamond shaped hole, long way of the diagonal length

SWD: diamond shaped hole, short way of the diagonal length

Strand width:Steel plate mesh diamond hole edge Terrier is making a wide wire stem length of the metal plate.

plate thickness: 0.4-8mm


Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel

Customize Design Anti-Corrosive Expanded Metal Mesh

Features:

Weight is light enough for outer wall hanging

Anti-corrosive

Rainstorm or isolation won`t hurt

Visibility and colorful

Used as decorative mesh for building outer wall ,radiator cover mesh

Easily fabricated, finished, installed and formed

Application

expanded metal used with concrete in buildings and construction, maintenance of equipment,

making of arts and crafts, covering screen for first class sound case. Also fencing for super highway,

studio,highway.

Expanded wire mesh application
Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel
Our other wire mesh series

Anping tenglu metal wire mesh co.,ltd,is a manufacture and exporter of stainless steel wire mesh product.

We are located in wire mesh industrial base Anping city,Hebei province in China.It have been 15 years that we manufacture and exported wire mesh product,our main product is stainless steel woven wire mesh,we keep the good manufacture technique of wire mesh product,to client orders,we will finish it within our shortest production time while keep mesh quality.

Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel
Product series
Stainless steel woven wire mesh
welded wire mesh
knitted wire mesh
expanded wire mesh
hexagonal wire mesh
Bright Surface Expanded Metal Screen Mesh Diamond Hole Shape Stainless Steel
