Oil Demister Knitted Stainless Steel Wire Mesh/Knitted Wire Mesh,stainless steel knitted wire mesh for demister pad gas

1. Wire Mesh Compressed Gasket Detailed Decription

Introduction to Knitted Wire Mesh

Knit ted wire mesh is a metal wire or plastic strand knitted into a mesh structure in very much the same way as stockings or sweaters. It is in no way related to the woven metal materials familiar to us as fly screens.

Mesh Diameters

Mesh is normally knit from wires ranging in diameter from .0035” to .0200”. In special applications, Metal Textiles has knit wires ranging in diameter from .0005” to .0350”. These wires can be round or flat such as those used in Metal Textiles copper gauze for cleaning and in air-filtration applications where large surface areas of wire are needed. A round wire when flattened has approximately twice as much surface area.

In filtration applications, wire diameter is perhaps the most important design variable. It directly affects flow, dirt holding capacity, pressure drop and cost. In general, larger diameter wire allows for higher flow but provides lower dirt holding capacity. Also, larger diameter wire is less expensive. Therefore, a balance must be struck between using a higher density filter of higher cost fine wire or a lesser density filter using lower cost heavy wire.

Density

Density refers to the mass of material per unit volume. It is related to the density of the original mesh and the amount of forming pressure used to compress the mesh into its final form. Determining the required mesh density to produce the specified final product density is a critical step in the design process. Proper density ensures optimal performance of the sealing, gasketing, filtration, heat transfer and separation applications.

Metal Textiles engineers are expert at determining proper density for specific requirements.

Anping tenglu metal wire mesh co.,ltd,is a manufacture and exporter of stainless steel wire mesh product.

We are located in wire mesh industrial base Anping city,Hebei province in China.

Our product range is as below,

Stainless steel woven wire mesh

Welded wire mesh

Crimped wire mesh

Hexagonal wire mesh

Knitted wire mesh

Wire mesh filter

Window screen

It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.

In order to make an offer,please provide us below wire mesh specification information.

Material

Wire diameter

Mesh size

Wire mesh length

Wire mesh width

If it is possible,please also provide us weight per roll that you required.
