Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable
Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable
Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable
Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable
Specifications
Place of Origin :
Hengshui,China
MOQ :
20 Square meter
Price :
According to order quantity negotiated
Supply Ability :
10000 Square Meter/Square Meters per Day
Packaging Details :
In waterproof paper in rolls or in pallet. Custom packing available at request
Material :
Galvanized, Painting, Aluminum
Type :
Expanded Mesh
Application :
Protecting Mesh
Color :
customized
Thickness :
0.5mm-15mm
Hole shape :
Diamond
Description
Metal Expanded wire mesh stretch expanded metal mesh,diamond shape wire mesh raised expanded metal

Expanded metal is an intermediate raw material that allows light and air to flow freely through it and that has more rigidity than the sheet from which it was produced.

Steel screen is a kind of metal screen screen industry.Also known as metal plate net, diamond net, iron plate net, metal expansion net, heavy steel plate net, pedal net, punching plate 'aluminum plate net, stainless steel plate net, granary net, antenna net, filter element net, sound net and so on.

Material plain steel sheet, galvanized steel sheet, stainless steel sheet, copper sheet, brass sheet, aluminum sheet
Thichness
0.2-3mm
Length 1m-20m
Hole Dia 0.8mm-10mm
Pitch 2-16mm
Perforated area percent from 7% to 83%
Hole forms Diamond,round, square, triangle, hexagon, cross ect
SurfaceTreatment Electric galvanized, Hot dipped galvanized, PVC coated, oxidation treatment etc

m.

Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable

EXPENDED FLATTENED MESH
LWD(mm) SWD(mm) Strand Width Strand Gauge %Free Area Approx.Kg/m2
6.05 3.38 0.5 0.8 50 2.1
10.24 5.84 0.5 0.8 75 1.2
10.24 5.84 0.9 1.2 65 3.2
3.80 2.10 0.8 0.6 46 2.1
14.20 4.80 1.8 0.9 52 3.3
24.40 7.10 2.4 1.1 57 3.4
23.20 5.80 3.2 1.5 43 6.3
32.70 10.90 3.2 1.5 59 4
33.50 12.40 2.3 1.1 71 2.5
42.90 14.20 4.6 2.7 58 8.6
39.10 18.30 4.7 2.7 60 7.6
43.20 17.08 3.2 1.5 69 3.2
69.80 37.10 5.5 2.1 75 3.9

Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable

Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable
Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable

Customize Design Anti-Corrosive Expanded Metal Mesh

Features:

Weight is light enough for outer wall hanging

Anti-corrosive

Rainstorm or isolation won`t hurt

Visibility and colorful

Used as decorative mesh for building outer wall ,radiator cover mesh

Easily fabricated, finished, installed and formed

Application

expanded metal used with concrete in buildings and construction, maintenance of equipment,

making of arts and crafts, covering screen for first class sound case. Also fencing for super highway,

studio,highway.

Expanded wire mesh application
Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable
Our other wire mesh series

Anping tenglu metal wire mesh co.,ltd,is a manufacture and exporter of stainless steel wire mesh product.

We are located in wire mesh industrial base Anping city,Hebei province in China.It have been 15 years that we manufacture and exported wire mesh product,our main product is stainless steel woven wire mesh,we keep the good manufacture technique of wire mesh product,to client orders,we will finish it within our shortest production time while keep mesh quality.

Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable
Product series
Stainless steel woven wire mesh
welded wire mesh
knitted wire mesh
expanded wire mesh
hexagonal wire mesh
Metal Raised Expanded Wire Mesh Stretch Diamond Shape 0.2-3mm Thichness Durable
