Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price
Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price
Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price
Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price
Specifications
Place of Origin :
Hengshui,China
MOQ :
2 Rolls
Price :
50-400 us dollar/roll
Supply Ability :
50000 Square Meter/Square Meters per Day
Delivery Time :
If we have in stock,10 days.For the product need to produce,according to order quantity,need to calculate
Packaging Details :
packed with water-proof paper, woven bag and also can be made as per client's requirement.
Material :
Stainless steel wire
Hope shape :
Square or rectangular
Application :
Decorative/Printing,filter,spaceflight,oil,chemical industry
Wire gauge :
0.025--2.0mm
Roll width :
0.914m, 1m, 1.2m etc
Roll length :
30m or as required
Mesh :
1, 5, 25, 60, 70, 80, 100, 200, 300, 400micron
Weave stype :
Plain,twill,dutch
Keyword 1 :
Stainless steel wire mesh
Keyword 2 :
Stainless steel filter mesh
Description

Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price

Stainless steel wire is selected for their wear-resisting, heat-resisting, acid-resisting and corrosion resisting characteristics. Many different grades of stainless are used in wire cloth. T304 is the most common, but other are used in specific applications to take advantage of each grade’s unique properties. The wire mesh made of stainless steel is extensively used in mining, chemical industry, food industry and pharmaceutical industry.

Material:
Stainless Steel Wire 201/304/304L/316/316L/431/321
Mesh Count:
plain weave can be woven from 1- 400 mesh
twill weave can be woven from 2- 635 mesh
dutch wevae can be woven up to 500*3500 mesh
Wire Diameter:
0.05-1.8mm
Feature:
Due to high content of Ni and Cr, it is with good oxidation resistance, corrosion resistance, acid and alkali resistance, high temperature resistance.
Application:
Mainly used in petroleum, electronics, chemical industry, medicine, textile, food, machinery, building, nuclear, power, aerospace, filtering industry, etc.


part of detailed specification:

Specification List of Stainless Steel Wire Mesh
Mesh/InchWire Gauge(SWG)Aperture in mm
3mesh x 3mesh146.27
4mesh x 4mesh164.27
5mesh x 5mesh183.86
6mesh x 6mesh183.04
8mesh x 8mesh202.26
10mesh x 10mesh201.63
20mesh x 20mesh300.95
30mesh x 30mesh340.61
40mesh x 40mesh360.44
50mesh x 50mesh380.36
60mesh x 60mesh400.30
80mesh x 80mesh420.21
100mesh x 100mesh440.172
120mesh x 120mesh440.13
150mesh x 150mesh460.108
160mesh x 160mesh460.097
180mesh x 180mesh470.09
200mesh x 200mesh470.077
250mesh x 250mesh480.061
280mesh x 280mesh490.060
300mesh x 300mesh490.054
350mesh x 350mesh490.042
400mesh x 400mesh490.0385
500mesh x 500mesh500.0273
Roll width: 2'-8'
Chemical composition of stainless steel wire:
AISI
Grade		Chemical Composition(%)
C
Si
Mn
P
S
Ni
Cr
Mo
304
=0.08
=1.00
=2.00
=0.045
=0.030
8.00~10.50
18.00~20.00
-
304H
>0.08
=1.00
=2.00
=0.045
=0.030
8.00~10.50
18.00~20.00
-
304L
=0.030
=1.00
=2.00
=0.045
=0.030
9.00~13.50
18.00~20.00
-
316
=0.045
=1.00
=2.00
=0.045
=0.030
10.00~14.00
10.00~18.00
2.00~3.00
316L
=0.030
=1.00
=2.00
=0.045
=0.030
12.00~15.00
16.00~18.00
2.00~3.00
430
=0.12
=0.75
=1.00
=0.040
=0.030
=0.60
16.00~18.00
-
430A
=0.06
=0.50
=0.50
=0.030
=0.50
=0.25
14.00~17.00
-
Sizes of Stainless Steel Wire:
Wire Diameter(mm)Tolerance(mm)Max. Deviation Tolerance(mm)
0.020-0.049+0.002
-0.001		0.001
0.050-0.0740.0020.002
0.075-0.0890.0020.002
0.090-0.109+0.003
-0.002		0.002
0.110-0.1690.0030.003
0.170-0.1840.0040.004
0.185-0.1990.0040.004
0.200-0.2990.0050.005
0.300-0.3100.0060.006
0.320-0.4990.0060.006
We can supply other specifications according to the customer's requirement.
Special size and specification are available according to customers requirment.

Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price


Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price


About us

Anping tenglu metal wire mesh co.,ltd,is a manufacture and exporter of stainless steel wire mesh product.
We are located in wire mesh industrial base Anping city,Hebei province in China.
Our product range is as below,
Stainless steel woven wire mesh
Welded wire mesh
Crimped wire mesh
Hexagonal wire mesh
Knitted wire mesh
Wire mesh filter
Window screen
Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price

Packing of stainless steel woven wire mesh

Kinds Ultra Fine Stainless Steel Weave Mesh,300 mesh 316L ultra fine wire mesh stainless steel price
