Specifications
Place of Origin :
Hengshui,China
MOQ :
2 Rolls
Price :
50-400 us dollar/roll
Supply Ability :
50000 Square Meter/Square Meters per Day
Delivery Time :
If we have in stock,10 days.For the product need to produce,according to order quantity,need to calculate
Packaging Details :
packed with water-proof paper, woven bag and also can be made as per client's requirement.
Material :
Stainless steel wire
Hope shape :
Square or rectangular
Type :
Weave Wire Mesh
Wire gauge :
0.025--2.0mm
Roll width :
0.5m to 6m
Roll length :
1-30m or customized
Technique :
Woven
Packing :
Wooden Case
Description

5 200 500 Micro 304 316 Stainless Steel Woven Plain Twill Dutch Wire Mesh,high temperature stainless steel wire mesh

Stainless Steel Square Woven Wire Mesh

Mesh count: 2-600mesh/inch

Wire dia: 0.02mm-2.0mm

Material: 201 202 302 304 304L 316 316L 321 601, etc

Width: 0.5m-6m

Length: 100' or as customers' exact demand


Specification

1. Plain Weave: also called tabby weave, linen weave or taffeta weave, is the most basic type of weaves.

Stainless Steel Woven Wire Mesh(Plain Weave)
mesh/inch wire diameter(mm) aperture(mm) mesh/inch wire diameter(mm) aperture(mm)
2 mesh 1.80 10.90 60mesh 0.15 0.273
3 mesh 1.60 6.866 70mesh 0.14 0.223
4 mesh 1.20 5.15 80mesh 0.12 0.198
5 mesh 0.91 4.17 90mesh 0.11 0.172
6 mesh 0.80 3.433 100mesh 0.1 0.154
8 mesh 0.60 2.575 120mesh 0.08 0.132
10mesh 0.55 1.990 140mesh 0.07 0.111
12mesh 0.50 1.616 150mesh 0.065 0.104
14mesh 0.45 1.362 160mesh 0.065 0.094
16mesh 0.40 1.188 180mesh 0.053 0.088
18mesh 0.35 1.060 200mesh 0.053 0.074
20mesh 0.30 0.970 250mesh 0.04 0.061
26mesh 0.28 0.696 300mesh 0.035 0.049
30mesh 0.25 0.596 325mesh 0.03 0.048
40mesh 0.21 0.425 350mesh 0.03 0.042
50mesh 0.19 0.318 400mesh 0.25 0.0385

2. Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line.

Stainless Steel Woven Wire Mesh(Twil Weave)
mesh wire diameter(mm) aperture(mm) material(AISI)
250 mesh 0.040mm 0.063 304 or 316
300 mesh 0.040mm 0.044 304 or 316
325 mesh 0.035mm 0.043 304 or 316
350 mesh 0.030mm 0.042 304 or 316
400 mesh 0.030mm 0.033 304 or 316

3. Plain Dutch Weave: similar to plain weave, just the weft and warp wire have different wire diameter and different mesh size.

4. Twill Dutch Weave: similar with twill weave, just the weft and warp wire have different wire diameter and different mesh size.

5. Reversed Dutch Weave: difference from standard Dutch weave lies in the thicker warp wires and fewer weft wires.

5 200 500 Micro 304 316 Stainless Steel Woven Plain Twill Dutch Wire Mesh,high temperature stainless steel wire mesh

5 200 500 Micro 304 316 Stainless Steel Woven Plain Twill Dutch Wire Mesh,high temperature stainless steel wire mesh



Detail specification

Specification List of Stainless Steel Wire Mesh
Mesh/Inch Wire Gauge(SWG) Aperture in mm
3mesh x 3mesh 14 6.27
4mesh x 4mesh 16 4.27
5mesh x 5mesh 18 3.86
6mesh x 6mesh 18 3.04
8mesh x 8mesh 20 2.26
10mesh x 10mesh 20 1.63
20mesh x 20mesh 30 0.95
30mesh x 30mesh 34 0.61
40mesh x 40mesh 36 0.44
50mesh x 50mesh 38 0.36
60mesh x 60mesh 40 0.30
80mesh x 80mesh 42 0.21
100mesh x 100mesh 44 0.172
120mesh x 120mesh 44 0.13
150mesh x 150mesh 46 0.108
160mesh x 160mesh 46 0.097
180mesh x 180mesh 47 0.09
200mesh x 200mesh 47 0.077
250mesh x 250mesh 48 0.061
280mesh x 280mesh 49 0.060
300mesh x 300mesh 49 0.054
350mesh x 350mesh 49 0.042
400mesh x 400mesh 50 0.0385
Roll width: 2'-8'


About us

Anping tenglu metal wire mesh co.,ltd,is a manufacture and exporter of stainless steel wire mesh product.
We are located in wire mesh industrial base Anping city,Hebei province in China.
Our product range is as below,
Stainless steel woven wire mesh
Welded wire mesh
Crimped wire mesh
Hexagonal wire mesh
Knitted wire mesh
Wire mesh filter
Window screen
5 200 500 Micro 304 316 Stainless Steel Woven Plain Twill Dutch Wire Mesh,high temperature stainless steel wire mesh
