Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron
Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron
Specifications
Place of Origin :
Hengshui,China
MOQ :
1 roll
Price :
7-200 us dollar per square meter
Supply Ability :
3000 rolls per month
Packaging Details :
Inside waterproof paper,outside wooden carton
Product name :
Stainless Steel Wire Mesh
Wire grade :
302 304 304L 316 316L etc
Wire diameter :
Mesh 40 304/316 Stainless Steel Woven Screen
Technique :
Woven
Width :
0.5-6.5m
Length :
30m or customized
Feature :
Wear-Resisting,Heat-Resisting,Acid-Resisting
Usage industry :
Chemical Industry,Filtering,Sieving
Description

Ultra thin 1250 mesh 325 550 635 mesh 10 micron stainless steel filter wire mesh,Ultra Thin Fine Woven Wire Mesh

Products Ultra thin 1250 mesh 325 mesh 550 635 mesh 10 micron stainless steel filter wire mesh
Material sus 210 304 304l 316 316l 310s 904l 2205 410 430 2507 stainless steel wire.

Mest count

plain weave can be woven from 1- 400 mesh

twill weave can be woven from 2- 635 mesh

dutch wevae can be woven up to 500*3500 mesh
Hole shape square/round hole
Wire diameter 0.018-2.03mm
Stock size 1*30m/roll, 1.22*30m/roll, 1.5*30m/roll or customized.

Features:

Corrosion resistance.

Anti-acid and alkai

Anti-high temperature.

Good filter performance.

Long using life

Applicatiosn:

In acid, alkali environment conditions sieving and filtering.

Petroleum industry as mud mesh,.

Chemical fiber industry as screen mesh.

Plating industry as acid cleaning mesh.

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Material

Material:410(SUS410,S41000),430(SUS430,S43000)

Mesh Count:1-300

Plain weave:The most popular a kind of preparation method industrial production and civil life is widely used.

Twill weave :Mainly in the 150 mesh to 600 purpose of plain dutch twill fine stainless steel wire mesh for filtration weaving use.

Dutch weave :In this method the plain dutch twill fine stainless steel wire mesh for filtration weaving has good tensile strength,mainly used for liquid and slurry filter.

Application

Mainly used in industrial filtering, food industry filtering, sugar industry filtering etc

SUS410/430 magnetic stainless steel wire mesh

1.Plain Weave: also called tabby weave, linen weav or taffeta weave, is the most basic type of weaves. In plain weave, the warp and weft are aligned so they form a simple criss-cross pattern. Each weft thread crosses the warp threads by going over one, then under the next, and so on. The next weft thread goes under the warp threads that its neighbor went over, and vice versa.

2. Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A float is the portion of a yarn that crosses over two or more yarns from the opposite direction.

Processing products

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Concentrating on putting all the efforts into maintaining product standards. We have a full range of production equipment, advanced technology, scientific management and inspection systems so that we can meet the exact requirements of our customers for various of wire mesh products.

About us

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron

Stainless steel wire mesh packing method,

Ultra Thin Stainless Steel Filter Wire Mesh 1250 Mesh 325 550 635 Mesh 10 Micron
