Feed Through Terminal block without protect spring plate | Pitch: 8.20mm | Part No.PA7 Case PA66,UL94V-0
Feed Through Terminal block without protect spring plate | Pitch: 8.20mm | Part No.PA7 Case PA66,UL94V-0
Feed Through Terminal block without protect spring plate | Pitch: 8.20mm | Part No.PA7 Case PA66,UL94V-0
Feed Through Terminal block without protect spring plate | Pitch: 8.20mm | Part No.PA7 Case PA66,UL94V-0
Feed Through Terminal block without protect spring plate | Pitch: 8.20mm | Part No.PA7 Case PA66,UL94V-0
Feed Through Terminal block without protect spring plate | Pitch: 8.20mm | Part No.PA7 Case PA66,UL94V-0
Specifications
Brand Name :
starpai
Model Number :
PH8.2
Certification :
UL,Rohs
Place of Origin :
Shenzhen
MOQ :
1000pcs
Price :
USD0.1 per pole
Payment Terms :
15-25 days after 100% T/T payment
Supply Ability :
10000pcs / month
Delivery Time :
1-25 work days
Packaging Details :
Bag
Color :
white or by customers
Current rating :
24A
Voltage :
300V
Poles :
1-12 poles
Description

Feed Through Terminal block without protect spring plate | Pitch: 8.20mm | Part No.PA7 Case PA66,UL94V-0

Feed Through Terminal block without protect spring plate | Pitch: 8.20mm | Part No.PA7 Case PA66,UL94V-0

Detailed

Pitch

8.20mm

Color: white or can be offered by customered

Poles

02-12Pin

Material

Case PA66,UL94V-0

Brass hole Zinc base alloy,Ni plated

Screw M3,C1018 steel,Zinc plated

Electrical

Voltage 300 V

Current rating 12A

Electrical Withstanding AC2000V,1minute

Isolation resistance DC500V 500MΩ

Wire range 20-14 AWG

Max Torque 4.0kgf.cm

Mechanical

Operation temperature - 33℃～+105℃

Strip length 7-8mm
