Specifications
Brand Name :
Vagsure
Model Number :
VS-C2031
Certification :
CE
Place of Origin :
Zhejiang
MOQ :
5 Sets
Price :
128-188USD/Set
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500 Sets Per Month
Delivery Time :
7-10 Days
Packaging Details :
EPE Foam Inside+Grade A Waterproof Carton
Product name :
Sauna steam generator
Main material :
Galvanized sheet
Voltage :
220V/380V
Power :
9kw
Lights control :
Yes
Function :
Wet Steam,auto power off,Auto drain
Feature :
Computer control panel
Application :
Sauna Room
Description

9kw 220v or 380v electric steam sauna generator light time and temperature control

1. product description

The steam generator is made by Galvanized sheet, anti-corrosive and durable. It is controled by computer control panel, long distance signal transmission, the longest distance can be 50m, transfer data reliably. Control cables with waterproof, moisture-proof interface. Working time and room temperature will be displayed on the panel. You could set temperature to the range of 35-55 C(95-131 F), and working time to 30 minutes-8 hours.

The Economic steam generator features auto water, over-voltage and high temperature protection. Water protection avoid heating function works without water. Over-voltage protection can effectively prevent the occurrence of the case of the steam pipe is blocked explosion overpressure condition. High temperature protection makes sure the temperature won't be over high so as to hurt users. All features ensure the stable product performance.
The segment-heating and self-diagnose function make the heater energy-efficient and easy-operation. Fast heating function, power that is able to only about 2 minutes out of steam, greatly reducing the time to wait. Auto-drain function is important for protecting heating elements, so eletromagetic auto drain valve is installed on 12kw, 15kw. and 18kw,units, and for 4.5~9kw units, you could also choose the optional auto-drain valve to replace the standard manual drain valve.

2. Specification

Product name: Steam Sauna generature with computer control panel
Model No: VS-C2031
Material: Galvanized sheet
Color: Blue
Certification: CE, SGS
Technical Charact Ristics
Mode Power(KW) Voltage(V) Size(mm) Volume(M³)
HA-40 4 220/380 210*650*430 5
HA-606 86 9220/380 12210*650*430 6
HA-80 8 220/380 210*650*430 8
HA-90 9 220/380 210*650*430 9
HA-120 12 380 260*650*600 12
HA-150 15 380 260*650*600 15
HA-180 18 380 260*650*600 18
Standard Functions
Cleaning Manual cleaning
Big Drain Valve Drain water and water scale after cleaning
Auto water inlet Water get into the tank automatically
Auto draining (4.5-9kw)Drain out water automatically; (12-18kw)Drain out manually after steam shower
Auto flushing Flush water tank automatically, to reduce water scale
Auto power off Powered off automatically
Overheat protection with manual/Auto. overheat protector
Time Setting 30minutes-8hours
Temperature Setting 35-55℃ or 98-131 ℉
Standard Configurations
Touch screen control panel Waterproof. Installed outside of steam room
Chrome finished brass steam nozzle Durable, Good looking
Big diameter auto draining valve Drain out hard water and lime scale, extend service life
Temperature sensor Durable, Good looking

3. Advantages

1. Multiple options, meets diverse requirements

2. Reliable manufactory and rich export experience

3. Good after-sale service

4. Prompt delivery

5. Certificated by CE, SGS


4. More pictures

Galvanized Sheet Steam Sauna Equipment / 9kw Steam Generator Anti CorrosiveGalvanized Sheet Steam Sauna Equipment / 9kw Steam Generator Anti Corrosive

5. Application

Steam Generators can use for Family, Hotel, Sauna SPA center, Leisure Center and so on. With function of Relax, Refresh, Expulsion of Toxin, Cosmetology, Lose Weight, Beautifying and so on. According to how to choose, the power of the steam generator is equal to the CBM of the room, (eg: a 8m³ room should use a 8kw steam generator).
