Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing
Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing
Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing
Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing
Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing
Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing
Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing
Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing
Specifications
Brand Name :
FAMOUS
Model Number :
200-type
Certification :
CE, ISO etc
Place of Origin :
China
MOQ :
1
Price :
USD1000~USD1200 per ton
Payment Terms :
L/C, T/T, D/A, D/P, Western Union
Supply Ability :
10000 units per year
Delivery Time :
in 30days
Packaging Details :
seaworthy packings for container shipping
Material :
Q345B steel
Surface treatment :
Painted or hot dip.etc
Name :
prefabricated steel truss pedestrian bridge
Installation :
Lifted into place by hand without crane, easier construction.etc
Multi-use :
civil engineering construction projects and to provide temporary crossings for foot & vehicle traffic.
Carry capacity :
Resist strong wind and earthquake, bears heavy snow.etc
Type :
200-type
Color :
Grey
Description

Prefabricated Modular Steel Bailey Bridge Assembled by China Manufacturing Supplier

Description of Steel Bailey Bridge

Prefabricated Steel Bailey Bridges are normally built on site from a pre-engineered system of ready-to-assemble components. Utilizing standardized prefabricated components , Bailey bridges can be built to match a wide range of vehicular bridging applications. Because of their excellent versatility and overall value, thousands of Bailey bridges have been installed throughout the world.

Specification of Steel Bailey Bridge

Product Name Specification of Compact 100 &200 Bailey bridge
Width 3.7meter, 4M, 4.2M, 7.3meter, 7.56meter
Maximum span 64meter single span and 200meter multi span
Bridge deck Steel composit panel
Steel grade Q345B (equivalent to ASTM A572)
Loading capacity 20ton, 40ton truck etc, or HS20-44, HS25-44/Truck 20
Corrosion Original painted or Hot dip galvanized
Advantages Price effective and technical full analysis and supports

Our Steel Bailey Bridges have been shipped and erected world-wide and are designed to suit a range of applications and come in a variety of

types dependent upon your specific bridge requirements.

Scope of Various Bridges

Our services include the complete complete bridge design and construction as per Client's choice of bridge features, and the scope of

various bridges are as follows:

· Road Bridges

· Pedestrian Bridges

· Railway Bridges

· Steel Truss Bridge

· Beam Bridges

· Steel Bailey bridge

· Structural Steel Box Bridge

· Highway Bridges

· Composite Beam Bridge

· Cable-Stayed Bridge

· Floating Bridge etc.

Features


Fully galvanized for long life and minimum maintenance


3.048m module length


4.2m single lane


Proprietary steel decking systems to suit different loading requirements


Durbar finish or factory applied anti-skid surfacing


Full highway load carrying capability


Simple, cost effective foundations

Army Portable Steel Bailey Bridge Painted Or Hot Dip Surface Treat Earthquake Heavy Snow Bearing

Meanwhile various standards ranging from Europe EU Standard, America ASTM Standard, British BS Standard, Australia AS/NZS Standard structural steel construction are also available.

Warmly welcome all friends and clients from International market to visit us!
