Specifications
Brand Name :
US-EU Metal
Model Number :
USEU02
Certification :
IS09001
Place of Origin :
Zhejiang
MOQ :
18mts
Price :
USD1000-1500 PER TON
Payment Terms :
L/C, T/T
Supply Ability :
100000 ton per month
Delivery Time :
25 working days
Packaging Details :
container seaworthy packings or break bulk ship
Surface Treatment :
Hot Dip Galvanized Or Painted
Material :
Steel
Cost :
Reasonable
Warranty :
3 To 50 Years
Grade :
Q235 Q345 & Q355B Steel
Performance :
Safety, Convenient, Easy To Install Etc.
Size :
Customized Size
Application :
River, Farm, Highway, Railway, Emergency, Military
Description

Bailey Bridge is a type of portable, pre-fabricated, truss bridge. It was developed by the British during World War II to provide military access across rivers or other bodies of water. The name comes from its inventor, Donald Bailey, who designed and patented the structure in 1936.

Compact 200 Bailey bridges are developed on the base of compact 100 Bailey bridges providing wider roadway, greater rigidity, greater stability overall, greater fatigue life and more effective structures. With panel height increased to 2.134m, it is an excellent choice for load designs of HS-15, HS-20, HS-25, HL-93 and more.

Specifications:

Single lane STD Carriageway Net Width: 4.2m Single span: 18m-67m
Double lane STD Carriageway Net Width:7.35m Single span: 18m-67m
Bridge deck Anti-slip steel decking floor,checkered steel plate etc
Steel grade Q345B/Q355 (equivalent to ASTM A572) or custom required
Loading capacity 20ton, 40ton truck etc, or HS20-44, HS25-44/Truck 20/HL-93

Portable Prefabricated Steel Truss Bridge Compact 200 Modular Bailey

Installation of the Steel Bailey Bridge:

Method 1 Craning: use of certain tons capacity crane on site, which allows a quick and easy assembly and installation


Method 2 Launching: When the site does not allow crane to work, the Panel Bridge, which can be carried by manpower, can be assembled manually and installed by launching using a pushing device with a limited capacity.

Advantages:

1.Great stability
2.Single or double lanes are optional
3.Lightweight components
4.Easy to assembly and dismantle
5.Strong environment adaptability.
6.Wide range of applications

Applications:

Infrastructure upgrading

Railway

Highway

Footbridge

Emergency

Military

Residential community

Farms

Rural areas

Temporary

Permanent

FAMOUS runs two well-equipped production bases and the capacity of each one is around 30000-40000tons per year. there are many domestic/overseas projects on the going. In addtion to ISO, we also have the certification of AWS D1.1, AWS D1.5 Bridge field specialized Certification, related tests/inspections have been done .

Portable Prefabricated Steel Truss Bridge Compact 200 Modular Bailey

Product images:

Portable Prefabricated Steel Truss Bridge Compact 200 Modular Bailey

Portable Prefabricated Steel Truss Bridge Compact 200 Modular Bailey

If you are interested, please contact us for a quote.
