17*40*12mm 6203ZZ Radial Grooved Ball Bearings
17*40*12mm 6203ZZ Radial Grooved Ball Bearings
17*40*12mm 6203ZZ Radial Grooved Ball Bearings
17*40*12mm 6203ZZ Radial Grooved Ball Bearings
17*40*12mm 6203ZZ Radial Grooved Ball Bearings
17*40*12mm 6203ZZ Radial Grooved Ball Bearings
Specifications
Brand Name :
SGC
Model Number :
6203, 6203-ZZ, 6203-2RS
Certification :
RoHS
Place of Origin :
Fuzhou, China
MOQ :
100 PCS
Price :
Get The Latest Price
Payment Terms :
D/P, L/C, T/T, Western Union
Supply Ability :
300000PCS per month
Delivery Time :
6-45 days upon receipt of official order
Packaging Details :
plastic tube+box, or according to requested by clients
Materials :
Chrome Steel 52100
Bore Size :
17 mm
OD :
40 mm
Width :
12 mm
Accuracy :
ABEC-1, ABEC-3, ABEC-5
Noise and Vibration :
Z1V1, Z2V2, Z3V3
Clearance :
C0, C2, C3
Shields :
Open, Seals, or Metal Shielded optional
Retainers :
Rivet Type
Lubrication :
Shell Alivania R2, ESSO Beacon 325, Chevron SRI-2, Mobil 28, Kluber, Kyodo Yushi, etc.
Hardness :
HRC60-65
Surface :
harden polished
Package :
Plastic Bag + Cardboard Box + Wooden
Application :
Precision Machinery, Grinding Media, Motorcycle, Electric Hand Tools, Bicycles, etc..
Feature :
Solid
Sample :
by free
Certifications :
ISO, ROHS
Service :
Customized Service,OEM /After-Sales Service
Description

High Performance Radial Grooved Ball Bearings with EMQ quality Model 6203ZZ

Open/Seals/Shields Type-Metric

Model No.: 6203, 6203-ZZ, 6203-2RS

Races: 52100, HRC60-65 Hardness

Balls: 52100, 8 balls, HRC 61-66 Hardness

Retainer: Rivet Type( Nylon cage optional)

Bondary Diamensions: 17*40*12mm

Net Weight: 0.066kgs

Applications:

The bearings are widely used on ocean engineering equipment and ship, food processing machinery, medical equipment, cryogenic engineering, automobile, motorcycle, electric tools, high-speed motor, household appliances and other industries.

Lubrications:

Before SGC bearings leave factory,the open bearing is filled with meter anti-rust oil only;while the shielded bearing has been filled with general bearing grease,which makes it suitable for light and medium load as well as low and medium speed applications, with a working temperature ranging from -30℃～100℃.If the bearings are applied beyond the above conditions, other special grease or lubricating methods shall be employed.



Bearing No.

Boundary Dimensions(mm)

Basic Load Rating

Balls

Limit Speed
Net Weight
d D B Chamfer C(N) CO(N) Qty Size Grease Oil Kgs
624 4 13 5 0.2 1.31 0.49 6 2.381 36000 45000 0.0032
625 5 16 5 0.3 1.76 0.68 6 3.175 32000 40000 0.0048
626 6 19 6 0.3 2.34 0.885 7 3.5 28000 36000 0.0081
627 7 22 7 0.3 3.35 1.4 7 3.969 26000 34000 0.013
628 8 24 8 0.3 4 1.59 7 3.969 24000 32000 0.017
629 9 26 8 0.3 4.55 1.96 7 4.763 22000 30000 0.02
6200 10 30 9 0.3 5.1 2.39 8 4.763 19000 26000 0.032
6201 12 32 10 0.6 6.1 2.75 7 5.953 18000 24000 0.037
6202 15 35 11 0.6 7.75 3.6 8 5.953 17000 22000 0.045
6203 17 40 12 0.6 9.6 4.6 8 6.747 16000 20000 0.066
6204 20 47 14 1 12.8 6.65 8 7.938 14000 18000 0.106
6205 25 52 15 1 14 7.85 9 7.938 12000 16000 0.128
6206 30 62 16 1 19.5 11.3 9 9.525 10000 13000 0.199
6207 35 72 17 1.1 25.7 15.3 9 11.112 8800 10000 0.287
6208 40 80 18 1.1 29.1 17.8 9 12 7700 9200 0.367
6209 45 85 19 1.1 32.5 20.4 10 12 6800 8200 0.416
6210 50 90 20 1.1 35 23.2 10 12.7 6100 7300 0.462
6211 55 100 21 1.5 43.5 29.2 10 14.288 5500 6600 0.602
6212 60 110 22 1.5 52.5 36 10 15.081 5000 5500 0.804
6213 65 120 23 1.5 57.2 40.1 - - 5400 6400 0.99
6214 70 125 24 1.5 60.5 46 　 　 5000 6000 1.34
6215 75 130 25 1.5 66 50 　 　 4800 5600 1.16
6216 80 140 26 2 71.5 54.5 　 　 4500 5300 1.43
6217 85 150 28 2 83 64 　 　 4300 5000 1.8
6218 90 160 30 2 95.5 72 　 　 3800 4500 2.19
6219 95 170 32 2.1 108 81.5 　 　 3600 4300 2.61
6220 100 180 34 2.1 122 93 　 　 3400 4000 3.2
6221 105 190 36 2.1 132 105 　 　 3200 3800 3.66
6222 110 200 38 2.1 133 106 　 　 2800 3400 4.29
6224 120 215 40 2.1 156 131 　 　 2800 3400 5.26
6226 130 230 40 3 165 148 　 　 2600 3200 6.04
6228 140 250 42 3 166 150 　 　 2400 3000 7.41
6230 150 270 45 3 175 169 　 　 2000 2600 9.76
6232 160 290 48 3 210 210 　 　 1900 2400 12.3
6234 170 310 52 4<
