10T European Style Single Girder Overhead Crane Woking Class A5 Variable-Frequency
10T European Style Single Girder Overhead Crane Woking Class A5 Variable-Frequency
10T European Style Single Girder Overhead Crane Woking Class A5 Variable-Frequency
10T European Style Single Girder Overhead Crane Woking Class A5 Variable-Frequency
10T European Style Single Girder Overhead Crane Woking Class A5 Variable-Frequency
10T European Style Single Girder Overhead Crane Woking Class A5 Variable-Frequency
Specifications
Brand Name :
KUANGYUAN
Model Number :
KSL
Certification :
EAC ISO CE
Place of Origin :
HENAN, CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
4000SETS/ MONTH
Delivery Time :
ABOUT 35 DAYS
Packaging Details :
Standard export packing
Product condition :
made in 2021
Lifting height :
8M
Lifting capacit :
10T
Span :
16.5m
Crane type :
Single beam overhead crane
Color :
Yellow
Material :
Q235B
Warranty :
18 monthsCustomized
Power source :
380V， 50Hz, 3P
Crane long travelling speed :
2-20m/min, variable-frequency
Description

10T European style Single Girder Overhead Crane, Woking class A5, variable-frequency

1. A brief introduction of 10t European style Single Girder Overhead Crane, Woking class A5, Variable-frequency

The 10t european style single girder overhead crane, working class A5, variable- frequency can used to lift cables indoor. Many European and American customers prefer this type of crane.

2. Configuration details of 10t European style Single Girder Overhead Crane, Woking class A5, Variable-frequency

1 Name European style Single Girder Overhead Crane
2 Model KSL
3 Capacity 10t
4 Span 16.5m
5 Lifting height 8m
6 Lifting speed 0.8/5 m/min
7 Cross travel speed 2~20 m/min
8 Long travel speed 2~20 m/min
9 Control type Pendent line control
10 Power supply 380V50Hz3Ph AC
11 Total Power 12.7 kw
12 Crane weight 4900KG
13 Recommended rail model P38

10T European Style Single Girder Overhead Crane Woking Class A5 Variable-Frequency

3. Product advantages of 10t European style Single Girder Overhead Crane, Woking class A5, Variable-frequency

1) Light weight, low headroom, effectively save construction resources

2) The hook limit is small and the working area is large.

3) Frequency control, easy to use.

4) The hook has anti-swing function.

HENAN MINE CRANE has obtained ISO9001:2015,14001:2015,18001:2007,CE,GOST,etc International certificates.

HENAN MINE CRANE cranes has been exported to more than 120countries in the world,i.e Philippines, Australia, India, Pakistan, Egypt, Bangladesh, Saudi Arabia, Peru, Ethiopia, South Africa, etc ( Pls view our website for the shipment page www.hnkscrane.com ), and we have received good feedback and many new orders from them!

HENAN MINE CRANE Technical support:Any way, Any time.

Main beam is made by one time forming machine,no weld,high quality and high strength

Main beam rib plate welding is done by robot, high quality weld.

Main beam is Box type, Sandblasting surface cleanness reach Sa 1/2

Modern electric hoist assembly workshop with testing platform,guarantee high quality.

Modern CNC machines center with various advanced equipment to process all kinds of gears,shaft,to make sure high quality and high precision

Wheel and gears are with quenching process,high hardness and long service life.

Wheels are of vacuum casted and processed and quenching by HENAN MINE,long service life.

Motor/reducer/bearing/cable are of China famous brand.

Painting:brushed by man,to make sure even coating thickness and high adhesive

Continuous 9years sales no.1 in China

4. FAQ

Question 1: What about your factory ?

A: HENAN MINE CRANE is the Quality Bench marking Enterprise in crane industry in 2019

HENAN MINE CRANE is Excellent Crane Supplier to China No.1 steel group- BAOSTEEL

HENAN MINE CRANE double girder overhead crane is the famous brand product in machinery industry in China.

HENAN MINE Crane sells all kinds of crane 93002sets in the year of 2020

HENAN MINE CRANE New Intelligentized Workshop with area 160000m2 has been put into use since Jan.1,2020,it is the largest crane manufacturing workshop in Asia,sales volume can reach 6billion.

Question 2 : What services do you offer?

A:We can design the most suitable Crane for you according to your plant drawings, and provide installation and guidance services.
