10T 6M A3 Q235 MH mobile single beam gantry crane Remote Control
10T 6M A3 Q235 MH mobile single beam gantry crane Remote Control
10T 6M A3 Q235 MH mobile single beam gantry crane Remote Control
10T 6M A3 Q235 MH mobile single beam gantry crane Remote Control
Specifications
Brand Name :
Kuangyuan
Model Number :
MH
Certification :
CEI,SO
Place of Origin :
China
MOQ :
1SET
Payment Terms :
L/C, D/A, Western Union
Delivery Time :
30working days
Product name :
10T MH Type Electric Single Beam Girder mobile Gantry Crane
Lifting mechanism :
Eliectric Hoist
Work Duty :
A3
Main electrical parts :
Schneider
Control Method :
Remote Control
Power Source :
3 Phase 380V 50hz
Color :
Clients' Requirments
Steel Material :
Q235
Girder Type :
Box type
Speed :
20m/min
Description

10T 6M A3 Q235 MH single beam gantry crane Remote Control

Product Description

MH type single girder gantry crane has box type and truss type, the former have good techniques and easy fabrication, the latter is light in dead weight and strong in wind resistance. For different usage, MH gantry crane also has cantilever and noncantilever gantry crane. If have cantilevers, the crane can load the goods to the crane edge through the supporting legs which is very convenient and high efficiency.

Main Features of MH model gantry Crane:

1.Simple and compact structure, steady performance.

2.Easy to install and high efficiency.

3.Overload, low voltage protective device.

4.Pendent control and remote control.

5.Easy maintenance.

Product Structure:
Rated load/ton 5 10 16 20
Span/m 10-40
Lifting height/m 30
Working class A3/1bM
Lifting speed/m/min 8 7 3.5 3.5
Trolley running speed/m/min 20 20 20 20
Crane running speed/m/min 20 20 20 20
Dead weight/t 10.5~37.5 16.8~52 18.9~65 24.5~77

Attention:

Safety is the most important issue for cranes. To ensure the safety,It is prohibited to use the equipment in the combustible, explosive or corrosives environment.(Need explosion proof type for this).

10T 6M A3 Q235 MH mobile single beam gantry crane Remote Control
Product Details:

Main Parts of MH model gantry Crane:

Certifications:
We have passed CE, GOST, SGS, and OHSAS & ISO9001:2000 international quality control, ISO14001:1996 environment and ISO9001:2001 health and safety certifications. We have a perfect quality-control system, a strict management system, and strong production capability and advanced testing measures to ensure the high production and high quality.

Contact us:

Thank you for your interests in Henan Mine Crane Co.,Ltd. We look forward to receiving your any question about Electric Winch and provide you our best solution.
