Cabin Control LDP 5t Monorail Hoist Crane 3P 220--440 V/50hz60HZ
Cabin Control LDP 5t Monorail Hoist Crane 3P 220--440 V/50hz60HZ
Cabin Control LDP 5t Monorail Hoist Crane 3P 220--440 V/50hz60HZ
Cabin Control LDP 5t Monorail Hoist Crane 3P 220--440 V/50hz60HZ
Specifications
Brand Name :
Kuangyuan
Model Number :
LDP
Certification :
CEI,SO
Place of Origin :
China
MOQ :
1SET
Payment Terms :
L/C, T/T, , MoneyGram
Delivery Time :
30working days
Product Name :
Low Cost Monorail Hoist LDP 1t 2t 3t Overhead Crane for Sale
Work Duty :
A3-A5
Power Source :
3P 220--440 V/50hz60HZ
Main electrical parts :
Schneider Brand
Lifting mechanism :
Electric Hoist
Control method :
Ground Control+Remote Control+Cabin Control
Color :
Customised
After-sales Service Provided :
Engineers available to service machinery overseas
Lifting Speed :
0.8/5m/min
Motor :
Chinese Famous Brand/Requirment
Description

LDP 5t Monorail Hoist Overhead Crane 3P 220--440 V/50hz60HZ for Sale

Product Description

LDP EOT model single girder Ovehead crane is designed as light type lifting equipment according to Chinese standard. It is equipped with the features of reasonable structure, max lifting height, strong rigidity of the whole. This crane is equipped with an electric wire rope hoist to lift different cargoes, its capacity can vary from 1 to 20 tons and reach from 7.5 to 31.5 m, working class A3-A4 according to ISO standard. This type of crane is widely used in factory, warehouse, luggage yard for lifting goods, forbidden to use in flammable, explosive and corrosive environment (we have explosion-proof and casting single-girder crane for special conditions). This single girder crane is operated by a pendant control or a remote control.

Product Structure:
Capacity(t) 1t, 2t, 3t, 5t 10t 16t
Span(m) 6.5m---28.5m
Lifting height(m) 3m---30m
Control mode Pendant control, wireless remote control, cabin control
Lifting speed(m/min) 2.8 ,8 , 8/0.8 2.3 , 5/0.8 7, 7/0.7 4, 4/0.4
Traveling speed(m/min) 20,30,45 (Inverter)
Service class(work grade) a) M2, M3: used in places of mild service, such as workshop and warehouse.
b) M4: used in places of Medium service such as assembly and depot.
Supply power(three phase power) 380V 50HZ 3Phase (according to user require)
Hoist type Wire rope or chain hoist, single or double speed
Working ambient temperature -20 °C~ <55°C.
Note It’s not suitable for lifting blazing & melting metal or toxicant as well as explosion-proof or insulating working conditions.
Product Details

Cabin Control LDP 5t Monorail Hoist Crane 3P 220--440 V/50hz60HZ

Safe configuration:
1.Weight overload protection device
2.Top quality durable polyurethane buffer
3.Crane traveling limit switch
4.Low voltage protection function
5.Emergency stop system
6.Current overload protection function
