20T Workshop Double Girder Bridge Crane Span 15m Working Duty A5
20T Workshop Double Girder Bridge Crane Span 15m Working Duty A5
20T Workshop Double Girder Bridge Crane Span 15m Working Duty A5
20T Workshop Double Girder Bridge Crane Span 15m Working Duty A5
20T Workshop Double Girder Bridge Crane Span 15m Working Duty A5
20T Workshop Double Girder Bridge Crane Span 15m Working Duty A5
Specifications
Brand Name :
KuangYuan
Model Number :
QD
Certification :
CE, ISO, EAC
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
4000 sets/ month
Delivery Time :
30 days
Capacity :
20T
Span :
15m
Working class :
A5
Color :
As your like color
Type :
QD
Supply voltage :
415V, 50Hz, 3P
Control method :
Cabin
Warranty :
18months from the date of delivery
Description

20T Double Girder Overhead Crane Span 15m, Working Duty A5 for Workshop ​

1. Product description for 20T Double girder overhead crane span 15m working duty A5

The double-girder bridge crane is mainly composed of a bridge frame, a cart operating mechanism, a trolley, and electrical equipment. According to the frequency of use, it is divided into three working levels: A5, A6, and A7. The operation of the hook bridge crane is all completed in the driver.

20T double girder overhead crane is mainly consists of bridge, trolley travelling mechanism, crab and electrical appliances, and is divided into 2 working grades of A5 and A6 accroding to the use frequency.This crane is completed in drivers chamber.

2. Technical Specification for 20T Double girder overhead crane span 15m working duty A5

S/N.

Crane No.s

Double Girder Overhead Crane

1

Name

2

Model

QD20t-15m

3

Working class

A5

4

Capacity

20tons

5

Span

15m

6

Lifting height

6m

7

Lifting speed

9.8m/min

8

Trolley travelling speed

44.6m/min

9

Crane travelling speed

89m/min

10

Control type

Cab

11

Power supply

440V50Hz3Ph AC

12

Lifting motor

45KW

13

Trolley traveling motor

4KW

14

Crane long traveling motor

2x11KW

15

Crane weight

27000Kgs

20T Workshop Double Girder Bridge Crane Span 15m Working Duty A5

20T Workshop Double Girder Bridge Crane Span 15m Working Duty A5
