JK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / Min
JK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / Min
JK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / Min
JK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / Min
Specifications
Brand Name :
kuangyuan
Model Number :
winch
Certification :
CE ISO GOST
Place of Origin :
China
MOQ :
1set
Price :
USD 2600~5400 sets
Payment Terms :
L/C, T/T
Supply Ability :
15000 per years
Delivery Time :
25days
Packaging Details :
export packing
Rope capacity :
150m
Warranty :
1 Year
Rated speed :
15m/min
Rope diameter :
12.5mm
Orm dimension :
945*996*570mm
Motor power :
5.5kw
Description

Electric Wire Rope Winch Machine 2500lbs JK Electric Pulling Winch

High speed Electric Winch is widely used on bridge /gantry carne, it is mainly used in marine to help lifting ship or fishing lifting, the large and middel sized concrete, steel structure, mechanical equipment installation and dismantling. The structural characteristics of steel wire rope is an orderly, lifting safe and reliable. Suitable for all kinds of bridge, port, wharf, road and bridge engineering.

Features of electric winch:

1.Top quality with competitive price

2.Widely used in factory, mining, shipyard or double beam cranes

3.Compact structure and reasonable design

4.Easy to install, operate and maintenance

5.Low noise and good working condition

Technical Parameter of High speed Electric Winch
Model Rated load(KN) Rated speed (m/min) Rope capacity (m) Rope diameter (mm) Motor model Motor power (KW) Overall dimensions (mm) Total weight (kg)
JK1 10 22 100 9.3 Y112M-4 4 620x701x417 300
JK1.6 16 24 120 12.5 Y132S-4 5.5 945×996×570 500
JK2 20 24 120 13 Y132M-4 7.5 945x996x570 550
JK3.2 32 25 200 15.5 YZR180L-6 15 1325x1335x840 1200
JK5 50 30 200 21.5 YZR225M-6 30 1900x1620x985 2400
JK8 80 25 250 26 YZR280S-8 45 1533x1985x1045 3500

JK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / Min

JK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / MinJK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / MinJK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / MinJK Electric Pulling Electric Wire Rope Winch Machine 2500lbs 15m / Min

RFQ:

Q1: What's the information should I provide when inquiry?

A1: More details or drawings, better.
A: Lift capacity B: span C: lift height D: power source or other specials you give us will be more appreciated.
Q2: What do Henan Mine Crane do?
A2: We design, manufacture, install overhead crane, gantry crane, port crane, hoists, winch and provide customer lifting solutions.
Q3: What makes you different from other manufactures?
A3: We have trained service technicians who will be able to get your material handling equipment up and running and have been providing our customers and effective service solution.

Q4: What area do you service? How can we install the crane?
A4: We mainly service in China and our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
Q5: Can this type work in hazardous environment?
A5: Sure! We can customize for you, acid proof or explosion proof, no problem for that.

Q6: Can you provide the various lifting tools?
A6: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
