Customized 1T Electric Wire Rope Construction Hoist 8m / Min Long Duration Time
Customized 1T Electric Wire Rope Construction Hoist 8m / Min Long Duration Time
Customized 1T Electric Wire Rope Construction Hoist 8m / Min Long Duration Time
Customized 1T Electric Wire Rope Construction Hoist 8m / Min Long Duration Time
Specifications
Brand Name :
kuangyuan
Model Number :
MD
Certification :
CE ISO GOST
Place of Origin :
China
MOQ :
1set
Price :
USD 540~880 sets
Payment Terms :
L/C, T/T
Supply Ability :
15000 per years
Delivery Time :
25days
Packaging Details :
export packing
Usage :
Construction Hoist
Condition :
New
Sling type :
Wire Rope
After-sales service provided :
Online support
Lift speed :
8m/min
Color :
Customised
Description

Customized 1T 2T 5T Electric Wire Rope Hoist Long Duration Time Hoist

CD1, MD1 type electric 2021 new products wire rope electric chain hoist top quality manufacturer for sale with wire rope hold the characteristic as compact structure, light weight and easy operation.It can be installed on I-steel or working together with single beam crane, double beam crane, jib crane and so on. CD1 type is single-speed while MD1 type has dual speed. The fast speed is for lifting, low speed can do precise loading and unloading, mounding of sand box, maintenance of machine tools etc.

Advantages of Wire Rope Hoist:

• CE approved.

• Lightweight robust construction.

• Low effort to lift maximum load.

• Fully forged hooks.

• High grade alloy load chain.

• Durable baked enamel paint protection.

• Overload protection device available upon request.

• Excellent after-sale serve.

Type CD1, MD1
Lifting weight(T) 0.25 0.5 1 2 3 5 10 16 20
Lifting height(m) 3.6.9 6.9.12.18.24.30 9.12.18
Hoisting speed(m/min)
8
0.8/8
7
0.7/7

3.5

0.35/5

 4
Travelling speed(m/min) 20 20/30 20
Wire
rope
 Dia 3.6 4.8 7.7 11 13 15 15 1735 19.5
spec 6x19 6 x 37 + 1
Hoisting
Motor
 Type ZD112-4 ZD121-4 ZD122-4 ZD131-4 ZD132-4 ZD141-4 ZD151-4 ZD152-4
ZDS0.2/0.8 ZDS0.2/1.5 ZDS0.4/3.0 ZDS0.4/4.5 ZDS0.8/7.5 ZDS1.5/13 ZDS1.5/13
Power(kw) 0.4

0.8

0.2/8

1.5

0.2/5

3.0

0.4/3.0

4.5

0.4/4.5

7.5

0.8/7.5

13

1.5/13

13

1.5/13

 18.5
Rotate speed 1380 (r/min)
Current(A) 1.25

2.4

0.72/2.4

4.3

0.72/4.3

7.6

1.25/7.6

11

2.4/11

18

2.4/18

30

4.3/30

 41.7

Travelling

Motor

 Type ZDY110-4 ZDY111-4 ZDY112-4 ZDY121-4
Power(kw) 0.06 0.2 0.4 0.8 0.8x2
Rotate speed 1400(r/min) 1380(r/min)
Current(A) 0.3 0.72 1.25 2.4 4.3
NO of connecting 120
Working system Intermediate FC=25% M3
Power source 380V 50HZ 3phs
We can design and manufacture all kinds of non-standard product according to your requirement

Customized 1T Electric Wire Rope Construction Hoist 8m / Min Long Duration TimeCustomized 1T Electric Wire Rope Construction Hoist 8m / Min Long Duration TimeCustomized 1T Electric Wire Rope Construction Hoist 8m / Min Long Duration TimeCustomized 1T Electric Wire Rope Construction Hoist 8m / Min Long Duration Time

RFQ:

Q1: What's the information should I provide when inquiry?A1: More details or drawings, better.
A: Lift capacity B: span C: lift height D: power source or other specials you give us will be more appreciated.
Q2: What do Henan Mine Crane do?
A2: We design, manufacture, install overhead crane, gantry crane, port crane, hoists, winch and provide customer lifting
solutions.
Q3: What makes you different from other manufactures?
A3: We have trained service technicians who will be able to get your material handling equipment up and running and have been
providing our customers and effective service solution.
Q4: What areas do you service? How can we install the crane?
A4: We mainly service in China and our senior engineer can be your side to do the installation guide service and training.
Moreover, our best sales can visit your country.
Q5: Can this type work in hazardous environment?
A5: Sure! We can customize for you, acid proof or explosion proof, no problem for that.
Q6: Can you provide the various lifting tools?
A6: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
