LDP Model 1T,3T,5T Remote or Pendent Line Control Electric Single-girder Crane

Product desciption:

LDP electric single-girder crane is a small-size low headroom crane. The electric hoist is at one side of the girder, which increases the work space of the hook and reduces the workshop height and cost. It is applicable to the places where the workshop’s headroom is low.
The crane is composed of box-shaped girder weld by steel plates, end girder, crab and travelling mechanism. The crab consists of traveling end airder, crab frame and fixed electric block. The crab is partially hung and runs at one side of the g rider. The electric hoist is raised to the upside of the girder from under the girder, which effectively increasing the lifting altitude. The crab is braked by conical motor and driven by exposed gear
The girder,of box-shaped structure and bias rails, has horizontal wheels at the upper and the lower, so that it is safe and reliable and can avoid rai gnawing.
The trolley adopts separate drive, conical motor brake and exposed gear drive. The travelling motor can be soft start motor and variable-frequency adjustable-speed motor according to user requirements. The crane can start steadily and runs safely and reliably
it has three operation modes: ground handle, wireless remote control and cab. The cab has two types: open cab and closed cab. The span o it is 7.5~22.5m (subject to non-standard design according to user’s requirements). The classification group is A3, and the operating ambient temperature is -25℃~40℃.

Sketch:

Technological parameter:

FAQ:

A: Can you provide custom service?
B: Yes, of course. We are manufacturer and we have our own engineer group. They can work out customized design according to your requirement. The most important thing is that you should tell us what you need.

A: Are there any professional technicians to assist our installation?
B: Yes. We have a professional installation team, who has already been to many countries to assist the installation. If you need our technicians to offer this service, please let us know in advance. So that we can arrange the suitable technicians to your country.

A: Whether or not you can offer the matched spare parts?
B: Yes, as a crane manufacturer, we can offer all the related spare parts. Such as motor, hoists, drums, wheels,grabs, hooks, rails, travel beams, enclosed bus bar, etc.

A: How can you ensure the quality?
B: Before delivery, every product will be tested strictly and we will send you the quality certification. You are also warmly
welcomed to our factory to make the inspections.
