Mid Chrome Industrial Grinding Balls Cast Iron High Surface Hardness
Mid Chrome Industrial Grinding Balls Cast Iron High Surface Hardness
Specifications
Brand Name :
DRAGON STEEL BALLS
Model Number :
High Chrome,Mid Chrome,Low Chrome
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 ton
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
3000 tons / Month
Delivery Time :
3-7 work days/ 25 tons
Packaging Details :
Container bags ,steel drums
Advantage :
High Wear Resistant,High Hardness
Technology :
Casting
Port :
Tianjin/Qingdao/Shanghai
Size :
12mm-120mm
Service :
After sale service
Test :
Any third party test
Description

50mm Mid Chrome Cast Iron Balls High Chrome Grinding Media Cast Balls

1. Cast Iron Balls Product Name

Casting ball

Cast Steel Ball

Cast Balls

Cast Iron Balls

Ball Mill Balls

Grinding Balls For mining

Grinding Media balls

2. Application

① Mining ( Gold, copper, iron ore )

② Cement plant

③ Coal mill

④ Sag mill

⑤ Industry

⑥ All the ball mill or rods mill machine

3. Classification

According to the different chemical elements , Cast balls can be divided into Low Cr,Medium Cr and High Cr. At present, the above materials are widely used all over the world, that’s the conventional materials, if there are special needs, can be customized.

4. Manufacturing process

Cast Iron balls are melted in electric furnace and poured into moulds after scientific proportioning. High chromium cast balls are also processed by oil quenching.

5. Detail Specifications

① Chemical Composition

Material Chemical Composition
Low Cr C:2.2-3.4, Si:≤1.2, Mn:0.5-1.5, P:≤0.06, S:≤0.06, Cr:1.0-1.5
Medium Cr C:2.0-3.2, Si:<1.0, Mn:0.5-2.5, P:≤0.06, S:≤0.06, Cr:≥5
High Cr C:2.0-3.2, Si:<1.0, Mn:0.5-2.5, P:≤0.06, S:≤0.06, Cr:≥10

② Hardness

Type Low Cr Medium Cr High Cr
20mm-150mm 45-50 48-55 58-63

③ Dragon Balls Weight

Size(mm) 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Weight(kg) 0.033 0.111 0.261 0.512 0.883 1.402 2.092 2.98 1.087 5.44 7.062 9.008 11.25 13.83

④ Dragon balls specifications

Diameter

(mm)

Diameter Tolerance

(mm)

 Approx Weight of per ball(kg) Average numbers per ton
20 ＋1,－0.5 0.033 30303
30 ＋2,－1 0.11 9090
40 ＋2,－1 0.261 3831
50 ＋2,－1 0.512 1961
60 ＋2,－1 0.883 1132
70 ＋3,－1.5 1.402 713
80 ＋3,－1.5 2.092 478
90 ＋3,－1.5 2.98 335
100 ＋3,－1.5 1.087 244
110 ＋3,－1.5 5.44 183
120 ＋3,－1.5 7.062 141

6. Quality Control

① Factory test

Cast iron balls test is an very important step. Real-time detection will be carried out in the production process. Balls produced in each shift will be sampled in large quantities and tested for size, hardness, chemical composition, drop test, core pulling and impact value to ensure the quality of steel balls.

② The third party test

According to the customer different demand, cast iron balls can be tested by any third party.

7. Packing

Cast Iron balls are usually packed in container bags and steel drums, it can also be customized according to different customer needs.

8. Company Introduction

Dragon balls factory are established in 2001.Up to now, we have cooperated with many large power plants in China for more than 10 years. Since 2007, Dragon balls has set up its own foreign trade team, and began to show itself to the world. The forged ball, cast ball and cylpebs are widely praised by friends at home and abroad.


Dragon balls has a very mature technology research and development team and sales team, we are constantly expanding the factory and team every year, in order to meet the growing demand at home and abroad.

Steel balls are a long-term business.

We are willing to do it all the time because if we know someone, we will become permanent friends.

We can always do this for so many years because our quality supports our long-term cooperation and friendship.

The quality of every steel ball is crucial because it is a strong bridge that connects us.
