Forged Cast Grinding Media Ball High Reliability With CE / ISO Certification
Forged Cast Grinding Media Ball High Reliability With CE / ISO Certification
Specifications
Brand Name :
DRAGON STEEL BALLS
Model Number :
45# 60Mn B2 B3 Low Cr Mid Chrome High Cr
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 ton
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
3000 tons / Month
Delivery Time :
3-7 work days/ 25 tons
Packaging Details :
Container bags ,steel drums
Main Product :
Forged ball, cast ball, cylpebs,liners,rods
Port :
Tianjin/Qingdao/Shanghai
Advantage :
Good Wear Resistant,High Hardness
Usage :
Mining,Cement plant,Power Station
Size :
20mm-150mm
Material :
Round Steel,Steel Iron
Tolerance :
+-1,+-2
Process :
Forging,hot rolling,casting
Description

Forged Cast Grinding Ball Steel Grinding Balls For Mining and Cement Plant

1.Dragon Balls Factory Main Products:

Cast Iron Ball

Forged Steel Ball

Hot Rolling Ball

Grinding Cylpebs

Grinding Rods

Ball Mill Liners

All the ball mill grinding media and the liners , we can customized the material ,the size and so on according to the different need .

2. Main Product Classification

Main Product Classification
Cast Iron Ball Low Cr,Medium Cr,High Cr
Forged Ball C45,60Mn,B2,B3
Hot Rolling Ball C45,60Mn,B2,B3
Cylpebs C45,60Mn,B2,B3
Grinding Rods Low Cr,Medium Cr,High Cr
Liners Mn13Cr2,High Chrome

3. Forged ball,hot rolling ball,grinding rods Chemical Elements

Material

Chemical Composition

C

Si

Mn

Cr

P

S

Ni

Cu

C45

0.42-0.5

0.17-0.37

0.5-0.8

≤0.25

≤0.035

≤0.035

≤0.25

≤0.25

60Mn

0.55-0.65

0.17-0.37

0.7-1.0

≤0.25

<0.04

<0.04

≤0.3

≤0.25

B2

0.72-0.85

0.17-0.37

0.7-1.0

0.4-0.6

≤0.025

≤0.025

≤0.02

≤0.02

B3

0.58-0.66

1.3-1.9

0.65-0.8

0.7-0.9

≤0.025

≤0.025

≤0.02

≤0.02

4. Cast Iron Ball,Cylpebs Chemical Elements

Material C Si Mn Cr P S
Low Cr 2.2-3.4 ≤1.2 0.5-1.5 1.0-1.5 ≤0.06 ≤0.06
Medium Cr 2.0-3.2 <1.0 0.5-2.5 ≥5 ≤0.06 ≤0.06
High Cr 2.0-3.2 <1.0 0.5-2.5 ≥10 ≤0.06 ≤0.06

5. Dragon Balls Different Product Line

Main Product

Production Line

Cast Iron Ball

Casting:Smelting the material in the furnace, pour out to the mould.

Forged Ball

Forging: Heating raw materials by electric circuit, air hammering and forging

Hot Rolling Ball

Rolling : Hot Rolling by the rolling machine

Cylpebs

Casting:Smelting the material in the furnace, pour out to the mould.

Grinding Rods

Heat treatment : Heat treatment the raw material

Liners

Customized casting

6. Quality Control

① Factory test

Steel Grinding Balls test is an very important step. Real-time detection will be carried out in the production process. Balls produced in each shift will be sampled in large quantities and tested for size, hardness, chemical composition, drop test, core pulling and impact value to ensure the quality of steel balls.

② The third party test

According to the customer different demand, steel grinding balls can be tested by any third party.

7. Packing

Steel Grinding balls are usually packed in container bags and steel drums, it can also be customized according to different customer needs.

8. Company Introduction

Dragon balls factory are established in 2001.Up to now, we have cooperated with many large power plants in China for more than 10 years. Since 2007, Dragon balls has set up its own foreign trade team, and began to show itself to the world. The forged ball, cast ball and cylpebs are widely praised by friends at home and abroad.


Dragon balls has a very mature technology research and development team and sales team, we are constantly expanding the factory and team every year, in order to meet the growing demand at home and abroad.

Steel balls are a long-term business.

We are willing to do it all the time because if we know someone, we will become permanent friends.

We can always do this for so many years because our quality supports our long-term cooperation and friendship.

The quality of every steel ball is crucial because it is a strong bridge that connects us.
