Customized Material Grinding Media Steel Balls For Cement Plant / Power Station
Customized Material Grinding Media Steel Balls For Cement Plant / Power Station
Specifications
Brand Name :
DRAGON STEEL BALLS
Model Number :
45# 60Mn B2 B3
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 ton
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
3000 tons / Month
Delivery Time :
3-7 work days/ 25 tons
Packaging Details :
Container bags ,steel drums
Keywords :
grinding steel ball
Advantage :
High Hardness,Large output
Usagae :
Mining,Cement plant,Power Station
Port :
Tianjin/Qingdao/Shanghai
Materail :
Round Steel
Size :
20mm-40mm
Hardness :
58-63
Tolerance :
+-1
Description

B2 B3 Customized Material Hot Rolling Steel Balls Forged Grinding Balls

1. Grinding steel ball Detail Specifications

① Weight

Size(mm) 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Weight(kg) 0.033 0.111 0.261 0.512 0.883 1.402 2.092 2.98 1.087 5.44 7.062 9.008 11.25 13.83

② Chemical Composition

Material Chemical Composition
C Si Mn Cr P S Ni Cu
C45

0.42-0.5

0.17-0.37

0.5-0.8

≤0.25

≤0.035

≤0.035

≤0.25

≤0.25
60Mn

0.55-0.65

0.17-0.37

0.7-1.0

≤0.25

<0.04

<0.04

≤0.3

≤0.25
B2

0.72-0.85

0.17-0.37

0.7-1.0

0.4-0.6

≤0.025

≤0.025

≤0.02

≤0.02
B3

0.58-0.66

1.3-1.9

0.65-0.8

0.7-0.9

≤0.025

≤0.025

≤0.02

≤0.02

③ Hardness

Size

C45

60Mn

B2

B3
20mm 55-58 58-62 60-64 62-65
30mm 55-58 58-62 60-64 62-65
40mm 55-58 58-62 60-64 62-65
50mm 55-58 58-62 60-64 62-65
60mm 55-58 58-62 60-64 62-65
70mm 53-56 58-62 60-64 61-63
80mm 53-56 58-62 59-63 60-65
90mm 50-55 58-62 57-61 60-65
100mm 48-52 57-61 56-60 60-65
110mm 48-52 57-61 55-60 58-64
120mm 48-52 57-61 55-60 56-63
130mm 48-52 57-61 55-60 56-63
140mm 48-42 57-61 55-60 56-63
150mm 48-52 57-61 55-60 56-63

④ Dragon balls specifications

Diameter

(mm)

Diameter Tolerance

(mm)

 Approx Weight of per ball(kg) Average numbers per ton
20 ＋1,－0.5 0.033 30303
30 ＋2,－1 0.11 9090
40 ＋2,－1 0.261 3831
50 ＋2,－1 0.512 1961
60 ＋2,－1 0.883 1132
70 ＋3,－1.5 1.402 713
80 ＋3,－1.5 2.092 478
90 ＋3,－1.5 2.98 335
100 ＋3,－1.5 1.087 244
110 ＋3,－1.5 5.44 183
120 ＋3,－1.5 7.062 141

2. Dragon Balls Main Product

Forged grinding ball

Hot Rolling Ball

Cast Iron Ball

Grinding Cylpebs

Grinding Rods

Liners

3. Hot Rolling Ball Different Name in Different Place

Hot Rolling Ball

Rolled Ball

Forged Ball

Grinding Media Ball

Rolling Ball

4. Grinding steel ball Application

Hot rolling balls are used in ball mills, mainly in mines, cement plants, power plants and so on.

① Mining ( Gold, copper, iron ore )

② Cement plant

③ Coal mill

④ Sag mill

⑤ Industry

⑥ All the ball mill or rods mill machine

5. Grinding steel ball Classification

According to the different chemical elements , hot rolling balls can be divided into C45,60Mn,B2 and B3. At present, the above four materials are widely used all over the world, that’s the conventional materials, if there are special needs, can be customized.

① 45#

② 60Mn

③ B2

④ B3

6. Hot Rolling Ball Manufacturing process

Hot rolling ball is making by hot rolling machine ,water quenching,double-layer insulating barrel and so on a series process.

7. Hot Rolling Ball Quality Control

① Factory test

Hot rolling balls test is an very important step. Real-time detection will be carried out in the production process. Balls produced in each shift will be sampled in large quantities and tested for size, hardness, chemical composition, drop test, core pulling and impact value to ensure the quality of steel balls.

② The third party test

According to the customer different demand,hot rolling balls can be tested by any third party.

Grinding steel ball factory

Customized Material Grinding Media Steel Balls For Cement Plant / Power Station

We can accept following any third party test.

Customized Material Grinding Media Steel Balls For Cement Plant / Power Station

Core test

Customized Material Grinding Media Steel Balls For Cement Plant / Power Station

Grinding steel ball

Customized Material Grinding Media Steel Balls For Cement Plant / Power Station
