Specifications
Brand Name :
BOYUE
Model Number :
Duplex Stainless Steel
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
29808 PCS
Delivery Time :
20
Packaging Details :
PLY Wooden case or pallet packing.
Standard :
ASME B16.5
Size :
3/4''
Material :
S32750 2507 1.4410
Type :
Socket Weld
Product name :
Socket Weld Pipe Flanges
Pressure :
Class150/300/600/9001500/2500
Description

3/4 " Class 150 32750(2507) Duplex Steel Stainless Steel F53 F51 F60 Socket Weld Pipe Flanges RTJ Forged Flange ​

UNS S32750 A182 F53 is a high alloy duplex stainless steel. F53 has excellent resistance to pitting and crevice corrosion resistance compared with the ordinary austenitic or duplex types. Due to this A182 F53 stainless steel is used primarily in highly corrosive conditions.

UNS S32750 F53 Mechanical Properties

Alloy Tensile Strength ksi Proof Strength 0.2% ksi (min) Elongation (%) (min) Hardness Rockwell C
Super Duplex F53 Annealed Condition 110-135 80 15 28 max

UNS S32750 is a super duplex stainless steel supplied in the solution annealed condition. As a super duplex stainless steel, it combines the desirable aspects of both austenitic and ferritic grades. The higher chromium, molybdenum and nitrogen contents result in a Pitting Resistance Equivalent number (PREN) of >41, providing pitting and crevice corrosion resistance superior to austenitic and duplex stainless steels in almost all corrosive media, and a Critical Pitting Temperature exceeding 50°C.

ASTM/ASME/ANSIB16.5, B16.47, ASME/ANSIB16.48 flange
slip on flange, Weld Neck Flange ,Threaded Flange Blind Flange,

Dimensions : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges etc.

Standards : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings

Class : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.

Size : 1/8″ NB TO 48″NB.

Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673

Duplex Steel Socket Weld Pipe Flanges RTJ Forged 3/4 Inch Class 150 32750 2507Duplex Steel Socket Weld Pipe Flanges RTJ Forged 3/4 Inch Class 150 32750 2507

A. Stainless:

304, 304L, 304H, 310S, 316L, 317, 317L

B. Duplex:

2205, S32750, 904L 254SMO, S31050

C. Special:

Alloy20, Nickel200, Monel400, Alloy625, Incoloy800, Alloy800H, AlloyC-276. Alloy-6XN.

D. Carbon:

ASTM A860 WPHY42. WPHY52, WPHY60, WPHY65, WPHY70

ASTM 694 F42, F46, F50, F52, F60, F65, F70

ASTM A106 GR.B, ASTM A234 WPB, ASTM A105

Duplex Steel Socket Weld Pipe Flanges RTJ Forged 3/4 Inch Class 150 32750 2507

Type:

Slip On Flange, Welding Neck Flange, Socket Welding Flange,

Threaded Flange, Lap Joint Flange, Blind Flange and other kinds of special flangs.
Standard:

· America:ASME B16.5,ASME B16.48,ASME B16.47,API 590

· China:GB/T9112~GB/T9124-2000,GB/T2506-1989(2005),GB/T2504-1989(2005),GB/T10746-1989,GB/T4450-1989

· Germany:DIN 2573~2576,DIN 2527,DIN 2630~2637,DIN 2641~2642

· Japan:JIS B2220-2004,JIS F7806-1996,JIS B2291-1994

· Shipbuilding:CB1001-81,CBM1013-81,CBM1018-81,CBT47-1999

· Industry Standard:JB/T74-1994,JB4700-4707-2000,JB/ZQ4485-4486-1997

· Industry Standard:HG/T20592-2009,HG/T20615-2009

· International Standard:ISO 7005-1-1992

· EU:BS EN 1092-1-2008
Material:

· Austenitc Stainless steel:

· F304,F304L,F304H,F316,F316L,F316H,F317,F317L,F347H,F310S,

F310H,F321,F321H

· Superaustenitic stainless steel:S31254

· Duplex stainless steel

· S31500,S31803(2205),S32304,S32205,S32760,S32750,HDR

· Copper Nickel Alloy:B10,B30

· Special steel:N06600,N08800,N08811,Titanium alloy, Alloy steel etc.

· Carbon manganese steel:20# / Q235B / A105,16Mn,F11,F13
Size: 1/2'-120'(DN15-DN3000)
Rate: 100Lb-2500Lb(0.6MPa-42.0MPa)
Technics: Hot die forging from round bar,CNC machining,Drilling and Passivating

Port:Tianjin/Shanghai/Ningbo
Lead Time :



Quantity(Pieces) 1 - 100 >100
Est. Time(days) 15-30 To be negotiated



Place of Origin China Brand Name BOYUE
Standard ANSI, ISO, ASME, DIN, ASTM Type SW/WN/SO/BL/TH Flanges
ModelNumber Steel Flange Thickness #150,#300,#600,.#900,#1500,#2500
Packing Ply-Wood Cases Payment 30%TT+70% Balance

Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's requirement.
Port:Shanghai/Tianjin

Commerce Clause


Minimum Order Quantity: 1pcs
Price: Depending on quantity
Payment Terms: T/T or Western Union or LC
Supply Ability: 40000pcs per month
Delivery Time: 10-100 days depending on quantity
Packaging Details: PLY-WOODEN CASE OR PALLET

Why Choose Us

1. One-Stop Service,One Single Source.
2. No MOQ.
3. Best quality,competitive price
4. Fast Reply.
5. On-Time Delivery
6. Professional sales and technical team .

FAQ

Q1: Are you a factory or a trade company?
A1: We are a professional manufacturer for designing and producing of Large-size products.(View Mor)
Q2: Do you make customized products or finished parts?
A2: All parts are custom made only, and in stock, we can produce based on your drawings.
Q3: Will my drawing be e after you get it?
A3: Yes, we will not release your design to third party unless with your permission.
Q4: What is the MOQ?
A4: Small order is acceptable, but the more, the cheaper.
Q5: How about the samples?
A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.
