Specifications
Brand Name :
BY
Model Number :
BYAS00054
Certification :
ABS, GL, DNV, NK,
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 ton per Month
Delivery Time :
5-8 work days
Packaging Details :
PLY-WOODEN CASE OR PALLET
Product Name :
Carbon Steel Pipe
OD :
1/2"-48”
Type :
Seamless or welded
Thickness :
SCH 5-SCH XXS
Standard :
A333 Gr6
Prodcut :
steel pipe tube
Description

6mm~88.9mm OD High Pressure Boiler Carbon Steel Tube For Construction Structure OD1/2'-16'

Product Standard: GB3087,GB5310,ASME SA210,ASME SA213,DIN17175

Main steel grades:10,20,20G,20MnG,25MnG,15CrMoG,12Cr2MoG,12Cr1MoVG,12Cr2MoWVTiB,10Cr9Mo1VNb,SA210A1,SA210C,SA213 T11,SA213 T12,SA213 T22,SA213 T23,SA213 T91,SA213 T92,ST45.8/Ⅲ,15Mo3,13CrMo44,10CrMo910 Etc.

Application: For boiler waterwall, economizer, re-heater and the steam pipe manufacturing

Chemical Requirements & Mechanical Properties:

<

Standard Grade Chemical Composition(％)
C Si Mn P S Cr Mo
GB3087 10 0.07～0.13 0.17～0.37 0.38～0.65 ≤0.030 ≤0.030 0.3～0.65 /
20 0.17～0.23 0.17～0.37 0.38～0.65 ≤0.030 ≤0.030 0.3～0.65 /
GB5310 20G 0.17～0.24 0.17～0.37 0.35～0.65 ≤0.030 ≤0.030 ≤0.25 ≤0.15
20MnG 0.17～0.24 0.17～0.37 0.70～1.00 ≤0.030 ≤0.030 ≤0.25 ≤0.15
25MnG 0.18～0.24 0.17～0.37 0.80～1.10 ≤0.030 ≤0.030 ≤0.25 ≤0.15
15CrMo 0.12～0.18 0.17～0.37 0.40～0.70 ≤0.030 ≤0.030 0.80～1.10 0.40～0.55
12Cr2MoG 0.08～0.15 ≤0.50 0.40～0.70 ≤0.030 ≤0.030 2.00～2.50 0.90～1.20
12Cr1MoV 0.08～0.15 0.17～0.37 0.40～0.70 ≤0.030 ≤0.030 0.90～1.20 0.25～0.35
12Cr2MoWVTiB 0.08～0.15 0.45～0.75 0.45～0.65 ≤0.030 ≤0.030 1.60～2.10 0.50～0.65
10Cr9Mo1VNb 0.08～0.12 0.20～0.50 0.30～0.60 ≤0.020 ≤0.010 8.00～9.50 0.85～1.05
ASME SA210 SA210A-1 0.13～0.19 ≥0.1 0.45～0.65 ≤0.030 ≤0.030
SA210C 0.18～0.24 ≥0.1 0.80～1.10 ≤0.030 ≤0.030
ASME SA213 SA213 T11 0.05～0.15 0.50～1.0 0.30～0.60 ≤0.030 ≤0.030 1.00～1.50 0.50～1.00
SA213 T12 0.05～0.15 ≤0.50 0.30～0.61 ≤0.030 ≤0.030 0.80～1.25 0.44～0.65
SA213 T22 0.05～0.15 ≤0.50 0.30～0.60 ≤0.030 ≤0.010 1.90～2.60 0.87～1.13
SA213 T23 0.04～0.10 ≤0.50 0.10～0.60 ≤0.030 ≤0.030 1.90～2.60 0.05～0.30
SA213 T91 0.08～0.12 0.20～0.50 0.30～0.60 ≤0.020 ≤0.010 8.00～9.50 0.85～1.05
SA213 T92 0.07～0.13 ≤0.50 0.30～0.60 ≤0.020 ≤0.010 8.50～9.50 0.30～0.60
DIN 17175 ST45.8/Ⅲ ≤0.21 0.10～0.35 0.40～1.20 ≤0.040 ≤0.040
15Mo3 0.12～0.20 0.10～0.35 0.40～0.80 ≤0.035 ≤0.035 0.25～0.35
13CrMo44 0.10～0.18 0.10～0.35 0.40～0.70 ≤0.035 ≤0.035 0.70～1.10 0.45～0.65
10CrMo910 0.08～0.15 ≤0.50 0.30～0.70 ≤0.025 ≤0.020 2.00～2.50 0.90～1.10

Standard Grade Chemical Composition(％)
Cu Ni V Al W Ti Nb N
GB3087 10 ≤0.25 ≤0.30 / /
20 ≤0.25 ≤0.30 / /
GB5310 20G ≤0.20 ≤0.25 ≤0.08
20MnG ≤0.20 ≤0.25 ≤0.08
25MnG ≤0.20 ≤0.25 ≤0.08
15CrMo ≤0.20 ≤0.30
12Cr2MoG ≤0.20 ≤0.30
12Cr1MoV ≤0.20 ≤0.30 0.15～0.30
12Cr2MoWVTiB ≤0.20 ≤0.30 0.28～0.42 0.30～0.55 0.08～0.15 B 0.002～0.008
10Cr9Mo1VNb ≤0.20 ≤0.40 0.18～0.25 ≤0.015 0.06～0.10 0.03～0.07
ASME SA210 SA210A-1
SA210C
ASME SA213 SA213 T11
SA213 T12
SA213 T22
SA213 T23 ≤0.030 1.45～1.75 B0.0005～0.006 0.02～0.08 ≤0.040
SA213 T91 ≤0.40 0.18～0.25 ≤0.015 0.06～0.10 0.03～0.07
SA213 T92 ≤0.40 0.15～0.25 ≤0.015 1.50～2.00 B 0.001～0.006 0.04～0.09 0.03～0.07
DIN 17175 ST45.8/Ⅲ
15Mo3
13CrMo44
10CrMo910 ≤0.30 ≤0.30 ≤0.015

Standard Grade TS(MPa) YS(MPa) Elongation(％) Hardness
GB3087 10 335～475 ≥195 ≥24 /
20 410～550 ≥245 ≥20 /
GB5310 20G 410～550 ≥245 ≥24 /
20MnG ≥415 ≥240 ≥22 /
25MnG ≥485 ≥275 ≥20 /
15CrMoG 440～640 ≥235 ≥21 /
12Cr2MoG 450～600 ≥280 ≥20 /
12Cr1MoVG 470～640 ≥255 ≥21 /
12Cr2MoWVTiB 540～735 ≥345 ≥18 /
10Cr9Mo1VNb ≥585 ≥415 ≥20 /
ASME SA210 SA210A-1 ≥415 ≥255 ≥30 ≤143HB
SA210C ≥485 ≥275 ≥30 ≤179HB
ASME SA213 SA213 T11 ≥415 ≥205 ≥30 ≤163HB
SA213 T12 ≥415 ≥220 ≥30 ≤163HB
SA213 T22 ≥415 ≥205 ≥30 ≤163HB
SA213 T23 ≥510 ≥400 ≥20 ≤220HB
SA213 T91 ≥585 ≥415 ≥20 ≤250HB
SA213 T92 ≥620 ≥440 ≥20 ≤250HB
DIN17175 ST45.8/Ⅲ 410～530 ≥255 ≥21 /
15Mo3 450～600 ≥270 ≥22 /
13CrMo44 440～590 ≥290 ≥22 /
10CrMo910 480～630 ≥280 ≥20 /

Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.

Delivery status: Annealed, normalized, normalized+Tempered, etc.

Surface treatment: oil impregnation, paint, passivation, phosphating, shot blasting etc.

Packing: Exporting package/wooden box /as requirement.

Mark: As required.

High Pressure Boiler Carbon Steel Tubing For Construction Structure OD 6mm - 88.9mm

Place of Origin

 China Brand Name BOYUE
Standard ANSI, ISO, ASME, DIN, ASTM Type

Seamless
ModelNumber Carbon Steel Pipe Thickness SCH 5-SCH XXS
Packing Depending on customer Payment 30%TT+70% Balance


Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's requirement.
Port:Shanghai/Tianjin

Commerce Clause

Minimum Order Quantity: 1pcs
Price: Depending on quantity
Payment Terms: T/T or Western Union or LC
Supply Ability: 40000 ton per month
Delivery Time: 10-100 days depending on quantity
Packaging Details: Depending on customer



Why Choose Us

1. One-Stop Service,One Single Source.
2. No MOQ.
3. Best quality,competitive price
4. Fast Reply.
5. On-Time Delivery
6. Professional sales and technical team .

FAQ

Q1: Are you a factory or a trade company?
A1: We are a professional manufacturer for designing and producing of Large-size products.(View Mor)
Q2: Do you make customized products or finished parts?
A2: All parts are custom made only, and in stock, we can produce based on your drawings.
Q3: Will my drawing be e after you get it?
A3: Yes, we will not release your design to third party unless with your permission.
Q4: What is the MOQ?
A4: Small order is acceptable, but the more, the cheaper.
Q5: How about the samples?
A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.
