Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'
Specifications
Brand Name :
BY
Model Number :
BYAS00025
Certification :
ABS, GL, DNV, NK,
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 ton per Month
Delivery Time :
5-8 work days
Packaging Details :
PLY-WOODEN CASE OR PALLET
Product Name :
Carbon Steel Pipe
OD :
1/2"-48”
Type :
Seamless or welded
Thickness :
SCH 5-SCH XXS
Standard :
A106,GR.B,A178C,A178D, P265GH,A53 GR.B,etc.
Prodcut :
steel pipe tube
Description

Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'


Product Description

1. Item ASTM A210C carbon steel seamless tube Cold drawn Small diameter
2. Standard

ASTM A213, A312, ASTM A269,ASTM A778, ASTM A789, DIN 17456,

DIN 17175, JIS G3461,etc.
3. Material Carbon pipe

20#,20G,STPT410,STF410,A106,GR.B,A178C,A178D,

P265GH,A53 GR.B,A135 GR.B,P265TR1,P265TR2,

STPT480,A106,GR.C,A210C,Q195,Q235,Q345,ST35.8,

ST45.8, ST52, etc
API Gr.B,X42,X46,X52,X60,X65,X70,X80,X100,etc
4. Specifications Wall thickness 0.1-230mm(SCH10S-XXS)
Outside diameter 6.0-2500mm(1/8”-100”)
Length 6m,5.8m,8m,11.8m,12m or as required.
5. Surface Black painted,PE coated,Galvanized,Varnished,HDPE,etc

ASTM A210 Standard Specification for Seamless Medium-Carbon Steel Boiler and Superheater Tubes

This specification covers seamless medium-carbon steel boiler and superheater tubes. The specification also covers minimum-wall-thickness, tubing sizes, boiler flues including e ends, arch and stay tubes. The specification provides tensile and hardness properties but only applicable to certain size limitations. Material manufacturing shall be killed. Tubes shall be made by seamless process, marked as either hot-finished or cold-finished. Surface condition shall be specifically stated in the order. Chemical composition shall conform to the requirements. Elemental composition other than listed here shall not be permitted. Tension test, flattening test, flaring test, hardness test, hydrostatic or nondestructive electric test shall be made on specimens. Superheater tubes shall be formed without defects and shall withstand expansion, beading, forging, welding, and bending.

What is Cold drawn?

Cold drawing is a kind of processing technology of materials. For metal materials, cold drawing refers to drawing in order to achieve a certain shape and certain mechanical properties, while the material is at normal temperature. Compared with hot forming, cold drawn products have the advantages of high dimensional accuracy and good surface finish.

The sheet for pipes' diameter and thickness

Unit: mm
Nominal diameter Out diameter Nominal wall thickness
A B ASME JIS DIN JIS DIN SCH10 SCH20 SCH30 STD SCH40 SCH60 XS SCH80 SCH100 SCH120 SCH140 SCH160 XXS
15 1/2" 21.3 21.7 21.3 2.8 2.0 2.11 - 2.41 2.77 2.77 - 3.73 3.73 - - - 4.78 7.47
20 3/4" 26.7 27.2 26.9 2.8 2.3 2.11 - 2.41 2.87 2.87 - 3.91 3.91 - - - 5.56 7.82
25 1" 33.4 34.0 33.7 3.2 2.6 2.77 - 2.90 3.38 3.38 - 4.55 4.55 - - - 6.35 9.09
32 1 1/4" 42.2 42.7 42.4 3.5 2.6 2.77 - 2.97 3.56 3.56 - 4.85 4.85 - - - 6.35 9.70
40 1 1/2" 48.3 48.6 48.3 3.5 2.6 2.77 - 3.18 3.68 3.68 - 5.08 5.08 - - - 7.14 10.15
50 2" 60.3 60.5 60.5 3.8 2.9 2.77 - 3.18 3.91 3.91 - 5.54 5.54 - - - 8.74 11.07
65 2 1/2" 73.0 76.3 76.1 4.2 2.9 3.05 - 4.78 5.16 5.16 - 7.01 7.01 - - - 9.53 14.02
80 3" 88.9 89.1 88.9 4.2 3.2 3.05 - 4.78 5.49 5.49 - 7.62 7.62 - - - 11.13 15.24
90 3 1/2" 101.6 101.6 - 4.2 - 3.05 - 4.78 5.74 5.74 - 8.08 8.08 - - - - -
100 4" 114.3 114.3 114.3 4.5 3.6 3.05 - 4.78 6.02 6.02 - 8.56 8.56 - 11.13 - 13.49 17.12
125 5" 141.3 139.8 139.7 4.5 4.0 3.40 - - 6.55 6.55 - 9.53 9.53 - 12.7 - 15.88 19.05
150 6" 168.3 165.2 168.3 5.0 4.5

​

Small Diameter Carbon Steel Seamless Tube Cold Drawn A210C Standard OD1/2'-48'

Supply Ability:40000Pieces / per Month

Packaging & Delivery

Packaging Details:Generally plywooden case or following customer's requirement.

Port:Shanghai/Tianjin

Place of Origin China Brand Name BOYUE
Standard ANSI, ISO, ASME, DIN, ASTM Type Seamless
ModelNumber Carbon Steel Pipe Thickness SCH 5-SCH XXS
Packing Depending on customer Payment 30%TT+70% Balance


Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's requirement.
Port:Shanghai/Tianjin

Commerce Clause

Minimum Order Quantity: 1pcs
Price: Depending on quantity
Payment Terms: T/T or Western Union or LC
Supply Ability: 40000 ton per month
Delivery Time: 10-100 days depending on quantity
Packaging Details: Depending on customer

Why Choose Us

1. One-Stop Service,One Single Source.

2. No MOQ.

3. Best quality,competitive price

4. Fast Reply.

5. On-Time Delivery

6. Professional sales and technical team .

FAQ

Q1: Are you a factory or a trade company?

A1: We are a professional manufacturer for designing and producing of Large-size products.(View Mor)

Q2: Do you make customized products or finished parts?

A2: All parts are custom made only, and in stock, we can produce based on your drawings.

Q3: Will my drawing be e after you get it?

A3: Yes, we will not release your design to third party unless with your permission.

Q4: What is the MOQ?

A4: Small order is acceptable, but the more, the cheaper.

Q5: How about the samples?

A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.
