Up to 12m Length Palisade Sliding Gate Industrial Palisade Fencing

Product Introduction

Palisade sliding gates, working with palisade fencing, are the widest used type for securing commercial and industries premises. Manufactured with high durability, the palisade sliding gate provides high vandal resistance and high security.

Compared with palisade swing gates, it slides neatly behind the neighboring palisade fencing with minimum opening clearance. Meanwhile, it is more suitable for heavy duty application.

They consist of three modules: the gate leaf; the rear rolling section; and the main tower.

Specifications of Palisade Sliding Gate

Palisade Gates are also available in either small single leaf for a personnel entrance or double leaf gates for vehicle entrances. All gate specifications are to suit the size of the desired gate.

The given gate lengths are the open sizes, which means the actual length of the fence gate is bigger than the given data. For example, the length of a vehicle gate is 4m; the actual overall length is more than 4m when taking the width of fence post into consideration.

Height: 1.2m, 1.8m, 2.0m, 2.4m or 3.0m.

Length: 4m, 5m, 6m, 7m, 8m, 9m, 10m, 11m, 12m or other widths as your request.

Leaf: one gate leaf.

Palisade pales: W, D section or angle pales.

Wheel: 2 gate wheel with a diameter of 100mm.

Wheel run track: 10mm to 15mm protruding from the ground surface.

End post: 120mm × 120mm.

Center post: 100mm × 100mm.

Fitting: post clamps, bolts and nuts.

Dimensions
12m maximum span
2.4m maximum height at 12m wide
3.0m maximum height at 10m wide.

Power
Single phase 240v 50Hz 5 amps

Features of Palisade Sliding Gate

• With safety a priority, all automatic gates come with safety edges and photo cells to detect anything in the way of the closing gate, as well as fully compliant to BS/EN 12453.

• Operates at 3-6 seconds per metre (depending on size and infills)

• Automated or manual operation

• Gate heights to 3.0m

• Double-leaf spans to 12m

• W or D pale infill options

• In-house powder coating

• Matching fencing systems

Applications of Palisade Sliding Gate

• Police facilities
• Airports and ports
• Data centre
• High-risk schools
• Utility plants
• Critical national infrastructure
• Industrial and commercial premises

Manufacture

Palisade Sliding Gate are manufactured and assembled in house to the relevant British standards, guaranteeing the highest quality product and exceptional service.

To ensure gates match aesthetic and functional needs, each gate is manufactured bespoke to order.

Delivery and installation

Palisade Sliding Gate are delivered ready to bolt down, and if they are automatic, ready for plugging into a power source.

FAQ

1. Are you manufacturer?

Yes, we are the prefessional steel fence, wrought iron fence, wire mesh fence manufacturer.

2. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery

3: How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers benefit;

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
