SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
Specifications
Brand Name :
AOBIAO
Model Number :
AB-LIH-021
Certification :
CE, ISO
Place of Origin :
Anping China
MOQ :
30 rolls
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000 roll per week
Delivery Time :
about 25-30 days after receicing the deposit.
Packaging Details :
1.woven bags of the above and bottom,high quality package or as customes requested 2.In roll ,water proof paper in side and our side with weave bag;carton;wooden case;pallet. 3. according to customers requirement.
Name :
5ft High 20m Roll Hot Dip Galvanized Common Used Cyclone Chain Mesh Fence
Wire :
1.5mm - 6mm
Aperture :
60x60mm,100x100mm or as your requirement.,45mm/50mm/60mm,75x75mm,80mm * 80mm etc.
Roll :
10m,15m,20m,25m, 30m
Application :
Fence Mesh,railway,Sport Field,etc,Residential
Frame finishing :
PVC Coated,Not Coated,stainless steel,Powder Coated,galvanized
Surface treatment :
PVC coated,Hot Dipped Galvanized,Galvanized+PVC Coated,hot-dipped galvanized,PVC sprayed
Pressure treated wood type :
Heat Treated,Nature,Chemical
Width :
0.5-6m
Usage :
Garden Fence, Sport Fence, Farm Fence
Packing :
Pallet,Waterproof Paper,in rolls with jute or pallet
Color :
Green,white,black
Hole shape :
diamond
Description

5ft High 20m Roll Hot Dip Galvanized Common Used Cyclone Chain Mesh Fence

Chain Mesh Fence product description

Chain mesh fence provides extensive reliability and high security, all at a low cost. It’s durability comes from it’s galvanized heavy gauge steel core. It consists of steel wires woven together to form a diamond-patterned mesh fence. To protect the steel from rust or corrosion, each steel wire is zinc coated through hot-dip galvanization.

SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing

Chain mesh fence specifications

Chain Mesh Common Specifications
Fence Height:
5ft, 6ft, 8ft, etc. (1.5m, 1.8m, 2.0m, 2.4m, etc.)
Fence Length:
9m, 12m, 15m, 20m, 30m
Wire Thickness:
2.5mm, 3.0mm, 3.15mm, 3.5mm, 4.0mm
Opening size:
25x25mm, 50x50mm, 75x75mm, 80x80mm
Flat Bar:
25.0mm*5.0mm
Fence Post:
Round Post (dia. 48mm, 60mm, 75mm)
Clamps:
Metal Clamps
Post Cap:
Metal Rain Cap / Anti-UV PP Cap
Surface treatment:
Pre-Hot Dipped Galvanized (100, 200, 250, 280g/m²)
PVC Coated (All colors in Ral)
Application
Wire diameter
Line Post
Top Rail
3’-4’ high
11 ga
1-5/8” 15 ga.
1-3/8” 17 ga.
5’-6’ high
11ga ,9ga
1-7/8” 16 ga.
1-3/8” 17 ga.
8'-10'high
9ga ,6ga
2-3/8” 15 ga.
1-5/8” 15 ga.

Chain mesh fence type:

(1) Knuckle-Knukle:
The wire is knuckled at both ends and abbreviated as(KK)


(2) Knuckle-Barbed:
The wire is knuckled at the bottom and twisted into a barbed selvedge at the top and is abbreviated as (KB)


(3) Barbed-Barbed:
The wire is twisted in to a barbed selvedge at both ends and is abbreviated as(BB)

Chain mesh fence production process:

SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing

Chain mesh application:

This product is widely used in filters baskets, air filtration units,medicine ,building

cement, mechanical equipment protection, crafts manufacturing,high grade sound box nets, expressway fence,decorative ceilling,highway fence , walkway

SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing

Chain mesh advantage:

SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing

Chain mesh packing:

SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing

Chain mesh gate:

SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing

SS 5ft High Chain Link Fence , 20m/Roll Cyclone Mesh Fencing
