145gsm Fiberglass Mesh Cloth 5x5mm Reinforced Fireproof Alkali Resistant Construction
145gsm Fiberglass Mesh Cloth 5x5mm Reinforced Fireproof Alkali Resistant Construction
145gsm Fiberglass Mesh Cloth 5x5mm Reinforced Fireproof Alkali Resistant Construction
145gsm Fiberglass Mesh Cloth 5x5mm Reinforced Fireproof Alkali Resistant Construction
Specifications
Brand Name :
Aobiao
Model Number :
FSL-FMF-001
Certification :
ISO
Place of Origin :
China
MOQ :
50 rolls
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3000 rolls per month
Delivery Time :
25-30 days after receiving deposit.
Packaging Details :
Plastic Bag + Woven Bag,carton,Plastic film,Shrink Wrapping+paper Label
Product name :
145g 5x5mm Reinforced Fireproof Alkali Resistant Construction Fiberglass Mesh Fabric
Weight :
75gsm-300gsm
Width :
20cm-200cm
Mesh size :
4*4,5*5mm
Weave type :
Plain Woven,Twill Woven,Leno
Yarn type :
C-Glass,E-class fiberglass mesh
Application :
Wall Materials,Heat Insulation Materials,Filter Mesh
Alkali content :
Medium,Alkali Free
Standing temperature :
High Temperature
Material :
Fiberglass Yarn,Glass Fiber Yarn,Fiberglass Wire,PTFE+Fiberglass
Length :
20m~500m
Feature :
Alkaline-resistant,Heat Resistant,strength,Alkali Resistant Fiberglass Mesh Fabric,Flexible soft
Usage :
Wall Reinforced Material,building material,Drywall Joint,repair walls cracks
Package :
Plastic Bag + Woven Bag,carton,Plastic film,Shrink Wrapping+paper Label
Description

145g 5x5mm Reinforced Fireproof Alkali Resistant Construction Fiberglass Mesh Fabric

Fiberglass Mesh Fabric introduction

Fiberglass Mesh Fabric is woven of alkali-free or mild alkali fiberglass, then coated by the alkali-resistant glue and treated by high-temperature heat finishing. It has alkaline resistance, flexibility, and high tensile strength, it always is used for thermal insulation, waterproofing, and crack resistance in the building field.

145gsm Fiberglass Mesh Cloth 5x5mm Reinforced Fireproof Alkali Resistant Construction

We can supply special mesh as follows:

(1) High strength mesh,

(2) Fireproof mesh.

(3) Strong and flexible mesh

We can supply specifications from 30g/m2 to 500g/m2 for mesh.

Main size: 5mm x 5mm or 4mm x 4mm, 75 g/m2, 90 g/m2, 125 g/m2,145 g/m2, 160 g/m2.

High quality :

(1) Coating glue: our coating glue is produced by Germany BASF which can keep more than 70% after 28 days NaoH test.

(2) Our fiberglass yarn is the largest producer of fiberglass yarn in the world like Saint Gobain, it is 20% strong in strength and beautiful surface than normal fiberglass yarn.

large production capacity.

We can supply 8 million 10 million square meters one month for fiberglass mesh.

We can supply 3 million 5 million square meters one month for self-adhesive tape

(3) Certificates to guarantee quality.

Fiberglass Mesh Fabric specification

No. Model of Raw Yarn Mesh(mm) Mesh(mesh/inch) Weight(g/m2) Fracture Strength(N/50MM)
Warp Woof Warp Woof Wrap Woof Warp Woof
1 50 204 5 5 5 5 70± 3 700 800
2 50 306 5 5 5 5 90± 3 700 900
3 100 330 5 5 5 5 125± 3 1100 1300
4 134 330 5 5 5 5 145± 5 1500 1500
5 134 408 5 5 5 5 160± 5 1500 1650
6 50 204 4 5 5 6 75± 3 750 750
7 50 255 4 5 5 6 90± 3 750 750
8 100 255 4 5 5 6 110± 3 1200 1100
9 100 306 4 5 5 6 125± 3 1200 1200
10 134 330 4 5 5 6 145± 5 1500 1500
11 134 380 4 5 5 6 165± 5 1500 1500
12 50 204 4 4 6 6 70± 3 750 750
13 50 306 4 4 6 6 90± 3 750 850
14 100 300 4 4 6 6 120± 3 1200 1200
15 134 330 4 4 6 6 150± 5 1500 1500
16 134 350 4 4 6 6 165± 5 1500 1500
19 204 610 12 12 2 2 110± 3 1000 1000

Fiberglass Mesh Fabric characteristics

1. Good chemical stability: Alkali-resistant, acid-resistant, waterproof, cement erosion-resistant, and another chemical corrosion resistant, and strong resin bonding, soluble in styrene.

2. Outstanding process: Include coating enough alkali-resist glue, our coating glue is produced by Germany BASF which can keep 60-80% strength after 28-day immersion of 5% Na(OH) solution, so that guarantees high strength, high tensility, lightweight.

3. Our fiberglass yarn is supplied by Jushi Group which is the largest producer of fiberglass yarn in the world like Saint Gobain, it owns 20% extra strength and beautiful surface than normal fiberglass yarn!

4. Strength retention rate > 90%, elongation <1%, the durability of more than 50 years

5. Good dimensional stability, stiffness, smoothness, and difficulty to shrink, deformation, good positioning properties.

6. Good impact resistance and not easy to be torn.

7. Fire resistant, thermal insulation, sound insulation, insulations, etc.

Fiberglass Mesh Fabric application
1). Fiberglass mesh is used for wall reinforcement.
2). Fiberglass mesh is an ideal material for outside wall heat insulation.
3). Fiberglass mesh can be applied to bitumen as roof waterproof material, so as to strengthen the tensile strength and lifetime of bitumen.
4). For Reinforcement of marble, mosaic, and stone, plaster.
145gsm Fiberglass Mesh Cloth 5x5mm Reinforced Fireproof Alkali Resistant Construction
