358 fencing system,the ultimate in high security perimeter protection, this system is extensively used when defend able space is paramount, used throughout the world in varying applications.
358 fencing is highly regarded as the most difficult mesh security fence to penetrate, providing an excellent defence against climbing and cut-through.
358 fencing is the popular choice when securing the perimeter of your business. 358 fencing's unique design ensures maximum security to your building, because of the anti-cut, anti-climb and enhanced security barrier that ensures maximum visibility for security cameras.
It is also very difficult and time consuming to attempt to pass items from the protected area 358 fencing.
Panel:
Wire dia: 3mm-5mm.
Mesh size: 12.7*76.2mm
Package: wrapped with shrink film or packed in pallet.
Panel width: 2400 mm.
Panel height: 2000–3600 mm.
Post:
Material: High grade steel.
Post type: RHS post or H post.
Post section: 60 × 60, 80 × 80, 100 × 100, or 120 × 120 mm.
Post Plate thickness: 2.5, 3.0, 4.0, 5.0 mm.
Post cap: metal caps or plastic cap.
Master View 358 | 2.1m | 2.4m | 3.0m |
Panel Height | 2134mm | 2438mm | 2997mm |
Panel Width | 2515mm | 2515mm | 2515mm |
Mesh Size | 12.7x76.2mm | 12.7x76.2mm | 12.7x76.2mm |
Horizontal Wire | 4mm | 4mm | 4mm |
Vertical Wire | 4mm | 4mm | 4mm |
Panel Weight | 50kg | 57kg | 70kg |
Posts | 60x90x4mm | 60x90x4mm | 80x80x4mm |
Post Length | 2.8m | 3.1m | 4.0m |
Clamp Bar | 40x6m slotted | 40x6m slotted | 40x6m slotted |
Fixings | 8 security nuts | ||
No. Of fixings | 8 | 9 | 11 |
Other specifications could be customized by your requirements |
358 wire mesh fence gates
Shipping Port Security fencing
Electrical sub-station fencing
Water Treatment works
Gas pipelines Security Fence
High security window grilles
Balustrades Security Fence
High density yet good viewing visibility.
Anti-climbing, anti-cutting, anti-corrosion.
Easy to install and long service life.
Anti-Climb.
Protects against cut-through.
Increased delay factor.
1. Free Sample for the quality test;
2. We provide quality iron fence panel, post, fence hardware, and accessories. To make sure you will have complete fence projects on time;
3. If you don't see what exactly you need, or the specification you need is special, contract with us and our design team will satisfy your demand asap.
4. Before the order can be confirmed finally, we would strictly check the material, color, dimension of the sample step by step.
5. Our salesman, also as an order follower, would trace every phase of production from the beginning.
