Specifications
Brand Name :
Fansi
Model Number :
FANSI-PL01
Certification :
SO,CE
Place of Origin :
Anping China
MOQ :
50 sets
Price :
Negotiable
Supply Ability :
2000 sets per month
Delivery Time :
About 25-30 days after receiving the deposit.
Packaging Details :
pallets
Product name :
palisade fence
Fence height :
1.2m-3.0m
Style :
D pale,W pale,angle
Surface treatment :
hot dip galvanized,powder coating
Pale size :
62mm,65mm,68mm,70mm
Pale thickness :
2.0mm 2.5mm 3.0mm
Angle :
50x50mm
Angle thickness :
5.0mm 6.0mm
Post :
55x100mm SHS post
Application :
Home Decoration,Garden Decoration
Description
High Security Residential D Pale or W Pale Palisade Fence 1.8m high
Product Description
Palisade Fencing is the perfect solution to your boundary security fencing. As Palisade Fencing is supplied piece small it is
easily adapted to most site conditions.

Security Steel Palisade is supplied in kit form with the flexible design allowing the fence to be erected so that it follows the
contours of the ground forming a formidable deterrent against crime and vandalism. The kit form allows for easy installation.

It also comes in several different grades of materials. The thickness of the steel Palisade can be adjusted depending on the height of the fence and the sensitivity of the area the fence is situated in.
Specification
Height above ground
Suggested Pale Thickness (mm)
Posts
Post Height
Rails
Meter
"D"Section
"W"Section
1.8
3.0
2.0 to 3.0
100x50
2.325m
45 x 45 x 6
2.0
3.0
2.0 to 3.0
100x50
2.725m
45 x 45 x 6
2.1
3.0
2.0 to 3.0
100x50
2.725m
45 x 45 x 6
2.4
3.0 or 3.5
2.0 to 3.0
100x50
3.125m
50 x 50 x 6
3.0
3.0 or 3.5
2.0 to 3.0
100x50
3.925m
50 x 50 x 6
3.6
3.0 or 3.5
2.0 to 3.0
100x50
4.725m
65 x 50 x 6
Product Structure
1 fence set = 17 pales + 3 angle rails + 1 post+accessories (fish plates, bolts&nuts)
Product Types
Product Application
The Palisade Fence series is the perfect fusion of security and aesthetics, suitable for various settings, including industrial areas, commercial zones, schools, and residential spaces. Whether you seek a high-security fencing solution or wish to elevate your property’s design, the Palisade Fence is the ideal choice.
Packing & Delivery
Each piece of fence will be separated by plastic film, then the whole pallet will be wrapped with plastic film and then packed in containers. We can also pack according to customer’s requirements.
