Large Canopy Steel Structure Warehouse Packaging Workshop
Large Canopy Steel Structure Warehouse Packaging Workshop
Large Canopy Steel Structure Warehouse Packaging Workshop
Large Canopy Steel Structure Warehouse Packaging Workshop
Large Canopy Steel Structure Warehouse Packaging Workshop
Large Canopy Steel Structure Warehouse Packaging Workshop
Specifications
Brand Name :
Ruly Steel
Model Number :
Ruly0420
Certification :
SGS, BV, ISO
Place of Origin :
China
MOQ :
500 Square Meter
Price :
USD29-USD99 Per Square Meter
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20000 Square Meter Per Month
Delivery Time :
30 Days
Packaging Details :
As request
Application :
Steel Structure Packaging Workshop
Type :
Steel Frame Structure Buildings
Working scope :
Design,Fabrication, Installation
Raw steel material :
Q235B, Q355B
Surface treatment :
Painting
Shot blasting level :
Sa 2.5
Service life :
50 Years
Wall and Roof :
Glass wool
Description

Steel Structure Warehouse With Large Canopy/Steel Structure Packaging Workshop

This is a Steel Structure Warehouse With Large Canopy/Steel Structure Packaging Workshop. We could design and fabricate for the Poultry farm, livestock house building. The main steel frame structure could be light H-section steel, steel square tube, double-purlin. The surface treatment for steel structure components could be paint or hot dip galvanized.

Project information for Light Steel Frame Structure Buildings for Livestock House Building:

Name

Steel Structure Warehouse With Large Canopy/Steel Structure Packaging Workshop
Structure Type Portal frame, single ridge, two slopes,single span
Length 60 m
Width 25m
Eave Height 7m
Roof Slope 10%
Gable Wall Column Spacing 7.5m
Roof

steel cladding sheet
Wall steel cladding sheet
Height difference between indoor and outdoor 300mm

Service Life 50-70years Standard AISI, ASTM, BS, DIN,JIS
Place of Origin Qingdao,Shandong,China Material steel and sandwich panel
Grade Q235B, Q355B or as per customer's need Application workshop, warehouse, poultry house,garage etc.
Connection intensive bolt, ordinary bolt Bolt Grade M20, M16, M14 etc.
Downsput PVC pipe or as per customer's request Window PVC steel or aluminum alloy
Purlin C/Z shape profile Door sliding or rolling door
Main Frame welded or hot rolled H section steel, colum and beam Panel EPS/PU/fiber glass/rock wool
Delivery 30-40days Payment

TT,LC
Our service:

We could contract the projects such as prefabricated steel structure warehouse, workshop, storage sheds, garage, hangar, chicken shed, car parking, showroom, office buildings, gym, dormitory building, high rise steel residence buildings, oli&gas project, power station, infrastructure buildings, etc.

Large Canopy Steel Structure Warehouse Packaging Workshop

Packing and transport

All the structure components, panels,bolts and sort of accessories will bewell packed with standard package suitable ocean transportation and loaded into 40’HQ.

All the products are loaded at the loading site of our factory using crane and forklift by our skilled workers,who will prevent the goods to be damaged.

Large Canopy Steel Structure Warehouse Packaging Workshop

How to quote

The following question we need to know before making the price. Just feel free to fill what you know.

1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
lower than that of the former
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
