Q355B Metal Workshop Prefab Industrial Steel Buildings Frame Structure
Q355B Metal Workshop Prefab Industrial Steel Buildings Frame Structure
Q355B Metal Workshop Prefab Industrial Steel Buildings Frame Structure
Q355B Metal Workshop Prefab Industrial Steel Buildings Frame Structure
Specifications
Brand Name :
Ruly Steel
Model Number :
Ruly0288
Certification :
SGS, BV, ISO
Place of Origin :
China
MOQ :
500 Square Meter
Price :
USD29-USD99 Per Square Meter
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20000 Square Meter Per Month
Delivery Time :
30 Days
Packaging Details :
As request
Application :
Prefab Steel Industrial Building
Type :
Industrial Steel Buildings
Surface treatment :
Painting or Hot-dip Galvanize
Raw steel material :
Q235B, Q355B
Wall and Roof :
Glass wool
Working scope :
Design,Fabrication, Installation
Standard :
AISC, ASTM, BS, DIN, GB, JIS
Service life :
50 Years
Description

Metal Workshop BuildingPrefab Steel Industrial Building steel frame structure building

Products Description:

Steel Structure Warehouse Features
1.Steel structure construction quality light,high intensity, large span.
2.The construction period of steel structure constructionis short,and the investment cost is reduced accordingly.
3.Steel structure has high fireproof and corrosion resistance.
4.Steel structure buildings can be moved easily and no pollution is recovered.
5.The use rate of steel structure is very high.

Project information:

Main Steel Frame System
Main structure H section steel Q355, alkyd painting, two primary painting, two finish painting.
Roof purlin XZ160*60*20*2.5, galvanized
Wall purlin XZ160*60*20*2.5, galvanized
Intensive bolt Grade 10.9
Turn buckle bolt M20+2, steel Q235, processing
Anchor bolt M24, steel Q235, processing
Ordinary bolt Galvanized bolt M20
Ordinary bolt Galvanized bolt M12
Brace nut Galvanized bolt M12
Bracing System
Cross brace Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing Φ25 round steel bar Q235, process and painted (alkyd painting)
Tie bar Φ127*3 steel pipe Q235, process and painted (alkyd painting)
Batter brace Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)
Wall & Roof System
Roof panel Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Wall panel Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
Edge cover 0.5mm color plate, angle Alu.
Fittings & accessories Nails, glue etc.
Unpowered ventilator Diameter Φ600, stainless steel
Sky lighting band 1.2mm FRP, double layer
Sliding door sandwich panel door
Roof drainage system
Gutter 0.5mm color steel plate
Rainspout pipes Φ110 PVC pipe

Our steel structure production factory:

Q355B Metal Workshop Prefab Industrial Steel Buildings Frame StructureQ355B Metal Workshop Prefab Industrial Steel Buildings Frame Structure

Advantage :

* Easy to assemble and
* Eco-friendly material: Can be used for several times and can be
* Shorter construction period, longer using
* High strength and stiffness, high weight
* Delivery within 20 days and packing Wrapped in bundles by steel strips or as
* simple construction, low cost and light

Features:

* Design according to customers'
* Manufacture under complete quality control system---ISO9001.
* Size: Web plate 6MM---100MM; Flange plate 6-100MM; Or as customer's
* Materials: ASTM A572 Gr50/A36, S355JR, Q235B, Q355B or as per customer's
* Fabrication Standard: AWS 1
* Surface treatment: Hot Dipped Galvanized/Painting
* Welding Art: FCAW/GTAW/GMAW/MCAW/SAW/ESW/PAW/LBW
* Length: We can cut to any lengths as customer request.
