Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
Specifications
Brand Name :
LONGKUO METAL WIRE MESH
Place of Origin :
CHINA
MOQ :
1rolls
Price :
$6 ~ 99/roll
Payment Terms :
T/T, Western Union
Supply Ability :
100,000m2/year
Delivery Time :
About 7 work days depends on the supply
Packaging Details :
Plastic bag, Moistureproof paper and Wooden pallet
Product name :
Stainless Steel Woven Wire Mesh
Mesh Range :
1-500 MESH
Wire diameter :
0.025-2mm
Length :
30m/roll 50m/roll or as required
Width :
Usually1M,1.2m or others
Application :
Manufacturing
Weaving :
Plain/Twill/Dutch weave
Sample :
According to size
Package :
Kraft paper, plastic waterproof cloth, hard paper tube, woven bag, wooden case
Surface :
Polishing, plastic spraying, galvanizing and no treatment
Description

Durable SS 304 Primary Colour Stainless Steel Woven Wire Mesh

Stainless Steel Woven Wire Mesh Technology

Plain weave, twill weave, mat weave, resistance welding, etc.

1. Plain stainless steel mesh:

The most common weaving method is widely used in industrial production and civil life. The main feature is that the density of warp and weft diameter is the same.

2. Stainless steel square mesh

Material: galvanized iron wire, stainless steel wire, copper wire, aluminum wire, etc. Features: precise structure, uniform mesh, good corrosion resistance, strong and durable. Widely used in industry and construction industry, screening sand, filtering liquid and gas. It can also be used for the safety protection of mechanical accessories, and it can also be used to make walls and ceilings instead of wooden strips.

3. Stainless steel mat / dense mesh

Material: stainless steel wire, low carbon steel wire, nickel wire, copper wire, polyester wire, etc. Weaving: plain weave, twill weave, bamboo flower weave, contrast weave. Features: good filtering precision, high load intensity of contrast net. Application: used in aerospace, petroleum, chemical industry, scientific research and transportation industry, also can make lunch box net, coal washing net, etc.

Stainless Steel Woven Wire Mesh Usage

1. It is used for screening and filtration in acid and alkali environment. In petroleum industry, it is used for mud screen, chemical fiber industry, screen screen and electroplating.

2. Used in mining, petroleum, chemical, food, medicine, machinery manufacturing and other industries.

3. It is used for screening and filtering in acid and alkali environment. It is used for mud screen in petroleum industry, chemical fiber screen and acid washing screen in electroplating industry.

Stainless Steel Woven Wire Mesh Technical Parameters:

Square mesh, Plain weave or Twill weave
Aperture(mm) Wire diameter(mm) Mesh per inch(1inch=25.4mm) Open area(%) weight
W D MESH FO KG/M2
10.00 2.00 2.0 68 4.23
10.00 1.60 2.2 75 2.80
8.00 1.60 2.5 69 3.39
7.00 1.40 3.0 69 2.90
6.30 1.00 3.5 74 1.74
5.00 1.00 4.25 68 2.12
4.00 1.00 5.0 62 2.54
3.00 1.20 6.0 50 4.40
2.50 1.00 7.25 51 3.65
2.00 1.00 8.5 41 4.10
2.00 0.50 10.0 64 1.25
1.64 0.90 10.0 42 4.00
1.60 0.50 12.0 58 1.51
1.06 1.00 10.0 38 4.88
1.25 0.40 16.0 57 1.23
1.25 0.80 12.0 37 3.92
1.00 0.30 20.0 57 0.99
1.00 0.40 18.0 51 1.45
1.00 0.50 17.0 44 2.12
0.87 0.40 20 48 1.56
0.80 0.50 20 38 2.44
0.70 0.36 24 44 1.54
0.63 0.40 25 37 1.97
0.50 0.30 30 37 1.59
0.40 0.25 40 38 1.22
0.315 0.20 50 37 0.99
0.25 0.16 60 37 0.79
0.20 0.125 80 38 0.61
0.16 0.10 100 38 0.49
0.125 0.080 120 37 0.40
0.10 0.063 150 38 0.31
0.075 0.053 200 36 0.26
0.063 0.04 250 37 0.20
0.042 0.036 325 29 0.22
0.036 0.028 400 32 0.16
0.025 0.025 500 25 0.16

Stainless Steel Woven Wire Mesh Characteristics

Customized according to customer requirements:

Material: 201, 304, 304L, 316, 316L and other stainless steel wire etc.

Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire MeshStainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh

Stainless Steel SS 304 Plain Dutch Weave Fine Woven Wire Mesh
