Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
Specifications
Brand Name :
LONGKUO METAL WIRE MESH
Place of Origin :
CHINA
MOQ :
1rolls
Price :
$6 ~ 99/roll
Payment Terms :
T/T, Western Union
Supply Ability :
100,000m2/year
Delivery Time :
About 7 work days depends on the supply
Packaging Details :
Plastic bag, Moistureproof paper and Wooden pallet
Product name :
Stainless Steel Woven Wire Mesh
Length :
30m/roll 50m/roll or as required
Width :
Usually1M,1.2m or others
Weave style :
Plain/Twill/Dutch weave
Sample :
According to size
Surface treatment :
Polishing, plastic spraying, galvanizing and no treatment
Application :
Manufacturing
Packing :
Kraft paper, plastic waterproof cloth, hard paper tube, woven bag, wooden case
Hole shape :
Square Hole
Usage :
Filter
Description

SS 201 Natural Colour Filtration Stainless Steel Woven Wire Mesh

Stainless Steel Woven Wire Mesh Service

Our company has a large number of regular specifications of stock, according to customer requirements for production and processing and customization.

Stainless Steel Woven Wire Mesh Surface treatment:

Electropolishing, ring resin, electrostatic spraying, metal plating, ultrasonic, etc.

Stainless Steel Woven Wire Mesh Company Introduction

Our factory is a chemical factory integrating production, sales, wholesale and retail. All products are provided with one-stop service. From wire drawing, mesh weaving, deep processing and inspection, we operate independently. All materials, sizes and specifications can be customized according to customer requirements. It is one of the largest manufacturers of stainless steel wire mesh in China. We have a large stock of many popular standard items.

Stainless Steel Woven Wire Mesh Technology

Plain weave, twill weave, mat weave, resistance welding, etc.

1. Plain stainless steel mesh:

The most common weaving method is widely used in industrial production and civil life. The main feature is that the density of warp and weft diameter is the same.

2. Stainless steel square mesh

Material: galvanized iron wire, stainless steel wire, copper wire, aluminum wire, etc. Features: precise structure, uniform mesh, good corrosion resistance, strong and durable. Widely used in industry and construction industry, screening sand, filtering liquid and gas. It can also be used for the safety protection of mechanical accessories, and it can also be used to make walls and ceilings instead of wooden strips.

3. Stainless steel mat / dense mesh

Material: stainless steel wire, low carbon steel wire, nickel wire, copper wire, polyester wire, etc. Weaving: plain weave, twill weave, bamboo flower weave, contrast weave. Features: good filtering precision, high load intensity of contrast net. Application: used in aerospace, petroleum, chemical industry, scientific research and transportation industry, also can make lunch box net, coal washing net, etc.

Stainless Steel Woven Wire Mesh Technical Parameters:

Square mesh, Plain weave or Twill weave
Aperture(mm) Wire diameter(mm) Mesh per inch(1inch=25.4mm) Open area(%) weight
W D MESH FO KG/M2
10.00 2.00 2.0 68 4.23
10.00 1.60 2.2 75 2.80
8.00 1.60 2.5 69 3.39
7.00 1.40 3.0 69 2.90
6.30 1.00 3.5 74 1.74
5.00 1.00 4.25 68 2.12
4.00 1.00 5.0 62 2.54
3.00 1.20 6.0 50 4.40
2.50 1.00 7.25 51 3.65
2.00 1.00 8.5 41 4.10
2.00 0.50 10.0 64 1.25
1.64 0.90 10.0 42 4.00
1.60 0.50 12.0 58 1.51
1.06 1.00 10.0 38 4.88
1.25 0.40 16.0 57 1.23
1.25 0.80 12.0 37 3.92
1.00 0.30 20.0 57 0.99
1.00 0.40 18.0 51 1.45
1.00 0.50 17.0 44 2.12
0.87 0.40 20 48 1.56
0.80 0.50 20 38 2.44
0.70 0.36 24 44 1.54
0.63 0.40 25 37 1.97
0.50 0.30 30 37 1.59
0.40 0.25 40 38 1.22
0.315 0.20 50 37 0.99
0.25 0.16 60 37 0.79
0.20 0.125 80 38 0.61
0.16 0.10 100 38 0.49
0.125 0.080 120 37 0.40
0.10 0.063 150 38 0.31
0.075 0.053 200 36 0.26
0.063 0.04 250 37 0.20
0.042 0.036 325 29 0.22
0.036 0.028 400 32 0.16
0.025 0.025 500 25 0.16

Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh

Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh

Natural Colour SS 201 Wire Filter Screen Stainless Steel Gauze Mesh
