High Speed Ball Bearing 7208 2RZ P4 Angular Contact Thrust Bearing
High Speed Ball Bearing 7208 2RZ P4 Angular Contact Thrust Bearing
High Speed Ball Bearing 7208 2RZ P4 Angular Contact Thrust Bearing
High Speed Ball Bearing 7208 2RZ P4 Angular Contact Thrust Bearing
Specifications
Brand Name :
deep dream
Model Number :
7208
Place of Origin :
Shaanxi, China
MOQ :
1 PCS
Payment Terms :
Western Union, T/T
Supply Ability :
200000 pcs per day
Packaging Details :
1.Single box: plastic bag+single box, OEM supply 2.Single wooden box: plastic bag+single wooden box 3.Carton: Standard export carton(30*108*38.1MM) or as your need. 4.Pallet: Wooden pallet with plastic film against moisture. 5.Pallet size: 1.2m*1m 6.Packag
Product name :
Angular Contanct Ball Bearings
Type name :
7208
Service :
OEM Customized Services
Size :
40*80*18mm
Package :
Original Package
Seals type :
ZZ 2RS OPEN
Feature :
High Speed,low noise
Description

High Speed Machine Bearing 7208 2RZ/P4 Angular Contact Ball Bearing 7208 Bearing

Description: of Angular Contact Ball Bearing

Angular contact ball bearings can support both radial and axial loads. Can work at a higher speed. The greater the contact angle, the higher the axial load carrying capacity. High-precision and high-speed bearings usually take 15 degrees contact angle.

In the axial force, the contact angle will increase. Angular contact ball bearings have four cages: brass cage, nylon cage, bakelite cage and steel cage, have single row and double row bearings. have open type, rubber sealed and steel sealed.

7207 bearing is angular contact ball bearing, high speed precision angular contact ball bearing installation method: high speed precision angular contact ball bearing, mainly used in light load of high speed rotation occasions, bearings require high precision, high speed, low temperature rise low vibration and a certain service life.The supports, which are often used as high-speed motorized spindles, are used in pairs and are the key accessories for high-speed motorized spindles of inner surface grinder.

Specifications: of Angular Contact Ball Bearing 7208

Product Name
Premium Angular Contact Ball Bearing 7208
Brand
Deep dream&OEM
Model No
7208
Sizes(mm)
40*80*18mm
Material
Chrome Steel, Bearing steel; GCr15; carbon steel, brass
Sealed Type
2RS rubber seals/ ZZ metal shields/Open
Precision
P0, P5, P6
Clearance
C0, C2, C3, C4
Packing
Original Package

Model Number
Dimension (mm)
Basic Load Rating (KN)
d
D
B
r
r1
Cr
Cor
7200C
10
30
9
0.6
0.6
5.85
2.9
7200AC
10
30
9
0.6
0.6
5.6
2.8
7201C
12
32
10
0.6
0.6
7.65
3.9
7201AC
12
32
10
0.6
0.6
7.35
3.75
7202C
15
35
11
0.6
0.6
9.65
5
7202AC
15
35
11
0.6
0.6
9.3
4.8
7203C
17
40
12
0.6
0.6
10.8
5.85
7203AC
17
40
12
0.6
0.6
10.4
5.6
7204C
20
47
14
1
1
14.6
8.15
7204AC
20
47
14
1
1
14
7.8
7205C
25
52
15
1
1
15.6
9.9
7205AC
25
52
15
1
1
15
9
7206C
30
62
16
1
1
23.3
14.6
7206AC
30
62
16
1
1
22
14
7207C
35
72
17
1.1
1.1
25.5
18
7207AC
35
72
17
1.1
1.1
24.5
17
7208C
40
80
18
1.1
1.1
32
22.4
7208AC
40
80
18
1.1
1.1
30.5
21.6
7209C
45
85
19
1.1
1.1
33.5
24.5
7209AC
45
85
19
1.1
1.1
32
23.6
7210C
50
90
20
1.1
1.1
43
31.5
7210AC
50
90
20
1.1
1.1
40.5
30.5
7211C
55
100
21
1.5
1.5
46.5
37.5
7211AC
55
100
21
1.5
1.5
44
35.5
7212C
60
111
22
1.5
1.5
55
44
7212AC
60
111
22
1.5
1.5
52
42.5
7213C
65
120
23
1.5
1.5
57
48
7213AC
65
120
23
1.5
1.5
54
45.5
7214C
70
125
24
1.5
1.5
69.5
58.5
7214AC
70
125
24
1.5
1.5
65.5
56
7215C
75
130
25
1.5
1.5
72
63
7215AC
75
130
25
1.5
1.5
68
60
7216C
80
140
26
2
2
73.5
68
7216AC
80
140
26
2
2
71
64
7217C
85
150
28
2
2
96.5
85
7217AC
85
150
28
2
2
91.5
80
7218C
90
160
30
2
2
122
104
7218AC
90
160
30
2
2
116
100
7219C
95
170
32
2.1
2.1
127
114
7219AC
95
170
32
2.1
2.1
122
108
7220C
100
180
34
2.1
2.1
132
122
7220AC
100
180
34
2.1
2.1
125
116
7221C
105
190
36
2.1
2.1
163
146
7221AC
105
190
36
2.1
2.1
156
140
7222C
110
200
38
2.1
2.1
163
150
7222AC
110
200
38
2.1
2.1
153
143
7224C
120
215
40
2.1
2.1
204
196
7224AC
120
215
40
2.1
2.1
19*6
186
7226C
130
230
40
3
3
212
216
7226AC
130
230
40
3
3
204
204

Why Choose Us:

1. High speed, High Precision, Low Noise, Long Service Life
2. Widely used
3. Large Inventories
4. High Quality and Competitive Prices
5. Various Brands
6. OEM is supported

Applications:

Bearings are mainly used for automobile steering mechanism, machine tool spindle.

High Speed Ball Bearing 7208 2RZ P4 Angular Contact Thrust Bearing

FAQ

1. who are we?
We are based in Shaanxi, China, start from 2019,sell to North America(17.00%),Eastern Asia(15.00%),Domestic Market(12.00%),Eastern Europe(10.00%),Western Europe(10.00%),South Asia(5.00%),Southeast Asia(5.00%),South America(5.00%),Northern Europe(5.00%),Oceania(5.00%),Mid East(4.00%),Southern Europe(3.00%),Africa(2.00%),Central America(2.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
deep groove ball bearing,needle rollerbearing,bearings, pillow block bearing,tapered roller bearing

4. why should you buy from us not from other suppliers?
Our company is located in Xi'An, China. With advanced science and technology R&D team, strong marketing and financial support, sound after-sales service, professional engineers, we will supply you goods with high quality and good service.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,HKD,CNY;
Accepted Payment Type: T/T,PayPal,Western Union;
Language Spoken:English,Chinese
