Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards
Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards
Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards
Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards
Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards
Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards
Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards
Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards
Specifications
Brand Name :
deep dream
Model Number :
681
Place of Origin :
Shaanxi, China
MOQ :
10 PCS
Payment Terms :
Western Union, T/T
Supply Ability :
200000 pcs per day
Packaging Details :
1.Single box: plastic bag+single box, OEM supply 2.Single wooden box: plastic bag+single wooden box 3.Carton: Standard export carton(30*108*38.1MM) or as your need. 4.Pallet: Wooden pallet with plastic film against moisture. 5.Pallet size: 1.2m*1m 6.Packag
Product name :
Miniature Ball Bearings
Type name :
681
Service :
OEM or customer logo acceptable
Size :
1*3*1mm
Material :
Chrome steel, Gcr15
Application :
for roller skating fingerboards
Feature :
High quality, high speed, low noise
Description

Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards

Description: of Deep Groove Ball Bearing 681

The miniature deep groove ball bearing is installed on the shaft, within the axial clearance range of the bearing, it can limit the axial displacement of the shaft or housing in two directions, so it can be positioned axially in two directions. In addition, this kind of bearing also has a certain self-aligning ability. When the bearing is inclined 2'~10' relative to the shell hole, it can still work normally, but it will have a certain impact on the bearing life.
Miniature stainless steel bearing materials mainly include 420, 440, 304, 316

Specifications: of Deep Groove Ball Bearing 681

Product Name
Miniature Ball Bearings 681 Miniature Ball Bearings for Roller Skate Fingerboards
Brand
OEM
Model No
681
Sizes(mm)1
1*3*1mm
Material
Chrome steel, Gcr15, stainless steel
Sealed Type
2RS rubber seals/ ZZ metal shields
Precision
P0,P6,P5,P4
Clearance

C0 C2 C3 C4
Features
High Temperature Resistance,low noise, long life

内径 (D) 外径 (D) 高 度 倒角(r) 基本 动负荷 CrtNIBasic Dynamic 基本 静负荷 CorlN)Bask Static .扱.限转速 Limiting Speed 型号 Reference
开放型 (B) Open 防尘盖型 (B1 ) Shield 开放员 Open 防尘蓋型 Shield 润滑脂 Grase 润滑剤 Oil 开放型 Open 防尘盖型 Shield
,100( Irpm
3 1 - 0.05 — 80 23 130 150 681 —
1 3 1.5 - 0.05 - -
4 1.6 - 0.1 — 140 36 100 120 691 —
4 1.2 2 0.05 0.05 112 33 100 120 681X 681XZZ
1.5 5 2 2.6 0.15 0.15 237 69 85 100 691X 691Xzz
6 2.5 3 0.15 0.15 330 98 75 90 601X 601 Xzz
5 1.5 2.3 0.08 0.08 169 50 85 100 682 682zz
5 2 2.5 0.1 0.1 169 50 85 100 MR52 MR52zz
6 2.3 3 0.15 0.15 330 98 75 90 692 692zz
d 6 2.5 2.5 0.15 0.15 330 98 75 90 MR62 MR62zz
7 2.5 3 0.15 0.15 385 127 63 75 MR72 MR72zz
7 2.8 3.5 0.15 0.15 385 127 63 75 602 602zz
6 1.8 2.6 0.08 0.08 208 74 71 80 682X 682Xzz
2.5 7 2.5 3.5 0.15 0.15 385 127 63 75 692X 692Xzz
8 2.5 - 0.2 — 560 179 60 67 MR82X —
8 2.8 4 0.15 0.15 550 175 60 71 602X 602XZZ
6 2 2.5 0.1 0.1 208 74 71 80 MR63 MR63zz
7 2 3 0.1 0.1 310 111 63 75 683 683zz
8 2.5 - 0.15 - 560 179 60 67 MR83 MR83zz
8 3 4 0.15 0.15 560 179 60 67 693 693zz
3 9 2.5 4 0.2 0.2 570 187 56 67 MR93 MR93ZZ
9 3 - 0.15 - 570 187 56 67 603 603zz
10 4 4 0.15 0.15 630 218 50 60 623 623zz
13 5 5 0.2 0.2 1300 405 40 48 633 633zz
7 2 2.5 0.1 0.1 310 115 60 67 MR74 MR74ZZ
8 2 3 0.15 0.15 395 139 56 67 MR84 MR84zz
9 2.5 4 0.1 0.1 640 225 53 63 684 684zz
10 3 4 0.2 0.2 585 204 48 56 MR104 MR104ZZ
4 11 4 4 0.15 0.15 960 345 48 56 694 694zz
12 4 4 0.2 0.2 960 345 48 56 604 604zz
13 5 5 0.2 0.2 1300 485 40 48 624 624zz
16 5 5 0.3 0.3 1730 670 36 43 634 634zz


Advantage:

1. With a High Load-Bearing Capacity
2. Low Noise and More Quiet
3. Long Life,Stable Performance and Durable
4. Have Low Rolling Resistance and Work in Sub-Zero Temperatures

Our Services:

1.We can offer a various kind of bearing with top quality.
2.Promptness in technical support pre- and after sales.
3.We can supply the samples (some for free).
4. OEM for our customers.
5.Prompt delivery time.

Applications:

Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards

Miniature Ball Bearings 1*3*1mm 681 681 ZZ Miniature Deep Groove Ball Bearings For Roller Skating Fingerboards

FAQ

1. who are we?
We are headquartered in Shaanxi, China, and from 2019, we sell to North America (17.00%), East Asia (15.00%), domestic market (12.00%), Eastern Europe (10.00%), Western Europe (10.00%), South Asia (5.00%) , Southeast Asia (5.00%), South America (5.00%), Northern Europe (5.00%), Oceania (5.00%), Middle East (4.00%), Southern Europe (3.00%), Africa (2.00%), and Central America (2.00%). We have around 11-50 people in total in the office.


2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
deep groove ball bearing,needle rollerbearing,bearings, pillow block bearing,tapered roller bearing

4. why should you buy from us not from other suppliers?
Our company is located in Xi'An, China. With advanced science and technology R&D team, strong marketing and financial support, sound after-sales service, professional engineers, we will supply you goods with high quality and good service.
