15x40x15.9mm Steel U Groove Wheels LFR5202KDD Roller Track Bearing High Quality LR Series
15x40x15.9mm Steel U Groove Wheels LFR5202KDD Roller Track Bearing High Quality LR Series
15x40x15.9mm Steel U Groove Wheels LFR5202KDD Roller Track Bearing High Quality LR Series
15x40x15.9mm Steel U Groove Wheels LFR5202KDD Roller Track Bearing High Quality LR Series
Specifications
Brand Name :
deep dream
Model Number :
LFR5202KDD
Place of Origin :
Shaanxi, China
MOQ :
10 PCS
Payment Terms :
Western Union, T/T
Supply Ability :
200000 pcs per day
Packaging Details :
1.Single box: plastic bag+single box, OEM supply 2.Single wooden box: plastic bag+single wooden box 3.Carton: Standard export carton(30*108*38.1MM) or as your need. 4.Pallet: Wooden pallet with plastic film against moisture. 5.Pallet size: 1.2m*1m 6.Packag
Product name :
Track Roller Bearing
Type name :
LFR5202KDD
Service :
OEM Customized Services
Size :
15*40*15.9mm
Package :
Original Package
Material :
Chrome Steel GCR15
Seals type :
ZZ 2RS OPEN
Description

High Quality LR Series U-Groove Guide Bearing LFR5202KDD 15*40*15.9mm Track Roller Bearing

Description: of Track Roller Bearing

High allowable speed, low resistance, long life The outer ring surface of the LFR series guide rail roller is designed into a Gothic shape, so that when the roller is working, the roller and the guide rail form two-point contact with an angle of 60 degrees. The friction resistance is small and the load is even. It avoids the installation and The stress concentration and boundary effects caused by manufacturing errors make the guide rail system have the characteristics of high speed, low energy consumption and long life.

● LFR series guide rail roller bearings are the most widely used, economical and practical products among linear guide rollers. They can be adapted to cylindrical guide rails with stable operation, small error, extremely low operating noise and high operating speed.
● The contact between the roller and the guide rail is two-point 60-degree contact, which has good contact performance and low running resistance, so as to achieve a relatively long service life.
● The roller adopts the internal structure design of double row angular contact ball bearing and the thickened outer ring, so that the roller has a higher load-carrying capacity. The roller bearing is equipped with an eccentric wheel and a concentric shaft and is easy to install.
● The rollers are made of high-quality bearing steel or stainless steel,
processed by heat treatment and precision grinding, and filled with long-life, high-quality, multi-purpose grease. The roller
dust-proof adopts metal dust cover (KDD) or rubber sealing ring (NPP).

Specifications: of Track Roller Bearing

Product Name
Track Roller Bearing
Brand
Deep dream&OEM
Model No
 LFR5202KDD
Sizes(mm)
15*40*15.9mm
Material
Chrome Steel, Bearing steel; GCr15; carbon steel, brass
Sealed Type
2RS rubber seals/ ZZ metal shields/Open
Precision
P0, P5, P6
Clearance
C0, C2, C3, C4
Packing
Original Package

Roller NO.
Dimensions(mm)
Load Ratings
W(g)
dw
d
D
C
B
A
Cw(KN)
Cow(KN)
LFR5200KDD
50
8
10
32
14
14
18
5.6
3.6
LFR5201KDD
68
10
12
35
15.9
15.9
20.65
8.5
5.1
LFR5201KDD-12KDD
68
12
12
35
15.9
15.9
21.75
8.5
5.1
LFR5201KDD-14KDD
107
14
12
39.9
20
19
24
8.9
5
LFR5301KDD
130
10
12
42
19
15.9
24
13
7.7
LFR5202KDD
80
12
15
40
15.9
19
23.4
10
7.8
LFR5302KDD
163
10
15
47
19
20
26.65
16.2
9.2
LFR5204KDD
195
16
20
52
20.6
20.6
31
16.8
9.5

Advantage:
1. High speed, high precision
2. Long service life
3. Low noise and good performance

Why Choose Us:
1. High speed, High Precision, Low Noise, Long Service Life
2. Widely used
3. Large Inventories
4. High Quality and Competitive Prices
5. Various Brands
6. OEM is supported

Applications:
SG series guide roller and LFR series guide roller bearing performance, the unique "sink head" design makes SG series guide roller mainly applied to the flat surface, especially compact roller mounting space, and form a complete set of guide roller fixed bearing loaded after the guide roller does not highlight or little highlight to the bearing plane. Used in embroidery machines, CNC equipment.
U-groove bearings are widely used in house

15x40x15.9mm Steel U Groove Wheels LFR5202KDD Roller Track Bearing High Quality LR Series
FAQ
1. who are we?
We are based in Shaanxi, China, start from 2019,sell to North America(17.00%),Eastern Asia(15.00%),Domestic Market(12.00%),Eastern Europe(10.00%),Western Europe(10.00%),South Asia(5.00%),Southeast Asia(5.00%),South America(5.00%),Northern Europe(5.00%),Oceania(5.00%),Mid East(4.00%),Southern Europe(3.00%),Africa(2.00%),Central America(2.00%). There are total about 11-50 people in our office.


2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;


3.what can you buy from us?
deep groove ball bearing,needle rollerbearing,bearings, pillow block bearing,tapered roller bearing


4. why should you buy from us not from other suppliers?
Our company is located in Xi'An, China. With advanced science and technology R&D team, strong marketing and financial support, sound after-sales service, professional engineers, we will supply you goods with high quality and good service.
