7210C Axial Angular Contact Roller Bearings Single Row Machinery 7210 Bearing 7210AC
7210C Axial Angular Contact Roller Bearings Single Row Machinery 7210 Bearing 7210AC
7210C Axial Angular Contact Roller Bearings Single Row Machinery 7210 Bearing 7210AC
7210C Axial Angular Contact Roller Bearings Single Row Machinery 7210 Bearing 7210AC
Specifications
Brand Name :
deep dream
Model Number :
7410
Place of Origin :
Shaanxi, China
MOQ :
1 PCS
Payment Terms :
Western Union, T/T
Supply Ability :
200000 pcs per day
Packaging Details :
1.Single box: plastic bag+single box, OEM supply 2.Single wooden box: plastic bag+single wooden box 3.Carton: Standard export carton(30*108*38.1MM) or as your need. 4.Pallet: Wooden pallet with plastic film against moisture. 5.Pallet size: 1.2m*1m 6.Packag
Product name :
Angular Contanct Ball Bearings
Type name :
7410
Service :
OEM Customized Services
Size :
50*90*20mm
Package :
Original Package
Seals type :
ZZ 2RS OPEN
Feature :
High Speed,low noise
Description

Angular Contact Bearing Used In Machinery Plant Single Row Ball Bearing 7210C Angular Contact Bearing 7210AC

Description: of Angular Contact Ball Bearing

Axial angular contact ball bearings are precision bearings for screw drive bearing arrangements. Depending on the series, they can support radial forces as well as axial forces in one or both directions. Contact seals protect the rolling element system against contamination and moisture. For higher speeds, non-contact minimal gap seals can be used.Bearing is an important part of contemporary machinery and equipment. Its main function is to support the mechanical rotating body, reduce the friction coefficient during its movement, and ensure its rotation accuracy. According to the different friction properties of the moving elements, bearings can be divided into rolling bearings and sliding bearings. Single row angular contact ball bearings can accommodate axial loads in one direction only. This type of bearing is typically adjusted against a second bearing. Their bearing rings have an upper and a lower shoulder and are non-separable.

Angular contact ball bearings have inner and outer ring raceways that are displaced relative to each other in the direction of the
bearing axis. This means that these bearings are designed to accommodate combined loads, i.e. simultaneously acting radial and
axial loads.

Specifications: of Angular Contact Ball Bearing 7410

Product Name
Premium Angular Contact Ball Bearing
Brand
Deep dream&OEM
Model No
7410
Sizes(mm)
50*90*20mm
Material
Chrome Steel, Bearing steel; GCr15; carbon steel, brass
Sealed Type
2RS rubber seals/ ZZ metal shields/Open
Precision
P0, P5, P6
Clearance
C0, C2, C3, C4
Packing
Original Package

Model Number
Dimension (mm)
Basic Load Rating (KN)
d
D
B
r
r1
Cr
Cor
7200C
10
30
9
0.6
0.6
5.85
2.9
7200AC
10
30
9
0.6
0.6
5.6
2.8
7201C
12
32
10
0.6
0.6
7.65
3.9
7201AC
12
32
10
0.6
0.6
7.35
3.75
7202C
15
35
11
0.6
0.6
9.65
5
7202AC
15
35
11
0.6
0.6
9.3
4.8
7203C
17
40
12
0.6
0.6
10.8
5.85
7203AC
17
40
12
0.6
0.6
10.4
5.6
7204C
20
47
14
1
1
14.6
8.15
7204AC
20
47
14
1
1
14
7.8
7205C
25
52
15
1
1
15.6
9.9
7205AC
25
52
15
1
1
15
9
7206C
30
62
16
1
1
23.3
14.6
7206AC
30
62
16
1
1
22
14
7207C
35
72
17
1.1
1.1
25.5
18
7207AC
35
72
17
1.1
1.1
24.5
17
7208C
40
80
18
1.1
1.1
32
22.4
7208AC
40
80
18
1.1
1.1
30.5
21.6
7209C
45
85
19
1.1
1.1
33.5
24.5
7209AC
45
85
19
1.1
1.1
32
23.6
7210C
50
90
20
1.1
1.1
43
31.5
7210AC
50
90
20
1.1
1.1
40.5
30.5
7211C
55
100
21
1.5
1.5
46.5
37.5
7211AC
55
100
21
1.5
1.5
44
35.5
7212C
60
111
22
1.5
1.5
55
44
7212AC
60
111
22
1.5
1.5
52
42.5
7213C
65
120
23
1.5
1.5
57
48
7213AC
65
120
23
1.5
1.5
54
45.5
7214C
70
125
24
1.5
1.5
69.5
58.5
7214AC
70
125
24
1.5
1.5
65.5
56
7215C
75
130
25
1.5
1.5
72
63
7215AC
75
130
25
1.5
1.5
68
60
7216C
80
140
26
2
2
73.5
68
7216AC
80
140
26
2
2
71
64
7217C
85
150
28
2
2
96.5
85
7217AC
85
150
28
2
2
91.5
80
7218C
90
160
30
2
2
122
104
7218AC
90
160
30
2
2
116
100
7219C
95
170
32
2.1
2.1
127
114
7219AC
95
170
32
2.1
2.1
122
108
7220C
100
180
34
2.1
2.1
132
122
7220AC
100
180
34
2.1
2.1
125
116
7221C
105
190
36
2.1
2.1
163
146
7221AC
105
190
36
2.1
2.1
156
140
7222C
110
200
38
2.1
2.1
163
150
7222AC
110
200
38
2.1
2.1
153
143
7224C
120
215
40
2.1
2.1
204
196
7224AC
120
215
40
2.1
2.1
19*6
186
7226C
130
230
40
3
3
212
216
7226AC
130
230
40
3
3
204
204

Why Choose Us:

1. High speed, High Precision, Low Noise, Long Service Life
2. Widely used
3. Large Inventories
4. High Quality and Competitive Prices
5. Various Brands
6. OEM is supported

Applications:

Bearings are mainly used for automobile steering mechanism, machine tool spindle.

7210C Axial Angular Contact Roller Bearings Single Row Machinery 7210 Bearing 7210AC

FAQ

1. who are we?
We are based in Shaanxi, China, start from 2019,sell to North America(17.00%),Eastern Asia(15.00%),Domestic Market(12.00%),Eastern Europe(10.00%),Western Europe(10.00%),South Asia(5.00%),Southeast Asia(5.00%),South America(5.00%),Northern Europe(5.00%),Oceania(5.00%),Mid East(4.00%),Southern Europe(3.00%),Africa(2.00%),Central America(2.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
deep groove ball bearing,needle rollerbearing,bearings, pillow block bearing,tapered roller bearing

4. why should you buy from us not from other suppliers?
Our company is located in Xi'An, China. With advanced science and technology R&D team, strong marketing and financial support, sound after-sales service, professional engineers, we will supply you goods with high quality and good service.
