CSK40 PP Deep Groove Ball Bearing One Way Clutch Bearing 40 X 78 X 22mm
CSK40 PP Deep Groove Ball Bearing One Way Clutch Bearing 40 X 78 X 22mm
CSK40 PP Deep Groove Ball Bearing One Way Clutch Bearing 40 X 78 X 22mm
CSK40 PP Deep Groove Ball Bearing One Way Clutch Bearing 40 X 78 X 22mm
CSK40 PP Deep Groove Ball Bearing One Way Clutch Bearing 40 X 78 X 22mm
CSK40 PP Deep Groove Ball Bearing One Way Clutch Bearing 40 X 78 X 22mm
Specifications
Brand Name :
deep dream
Model Number :
CSK40
Place of Origin :
Shaanxi, China
MOQ :
1 PCS
Payment Terms :
Western Union, T/T
Supply Ability :
200000 pcs per day
Packaging Details :
1.Single box: plastic bag+single box, OEM supply 2.Single wooden box: plastic bag+single wooden box 3.Carton: Standard export carton(30*108*38.1MM) or as your need. 4.Pallet: Wooden pallet with plastic film against moisture. 5.Pallet size: 1.2m*1m 6.Packag
Product name :
Deep Groove Ball Bearings
Material :
Chrome Steel/GCr15 Stainless Steel
Service :
OEM Customized Services
Type :
CSK40
Seals Type :
ZZ,2RS,RS,open
Feature :
Long Life High Speed
Size :
40*78*22mm
Description

One-Way CSK40 Clutch Bearing CSK40 PP Deep Groove Ball Bearing 40*78*22mm

Description: of deep groove ball bearing CSK40

CSK series one way bearing is a sprag type freewheel , integrated into 6200 series ball bearing(except sizes 8 and 40), Also named OW BB KK etc. It provides you an one way clutch, and eliminates the need for a ball bearing. gives a high degree of freewheeling accuracy while utilizing a minimum of space. It is bearing supported, shipped grease lubricated and protected against dust larger than 0.3mm diameter. Torque transmission is ensured by a press fit assembly into a rigid with N6 outer housing, and onto a shaft with n6 tolerance. The initial bearing radial clearance is set at C5, and is reduced if using the press fit as specified. Operating temperature range: -20°C to +100°C. Peaks up to +120°C are acceptable for shorter periods.

Specifications: of deep groove ball bearing CSK40

PRODUCT NAME
One-Way CSK40 Clutch Bearing CSK40 PP Deep Groove Ball Bearing 40*18*22mm
MODEL NUMBER
 CSK40
Precision Grade
P0 P6 P5 P4 P2
Bearing Seal
2RS 2Z OPEN
Dimensions
40*78*22mm
MATERIAL
Chrome Steel GCR15
CAGE MATERIAL
Steel or nylon
Our market
Our products have been exported to the Mainland China, Europe, Africa,
South America, North America

TYPE keyway Dimensions(mm) Nominal torgue weight
GERMANY JAPAN AND OTHER d D B N.m KG
CSK8 BB8 KK8 OW8 P PP 8 22 9 2.5 0.015
CSK10 BB10 KK10 OW10 P PP 10 30 9 5 0.032
CSK12 BB12 KK12 OW12 P PP 12 32 10 10 0.04
CSK15 BB15 KK15 OW15 P PP 15 35 11 30 0.05
CSK17 BB17 KK17 OW17 P PP 17 40 12 48 0.07
CSK20 BB20 KK20 OW20 P PP 20 47 14 60 0.11
CSK25 BB25 KK25 OW25 P PP 25 52 15 80 0.14
CSK30 BB30 KK30 OW30 P PP 30 62 16 100 0.21
CSK35 BB35 KK35 OW35 P PP 35 72 17 123 0.30
CSK40 BB40 KK40 OW40 P PP 40 78 22 260

0.50

Why Choose Us:

1. High speed, High Precision, Low Noise, Long Service Life
2. Widely used
3. Large Inventories
4. High Quality and Competitive Prices
5. Various Brands
6. OEM is supported

Application of Deep groove ball bearing :

One side of the inner ring or the outer ring can be fixed by glue. If both sides of the inner and outer rings are fixed with glue, the function will be reduced. If you do not want to use the tight fitting method, you can use CSK-P series C3 bearing to install the effect. Widely used in printing machinery, packaging machinery, food machinery, electric drums, electric motorcycles, fitness equipment, reducers and test equipment, belt conveyors, lifting cranes, textile machinery and other equipment, greatly improving the operation of equipment Safety and reliability.

CSK40 PP Deep Groove Ball Bearing One Way Clutch Bearing 40 X 78 X 22mm

FAQ

1. who are we?
We are based in Shaanxi, China, start from 2019,sell to North America(17.00%),Eastern Asia(15.00%),Domestic Market(12.00%),Eastern Europe(10.00%),Western Europe(10.00%),South Asia(5.00%),Southeast Asia(5.00%),South America(5.00%),Northern Europe(5.00%),Oceania(5.00%),Mid East(4.00%),Southern Europe(3.00%),Africa(2.00%),Central America(2.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
deep groove ball bearing,needle rollerbearing,bearings, pillow block bearing

4. why should you buy from us not from other suppliers?
Our company is located in Xi'An, China. With advanced science and technology R&D team, strong marketing and financial support, sound after-sales service, professional engineers, we will supply you goods with high quality and good service.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,HKD,CNY;
Accepted Payment Type: T/T,PayPal,Western Union;
Language Spoken:English,Chinese
