Specifications
Brand Name :
RILANT
Model Number :
SZR-650
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 sets per month
Delivery Time :
45 working days
Packaging Details :
Standard export package
Use :
Roof,furring channel roll foming machine,door frame,cable tray machine,Vineyard Grape Stake
Voltage :
380V 50Hz 3phases
Condition :
New
Dimension(l*w*h) :
6500*1300*1100
After-sales service provided :
Engineers available to service machinery overseas
Weight :
2T
Power(w) :
5.5 KW
Control system :
PLC
Roller material :
coated with chrome,45# steel,45#steel,Cr12,High grade #45 steel with hard chromed
Warranty :
1 Year
Product name :
Roll forming machine prices
Color :
Client's Request
Shaft material :
high grade 45# steel
Usage :
Roof Profile,Construction,roof tile panel
Raw material :
PPGI,PPGI/Galvanized sheet
Cutting blade material :
Cr 12,Cr12Mov with quench HRC58-62°
Thickness :
1.2-2mm
Life time :
10 YEARS
Description

Steel Frame & Purlin Machine C Z Cold Roll Forming Machine Square Round Down Pipe Production Line

Description: Downspout pipe roll forming machine could be used to make downspout pipes in a higher speed and good quality by 16 years in this area. For this machine, we take guide column frame style to make machine for making sure machine working speed and steady. And for the transmission, we will use gearbox with chain.

Product Name
Steel Frame & Purlin Machine C Z Purlin Cold Roll Forming Machine
Place of Origin
Jiangsu, China
Size
9500*800*1200
Width of the plate
210mm - 540mm
Weight
6.5Tons
Processing Speed
10-12m/min
Control system
PLC control panel
Power
380V 50Hz (as per local requirement)

Basic Technical Information:

Uncoiler: Manual Uncoiler
* Inner diameter: 508mm
* Outer diameter: 1200mm
* Loading weight: 3T
* Thickness of Material: 0.4-0.6mm
* Rolling Stations: 22 stations for square pipe and 26 stations for round pipes.
* Forming Speed: 10-15m/min. (not including cutting)
* Diameter of Shaft: ¢70mm
* Transmission: by chain-brackets
* Main Power: 7.5KW
* Weight of the machine appro.6 Tons.
* Cutting Type: Hydraulic cutting for rectangular downpipe and Flying Saw Cutting for Circle downspout
* Hydraulic Power: 4KW
* Material of cutter blade: Cr12 steel with quenched treatment.
* Cutting Length and Quantity: Clients can set the required length and quantity on the PLC touchscreen
* Electrical System for Rectangular Downspout Roll Forming Machine
* Panasonic PLC Control System and Omron Encoder;
Main parameters for downspout Elbow machine:
* Type of controlling: adopt strong electric controlling
* Main motor power: 2.2kw
* Max curving angle: 90 degrees.
* Functions: curving and biting
* Curving speed: 0-15m/min
* Dimension: 1300*650*1500mm
