Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Specifications
Brand Name :
WORLD
Model Number :
JW36
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 sets per month
Delivery Time :
45 working days
Packaging Details :
Standard export package
Voltage :
380V/220V Optional
Power(w) :
45kw
Condition :
New
Dimension(l*w*h) :
2850x1750x4140mm
Cnc or not :
Normal
Warranty :
1 Year
Power source :
Mechanical
After-sales service provided :
Engineers available to service machinery overseas
Weight :
3T
Color :
Customizable
Product name :
50Ton 100Ton Single Column C type Hydraulic Punch Press Machine
Type :
J23-100 mechanical power press punching machine
Application :
Metal Sheet Stamping,Power Construction,small single punch tablet making,Metal Punching,moulding and bending
Usage :
bending,punch press machine,stamping,molding
Nominal force :
630KN press machine
Keyword :
C frame press,Deep drawing press,power press,single column,Single arm press machine
Name :
power punch press machine
Description

Mechanical Punch Press Machine Hydraulic Deep Drawing H Type Power Press Machine

Features:

1. Welded body with steel plate and high intensity.
2.Main motor is made by Siemens.

3. Adopts combined pneumatic friction clutch and brake.

4 Cluster gear adopts the flooding oil lubrication

5. Six-face rectangle lengthen guide

6. Equipped with hydraulic overload protecting device

7. Electric compelling grease lubrication system.
8. Balancing cylinder adopts manual lubrication system.

9. One set of blowing device

10. Controlled by PLC with international brand

11. Buttons, indicators, AC contactors, air circuit breakers and other controlling devices are imported from international brand

12. Equipped with optional air cushion device, automatic feed shaft and photoelectric protector, which can used to work with various automatic equipments


Standard equipment:
Wet clutch(World)
Hydraulic overload protecting pump
Auto lubrication system
Manual lubrication system
Balance cylinders for slide and upper die
Digital die height indicator Joint for miss-feeding
Touch screen
Electronic crankshaft angle indicator
Cam controller
Rotary encoder
Movable operation panel
Die height adjusted motor
PLC:Programmable logical controller
Air blowing device
Shock Absorption Pads

Optional equipments:
Light curtain
Foot pedal
Air cushion device
Die quick change device
Frequency changer
Knock out device (Shank Hole)
Foundation bolts


Specifications:

ITEMCODEUNITJH25-110 JH25-160JH25-200JH25-250 JH25-315
Nominal CapacityPeKN11001600200025003150
Slide Stroke LengthSmm110130150170170
Slide StrokesFixed spm6060504040
Variable(optional) spm40-7040-7030-6030-4530-45
Max. Die Shut HeightH2mm435550550605605
Die Shut Height Adjustmenttmm90110110120120
Throat DepthC1mm350390430470480
Distance Between Uprightsd1mm14701600192021902170
Slide Bottom SizeFBbmm520580650700700
LRamm14001500185021002100
Shank Hole SizeDiameterdmm6060707070
DepthImm808590100100
Table SizeFBDmm680760840920940
LRCmm18802040242027002800
ThicknessH3mm155165170180190
Overall DimensionsFBAmm18202080237027002700
LRBmm19702150255028502850
HeightHmm32003380382041804180
Motor Power KW1118.5223037


Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
Deep Drawing 380V Metal Stamping Press Machine JW36 Automotive Stamping Press
