C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
C Frame J23 Mechanical Power Press Machine 1750mm Eccentric Press Machine
Specifications
Brand Name :
WORLD
Model Number :
JW36
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 sets per month
Delivery Time :
45 working days
Packaging Details :
Standard export package
Voltage :
380V/220V Optional
Power(w) :
45kw
Condition :
New
Dimension(l*w*h) :
2850x1750x4140mm
Cnc or not :
Normal
Warranty :
1 Year
Power source :
Mechanical
After-sales service provided :
Engineers available to service machinery overseas
Weight :
3T
Color :
Customizable
Product name :
50Ton 100Ton Single Column C type Hydraulic Punch Press Machine
Type :
J23-100 mechanical power press punching machine
Application :
Metal Sheet Stamping,Power Construction,small single punch tablet making,Metal Punching,moulding and bending
Usage :
bending,punch press machine,stamping,molding
Nominal force :
630KN press machine
Keyword :
C frame press,Deep drawing press,power press,single column,Single arm press machine
Name :
power punch press machine
Description

250 Ton Punch Press C Frame Single Crank Eccentric Mechanical Power Press Machine

This machine is applicate to all drawing, blanking, forming process, especially in the following areas: all kinds of containers,
all kinds of automobile covering parts, electric parts, kitchen utensils, tractor, motorcycle, aerospace,aviation, electronics,
instrumentation, plastic,rubber,chemical and other industrial departments.
Main Features
1) High accuracy, reach JIS-Grade1
2) High rigidity, steel-welded frame
3) High precision, 6-side long guide rail
4) Dry type pneumatic clutch-brake unit
5) Imported safety dual-solenoid valve for clutch
6) Automatic grease lubrication system
7) Frequency drive inverter
8) PLC system
Standard equipment:
Wet clutch(World)
Hydraulic overload protecting pump
Auto lubrication system
Manual lubrication system
Balance cylinders for slide and upper die
Digital die height indicator Joint for miss-feeding
Touch screen
Electronic crankshaft angle indicator
Cam controller
Rotary encoder
Movable operation panel
Die height adjusted motor
PLC:Programmable logical controller
Air blowing device
Shock Absorption Pads

Optional equipments:
Light curtain
Foot pedal
Air cushion device
Die quick change device
Frequency changer
Knock out device (Shank Hole)
Foundation bolts


Specifications:
ITEM CODE UNIT JH25-110 JH25-160 JH25-200 JH25-250 JH25-315
Nominal Capacity Pe KN 1100 1600 2000 2500 3150
Slide Stroke Length S mm 110 130 150 170 170
Slide Strokes Fixed spm 60 60 50 40 40
Variable(optional) spm 40-70 40-70 30-60 30-45 30-45
Max. Die Shut Height H2 mm 435 550 550 605 605
Die Shut Height Adjustment t mm 90 110 110 120 120
Throat Depth C1 mm 350 390 430 470 480
Distance Between Uprights d1 mm 1470 1600 1920 2190 2170
Slide Bottom Size FB b mm 520 580 650 700 700
LR a mm 1400 1500 1850 2100 2100
Shank Hole Size Diameter d mm 60 60 70 70 70
Depth I mm 80 85 90 100 100
Table Size FB D mm 680 760 840 920 940
LR C mm 1880 2040 2420 2700 2800
Thickness H3 mm 155 165 170 180 190
Overall Dimensions FB A mm 1820 2080 2370 2700 2700
LR B mm 1970 2150 2550 2850 2850
Height H mm 3200 3380 3820 4180 4180
Motor Power KW 11 18.5 22 30 37
